Summary of Contents for Suttle H5EA
- Page 1 User Manual H5EA HDMI Extender over Single Cat5e 7.1 CH 7.1 CH AUDIO rev: 110127 AUDIO Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the H5EA should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
PS3 transmit utmost high quality video and audio with a greater distance at the minimal cost, when integrating several components apart. The H5EA includes two units: an HDMI transmitting unit and an HDMI receiving unit. The transmitting unit is used to capture the input HDMI/DVI signals and carry the signals through one RJ45 connector into one cost effective Cat-5/5e/6 cable. -
Page 4: Specifications
SPECIFICATIONS Model Name H5EA Technical Transmitting Unit Receiving Unit Role of usage Transmitter [TX] Receiver [RX] HDMI compliance High Speed HDMI - Deep Color & 3D support HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color... -
Page 5: Package Contents
PACKAGE CONTENTS ● 1x H5EA [TX & RX] ● 2x DC 5V 2A External Power Supply ● 1x User Manual PANEL DESCRIPTIONS Transmitting unit Input Panel Output Panel MODE SET: 0 – Supported up to 1080p 36-bit video and up to 7.1ch audio output. - Page 6 Note for EDID (Extended Display Identification Data) learning If you cannot get the audio / video output from the connected display from the first time setup. Please follow the instructions below to check if the extender is OK: Please set the rotary arrow on TX at "Mode 5"...
-
Page 7: Receiving Unit
Receiving unit Input Panel Output Panel +5V DC: Connect to 5V DC power supply unit. HDMI Signal IN: Connect to the HDMI Signal OUT on the transmitter unit with a solid Cat5e/6 UTP/STP cable. Signal Level: Adjust the 8-level signal equalization control to the received HDMI signals. The HDMI signal level varies from 0 (strongest) to 7 (weakest) for respective transmission length from longest possible range to short distance. -
Page 8: Installation
INSTALLATION 1. Connect a HDMI or DVI source (e.g., a Blu-ray Disc player) to the Transmitter Unit. 2. Connect a HDMI or DVI display (e.g., a LCD HDTV) to the Receiver Unit. 3. Connect a solid Cat-5/5e/6 UTP/STP cable between the Transmitter and Receiver units. 4. -
Page 9: Edid Learning
EDID just learned and restore to default EDID. 5. Unplug the HDMI cable from the display and follow the instruction in [INSTALLATION] section to set up the H5EA and enjoy the experience. NOTICE 1. When adjusting the signal level on the receiver unit, please dial the rotary control switch from 7 to 0 and stop turning the rotary switch whenever the audio/video is playing normally. -
Page 10: Performance Guide
PERFORMANCE GUIDE Performance rating Type of category cable Wiring Shielding CAT5 CAT5e CAT6 Unshielded (UTP) Solid Shielded (STP) Unshielded (UTP) Stranded Shielded (STP) Termination Please use EIA/TIA-568-B termination (T568B) at any time RJ45 / CAT5 PIN DEFINITION RJ-45 Jack Data Link TIA/EIA-568-B Function Color PAIR3...
