NOTE!
Make sure that all bolts are tightened
to the correct torque and that nothing
fouls or restricts movement of the shock
absorber when the suspension is being
fully compressed or extended.
WARNING!
Certain modifications may be neces-
sary when installing the Öhlins shock
absorber/suspension. It is essential that
the mounting instructions are carefully
followed.
Traction, handling,
comfort and safety
Öhlins Racing AB, Box 722, S-194 27 Upplands Väsby, Sweden.
Phone +46 8 590 025 00, fax +46 8 590 025 80.
E-mail: info@ohlins.se
Notes
Mounting instructions
HU 095 - HUSABERG MX 2000
Kit content
Shock absorber,
Type 46PRCQ
Sticker Öhlins
00197-01
Sticker Memo note
01180-01
C.spanner
00710-02
Owners Manual
Setup data
Lenght
415 mm
Stroke
107 mm
Rebound adjustment
18 clicks
Compression adjustment
15 clicks
Preload
1 mm
Hu095
2
1
1
