Summary of Contents for Gefei MIO-HDMI-CEXT
- Page 1 MIO-HDMI-CEXT HDMI signal Extender User Manual www.gefei-tech.com [Gefei Tech. Co., Ltd]...
- Page 2 Copyright Copyright © 2009 Gefei Tech. Co., Ltd All rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 3: Table Of Contents
Contents Product Description ..........................1 Features ................................1 MIO HDMI-CEXT panel Introduction ....................2 Application ..............................4 How To Connect the MIO HDMI-CEXT Extender System ............4 Technical specifications .........................6 Contact Us ..............................10... -
Page 4: Product Description
Provide a loop-out interface by receiver Mini box structure easily installed inside frame racks, video walls and so on Widely used in broadcasting system, studios and other professional fields © Beijing Gefei Tech. Co., Ltd 1 / 10... -
Page 5: Mio Hdmi-Cext Panel Introduction
MIO HDMI-CEXT-T left panel interface HDMI/DVI-IN: Support HDMI signal with embedded audio with a HDMI-to-DVI adapter. Supports input resolution as following: 480i 60, 576i 50 720P50/59.94/60, 1080I50/59.94/60, 1080P30/29.97/25/24/23.98 1080P50/60 Power jack: standard power: 12V, 1A © Beijing Gefei Tech. Co., Ltd 2 / 10... - Page 6 CABLE-IN: Receive the data transferred by coaxial cable with BNC interface, maximum transmission distance is 100 meters (Belden 1694) LOOP: Loops out the data from cable in, which could be used in cascade work type. © Beijing Gefei Tech. Co., Ltd 3 / 10...
-
Page 7: Application
How To Connect the MIO HDMI-CEXT Extender System 1. Connect the MIO HDMI-CEXT Extender transmitter (interface marked as HDMI/DVI-IN) to the DVI/HDMI source device, and you need a HDMI-to-DVI adapter when input © Beijing Gefei Tech. Co., Ltd 4 / 10... - Page 8 Connect MIO HDMI-CEXT Extender receiver (interface marked as LOOP) to the other MIO HDMI-CEXT Extender receiver (interface marked as CABLE-IN) if needed. 4. Connect the included 12V DC power adapter to the MIO HDMI-CEXT. © Beijing Gefei Tech. Co., Ltd 5 / 10...
-
Page 9: Technical Specifications
1080P50/60 Output Output interface: 1* coaxial cable, BNC connector Physical characteristics: Size: 120 X 95 X 27 mm Working temperature: 0-65˚C Deposit temperature: -20 - +70 ˚C Power: DC 12V 1A © Beijing Gefei Tech. Co., Ltd 6 / 10... - Page 10 Output interface: 1* coaxial cable loop out, BNC connector 1*DVI-I (digital signal), Female Physical characteristics: Size: 120 X 95 X 27 mm Working temperature: 0-65˚C Deposit temperature: -20 - +70 ˚C Power: DC 12V 1A © Beijing Gefei Tech. Co., Ltd 7 / 10...
-
Page 11: Device List
PO No. CUSTOMER: CARRIER： SHIPPING DATE: FROM Device List Name Specification Quantity Remark MIO HDMI-CEXT-T DVI (HDMI) TO Cable Transmitter MIO HDMI-CEXT-R Cable TO DVI (HDMI) Receiver AC-DC Power 12VDC 1A Total © Beijing Gefei Tech. Co., Ltd 8 / 10... - Page 12 Gefei-tech MIOHDMI-CEXT User Manual Accessories List Name Specification Quantity Remark Video Cable ----------- ----------- Audio Cable ----------- ----------- Power Cable ----------- ----------- User’s Manual (or Disk) Others Total © Beijing Gefei Tech. Co., Ltd 9 / 10...
-
Page 13: Contact Us
Technical support: Tel: 010-58858188 Fax: 010-58858189 Website www.gefei-tech.com E-mail：swangt@gefei-tech.com Address: Beijing Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd.Haidian District Beijing 100085 To find more information, please visit www.gefei-tech.com © Beijing Gefei Tech. Co., Ltd 10 / 10...
