Thank you for purchasing this Southland™ Trimmer / Brush Cutter.
This manual provides complete instructions for safely operating, and maintaining your Trimmer / Brush Cutter. Read and
save these instructions. Refer to this manual each time before using your Trimmer / Brush Cutter.
Record the following for future reference:
Mfg. Date Code : _________________
Date of Purchase: Attach a copy of your sales receipt.
Consumer Toll Free Number: 1-800-737-2112
Refer to the website for electronic manual and parts book.
WARNING
This product contains one or more chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
If you have a question or problem...
CALL TOLL FREE: 1-800-737-2112
KEEP THIS MANUAL FOR FUTURE REFERENCE
01/27/2010
Operator's Manual
TRIMMER / BRUSH CUTTER
30cc, 2 Cycle
Page
1
2-4
5
5
5-7
8-11
12
12
13
13
14-19
www.gardnerinc.com
Printed in China
S-HBR-3017-SBEZ-E
MODEL Nos.
S-HBR-3017-SBEZ
For Occasional Use Only
A200482
