BLUETOOTH MARKETING DEVICE
BT-Pusher PRO+
DeviceGate Technology Co.,Ltd
Web
http://www.bt-pusher.com/en
http://devicegate.en.alibaba.com/
Add
Room 4032,HaoJing Building,NO.9 DaGangGongYe Road,
TianHe , GuangZhou, GuangDong, China
Mail
bt-pusher@devicegate.com
Tel
0086-20-82317785, 0086-20-82317786
Fax
0086-20-62201638
LONG RANGE
USER GUIDE
Version 1.0.2
devicegate@gmail.com
Advertisement
Table of Contents
Summary of Contents for DeviceGate Technology BT-Pusher PRO+
-
Page 1: User Guide
LONG RANGE BLUETOOTH MARKETING DEVICE BT-Pusher PRO+ USER GUIDE Version 1.0.2 DeviceGate Technology Co.,Ltd http://www.bt-pusher.com/en http://devicegate.en.alibaba.com/ Room 4032,HaoJing Building,NO.9 DaGangGongYe Road, TianHe , GuangZhou, GuangDong, China Mail bt-pusher@devicegate.com devicegate@gmail.com 0086-20-82317785, 0086-20-82317786 0086-20-62201638... -
Page 2: Table Of Contents
BT-Pusher PRO+ User Guide Content Introduction..................3 Overview.................3 Function……………………………………………………………………………………………….3 Application…………………………………………………………………………………………..4 Features……………………………………………………………………………………………….5 Package Contents………………………………………………………………………………..5 Installation……………………………………………………………………………………………………….7 BT-Pusher Pro Interface Specification………………………………………………….7 User Guide…………………………………………………………………………………………….8 2.2.1 Power……………………………………………………………………………………………….8 2.2.2 FLASH DISK Local Managerment………………………………………………….10 2.2.3 Network Remote Managerment…………………………………………………….13 Installation Notes……………………………………………………………………..15 Warranty Information …….………………………………………..……………………………………17 Page 2 of 17... -
Page 3: Introduction
Overview BT-Pusher BlueTooth Advertising System is a new generational advertisement and information transmitting marketing system,which is developed by DeviceGate Technology Co.,Ltd. BT-Pusher Bluetooth Advertisng System can send promotional and advertising messages,business cards, event notifications to the mobile phones and all other Bluetooth-enabled devices automatically .You can provide your customers with news,... -
Page 4: Application
BT-Pusher PRO+ User Guide It can be monitored from remote distance over internet by wired(LAN) or wireless(GPRS ● or WIFI) Blacklist function ● A variety of refuse retransmission mechanism ● Auto pair with mobile bluetooth devices(mainstream mobile models) ● Show the system working status using LED ●... -
Page 5: Features
BT-Pusher PRO+ User Guide Transportation Auto parts sales shop ● Auto 4S shops Repair stations ● Motor City Cinemas ● Housing Sales Center Recreation centers ● Even you can think of any place, almost everywhere 1.4 Features Model BT-Pusher PRO+ Appearance Status indication LED status indication... -
Page 6: Package Contents
BT-Pusher PRO+ User Guide 1.5 Package Contents Each BT-Pusher PRO+ include: 1， BT-Pusher PRO+ device 2， A adapter Optional Accessories: 1， 4800mAH Li-ion battery（size:126cm(L)*81cm(W)*26cm(H)） Page 6 of 17... -
Page 7: Installation
BT-Pusher PRO+ User Guide 2. Installation BT-Pusher Pro+ interface specification Antenna USB INTERFACE POWER INPUT LED STATUS INDICATION NETWORK INTERFACE LED：Indicate the working status of the BT-Pusher PRO+ device POWER INPUT：DC 12V 1A power adapter USB INTERFACE：Used to connect flash disk for offline management. Please use BtspConfig software to modify corresponding parameters or update file contents and make sure to save the results to a flash disk,then insert the flash disk into the relevant BT-Pusher Device’s USB interface, the system will... -
Page 8: User Guide
BT-Pusher PRO+ User Guide 2.2 User Guide 2.2.1 Power 1. Put bt-pusher Pro+ device in a secure place, and Plug power adapter (DC 12V) in the power interface,As shown below: 2. You can also use lithium battery-powered, as shown below: 3. - Page 9 BT-Pusher PRO+ User Guide Then you will receive the BT-Pusher device’s default information, if you want to change what is being sent, please use BtspConfig or BTManagerServer software changes. (Please make sure your Bluetooth-enabled cell phone turned on , and Bluetooth visibility function keep alive.
-
Page 10: Flash Disk Local Managerment
BT-Pusher PRO+ User Guide 2.2.2 FLASH DISK Local Managerment BT-Pusher device with flash disk local management functions, through flash disk operation can update the system configuration information, modify the file content,blacklist and download log file and so on. Need to use the BtspConfig configuration software for the relevant operation.BtspConfig software on BtspConfig directory: Double-click to open BtspConfig.exe software, will appear below the （1）... - Page 11 BT-Pusher PRO+ User Guide Second, fill in the number of devices you need to configure and network （2） device name, as shown below: Please refer to document “BtspConfig software User Guide” for more detailed operation Note: The default server IP: 192.168.1.107, server port: 2323.
- Page 12 BT-Pusher PRO+ User Guide same with network management software BtManagerServer used.See network management software BtManagerServer installation directory under the config.ini file can know that it used network ports. If you want to connect to internet, You need write correct gateway IP Address in System Config window,and server ip must be a Internet ip address. Use BtspConfig software to modify corresponding parameters or update file contents and make sure to save the results to a flash disk,then insert the flash disk into the relevant BT-Pusher Device’s USB interface, the system will automatically set...
- Page 13 BT-Pusher PRO+ User Guide Flash disk inserted, BT-Pusher device’s top green light flashes once every （1） half a second, as shown below, indicates device being updated： When the top green LED stop flashing,The middle Green LED will （2） continue to flash, indicating update has been completed, the system re-enter the normal working state, only this time you can unplug the Flash disk.
-
Page 14: Network Remote Managerment
BT-Pusher PRO+ User Guide 2.2.3 Network Remote managerment Bluetooth advertising device BT-Pusher with network management capabilities ,it can be connected to the network, you can modify device configure,user blacklist,update files and download log files using BTManagerServer software. Please use network cable to connect network,as shown below: 2. - Page 15 BT-Pusher PRO+ User Guide 3. Double-click to open config file, make sure the server port local_port with BtspConfig software settings are same , as shown below:： 4. Double-click to open BtManagerServer software, and soon there is a device icon into a green, indicates BT-Pusher device is connected with BTManagerServer software, this time you can use BtManagerserver software...
-
Page 16: Installation Notes
BT-Pusher PRO+ User Guide Please refer to “BTManagerServer Software User Guide.pdf” for more detailed operation 2.3 Installation Notes 1. Away from the high-temperature place. 2. To avoid direct sunlight. 3. Do not put damp places, to avoid the water. 4. Do not place other equipment above BT-Pusher device. -
Page 17: Warranty Information
BT-Pusher PRO+ User Guide 3 Warranty Information DeviceGate guarantees BT-Pusher products are free of defects for a period of 12 months from the date of purchase. This warranty is non-transferable and applies to the original purchaser. BT-Pusher products found to be defective will be replaced free of charge. Purchaser is responsible for all shipping costs.
