Page 1: User Manual
HDMI V1.4 Over Cat5e Extender • Full 1080p and 3D support • Extends signal up to 100m • Transfers IR control signal • Carries 100Mbps Ethernet • Supports all digital audio formats • Model #33-12550 Distributed Exclusively by MCM Electronics www.mcmelectronics.com... - Page 2 INTRODUCTION For optimum performance and safety when using this product, please read these instructions carefully before connecting, adjusting or operating. Please keep this manual for future reference. The Stellar Labs Model 33-12550 set consists of a transmitter and receiver. The transmitter converts and combines the HDMI, Ethernet and Remote Control signals into an HDBaseT signal, and transmits it over conventional Cat5e or Cat6 Ethernet cable.
- Page 3 ports can act as the input, allowing the remaining three to act as outputs. Because the extender can reach distances of up to 100 meters, it also solves the problem of reliable HDMI signal transmission over long distances. It offers a solution for space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
- Page 4 • Video Output Support: 24/50/60fs/1080p/1080i /720p/576p/576i/480p/480i • Support 1080p @ 60Hz @ 48bit pixels • Support Audio Format: DTS-HD/Dolby- trueHD/LPCM7.1/DTS/Dolby-AC3/DSD • Support CEC • Capable of sending 10.2Gbps HDMI Signal and 100Mbps Ethernet signal, over Cat5e / Cat6 cable • Maximum distance 100m •...
-
Page 5: Included Accessories
INCLUDED ACCESSORIES This kit includes the following items. Upon purchasing the product, please check to ensure all items are present prior to attempting installation. • HDBaseT Transmitter • HDBaseT Receiver • (2) 5VDC, 2A AC adaptors • (1) IR Emitter with attached 44” cable and 2.5mm male plug •... - Page 6 PANEL LAYOUT/CONNECTION Rear Panels...
- Page 7 DC/5V Located on the rear panel of each unit is the input for the 5V AC Adaptor. The AC adaptors should not be connected to a power source until all other connections are made. HDMI Ports The TRANSMITTER has the HDMI input, which will come from the high definition media source, such as a DVD or BluRay player, digital cable box or satellite receiver.
- Page 8 HDBaseT Ports The units are connected together via a Cat5e or Cat6 cable, which can be up to 100m (328’) in length, and inserted into the HDBaseT ports. This single Cat55/6 cable will carry all high definition video, digital audio, Ethernet and IR signals.
- Page 9 PANEL LAYOUT/CONNECTION Front Panels...
- Page 10 POWER Each unit has a red LED indicator, confirming that power is connected to the unit. LED (1) and (2) The green LED’s labeled 2, confirms the connection between the two units, via the Cat5e/6 cable connected to the HDBaseT ports. The green LED labeled 1 confirms the presence of an HDMI signal.
- Page 11 IE (transmitter only) This 2.5mm female connection is for the IR emitter provided with this set. Simply plug the emitter into this port, and position it near the video source device (such as a digital cable box). Now the IR remote control, provided with the cable box, can be used in the remote location, near the television monitor, to control the cable box.
- Page 12 SPECIFICATIONS Max Cable Length 100m (328’) Supported Resolutions 24/50/60fps 480p/576p/720p/1080p 480i/576i/1080i Supported Audio DTS-HD/Dolby-trueHD LPCM7.1/DTS/Dolby-AC3 Max bandwidth 340MHz Max baud rate 10.2Gbps Input video signal 0.5V ~ 1.5V p-p Output DDC signal 5V p-p (TT1L) HDMI cable distance 10m (32’) at input (26AWG cable) 15m (49’) at output Power requirements...
-
Page 13: Warranty
Electronics will replace or repair this unit (at their option) within a reasonable time. No expressed or implied warranty is made for any defects caused by, abuse, neglect, improper operation of unit, excess wear and defects resulting from modification of this unit. Distributed Exclusively By: MCM Electronics www.mcmelectronics.com...
