Summary of Contents for ViewQwest TV
- Page 1 Welcome You’re watching ViewQwest TV. User Manual...
-
Page 2: Table Of Contents
Contents Safety Information Product Features What’s in the Box ViewQwest TV at a Glance Connect Starting ViewQwest TV Setting Up Configure Homescreen User Interface Managing your Device Manage personal settings Enjoy Controlling the device Q&A... -
Page 3: Safety Information
•Do not remove any parts of the device. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way. •When connecting the unit and TV with the HDMI cable, ensure that power is disconnected. •Use only attachments and accessories specified or recommended by... - Page 4 2. Storage •Unplug the device during lightning storms or when unused for long periods of time. •Do not expose the device to extreme moisture, dust or vibrations. •Store the device away from direct sunlight, excessive heat, fire and extreme cold environments. •Store the device in a cool, dry place.
- Page 5 ViewQwest TV Quick Start Guide...
-
Page 6: Product Features
•Android 4.1.1 OS: With Android 4.1.1 Jelly Bean you can customize ViewQwest TV the way you want it by choosing from thousands of apps in the Google Play store. There’s virtually no limit to what you can do from the comfort of your couch. -
Page 7: What's In The Box
What’s In the Box Power Adaptor Micro USB Cable Mouse AVI Cable ViewQwest TV HDMI Cable... -
Page 8: Viewqwest Tv At A Glance
ViewQwest TV at A Glance MICRO SD USB1 USB2 DC 5V HDMI ETHERNET A/V OUT Micro SD Card Slot Enables device to read and write data to SD media inserted in the slot USB Host Port Ports for USB mouse, USB keyboard or mobile... -
Page 9: Connect
Connect. Welcome to the new TV Generation... -
Page 10: Starting Viewqwest Tv
Turning On / Off ViewQwest TV •Power on: Plug ViewQwest TV into a power source and the system will run automatically. When the device is properly connected, you will see the ViewQwest logo followed by the Home screen. -
Page 11: Setting Up
Setting Up Connecting to HDTV 1. Connect one end of the HDMI cable to your ViewQwest TV, the other end to your HDTV. 2. Turn on your ViewQwest TV and your HDTV. 3. Use your HDTV’s remote control to setup the transmission. -
Page 12: Configure
Configure. The 2nd step into a new TV Generation... -
Page 13: Homescreen User Interface
Homescreen User Interface Once your ViewQwest TV is turned on, you will see the home screen. You will then be able to access all the features on your ViewQwest TV, including applications, widgets, and others. Legend: Go back to previous screen... -
Page 14: Managing Your Device
- You will need to un-mount the SD Card or only remove your SD card when ViewQwest TV is being turned off. Open Settings > Press SD card & device storage > Click Unmount SD card. - You can now safely remove the SD card from your ViewQwest TV. - Page 15 Managing your Network •Wireless: Make sure ViewQwest TV is within range of your wireless router, Use Wireless & Network settings to configure and manage connections. •Wired: Plug the network cable into the network port of your ViewQwest TV and you will be connected.
- Page 16 Manage applications: Opens a list of all the applications and other software installed on your ViewQwest TV, along with their file sizes. You will also be able to retrieve application’s information, manage its settings and uninstalling it from here.
-
Page 17: Manage Personal Settings
Manage Personal Settings Language & Input Use the Language & Input settings to select the displayed language and to configure the onscreen keyboard. Select language Opens the Language screen, where you can select your preferred language. Select input method You can select the text input method. Mouse sensitivity option You can adjust the mouse pointer speed. - Page 18 Date & Time To set date, time zone, time, time format, date format. About Machine Information about your ViewQwest TV. Legal Information To assess legal information on open source licenses. Version Information Lists details on model number, Android version, Kernel version, system...
-
Page 19: Controlling The Device
Controlling the Device You can easily control the device with the ViewQwest mouse. Using the Mouse for the first time Plug the signal receiver into the player. Remove the signal receiver from the mouse. Insert two AAA batteries. - Page 20 & Problem? Don’t Worry!
-
Page 21: Troubleshooting
If the ViewQwest TV is not responding, first make sure : •The cables between device and your TV are connected properly. •The power cords for device and your TV are securely connected to a working power source. •Your TV is turned on and the input has been set properly. - Page 22 Make sure you’re using the correct HDMI cable and that it is firmly connected to the ViewQwest TV. Make sure the input setting on your TV matches the input port the HDMI cable is connected to. For information, see the documentation that came with your TV.
-
Page 23: Product Warranty
0° and 40 °C (32 °C to 104 °F). Keeping the outside of the ViewQwest TV clean To clean your ViewQwest TV, unplug the power cord and all cables. Then use a soft , lint-free cloth. Avoid getting moisture in openings. - Page 24 Have a Question? Contact Us http://forum.fibernet.sg noc@viewqwest.com 6723 8100...
