Specifications - Aiken Amplification Invader MKII User Manual

Specifications

Output Power:
Input Impedance:
Input sensitivity:
Tube complement:
Fuses:
Speakers:
Footswitch:
Dimensions:
Weight:
InvaderMKIIManual.doc
18W for the 2-EL84 model or 30W for the 2-
EL34 model, at onset of clipping into resistive
load at rated impedance.
1Megohm
10mV for output clipping, all volume/tone
controls fully up, ali mode.
Four ECC83/12AX7, one 12AT7, two EL84
(18W model), or two EL34 (30W model).
18W/100V-120V: Mains: 2A slo-blo, HT:
500mA fast-acting
18W/200V-240V: Mains: 1A slo-blo, HT:
500mA fast-acting
30W/100V-120V: Mains: 2A slo-blo, HT:
500mA fast-acting
30W/200V-240V: Mains: 1A slo-blo, HT:
500mA fast-acting
Varies, depending on model and customer
preference.
Accepts any normally-open on/off footswitch
to control reverb function (not included)
Head: 25.5" W x 10.25" H x 9" D
1x12 combo:
2x12 combo:
18W chassis only: 23 lbs
30W chassis only: 29 lbs
Head cabinet (no chassis): 14lbs
1x12 combo cabinet with Greenback speaker
(no chassis): 33bs
2x12 combo cabinet with Greenback
speakers (no chassis): 46lbs
Examples:
18W head total weight = 37lbs
30W head total weight = 43lbs
18W 1x12 combo total weight = 56lbs
18W 2x12 combo total weight = 69lbs
30W 2x12 combo total weight = 75lbs
12/08/11
Copyright 2003-2011, Aiken Amplification, Inc.
25.5" W x 21"H x 10.25" D
29" W x 21" H x 10.25" D
Page 17 of 17
