Lookee TV 6636D07HD Instruction Manual

Desktop style 7” hd internet tv & radio player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction Manual
Model 6636D07HD
Desktop Style 7" HD Internet TV & Radio Player

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6636D07HD and is the answer not in the manual?

Questions and answers

Summary of Contents for Lookee TV 6636D07HD

  • Page 1 Instruction Manual Model 6636D07HD Desktop Style 7” HD Internet TV & Radio Player...

  • Page 2: Table Of Contents

    Location of Controls on the Main Unit - Rear Location of Connectors on the Main Unit - Rear Location of Controls on the Remote Control Understanding the Remote Control Operational Instructions Start Menu Connecting to the Internet through Wi-Fi. Lookee TV Lookee Radio Revision3 Inmoo Blubrry UrLlama LookeeSound 4.10 SHOUTcast...
  • Page 3 Other Settings Network Setting 5.1.1. Wi-Fi Setup 5.1.2. Connecting Options 5.1.3. Network Status Network Cable Setup Language Alarm Key Tone Setting Slideshow Setting FM Setting Screensaver time Time Zone 5.10 Date & Time 5.11 Firmware Update 5.12 Auto Power Off 5.13 Restore Default Factory Setting 5.14 About Troubleshooting Guide...

  • Page 4: Introduction

    Introduction Congratulations on your purchase of a LookeeTV HD Internet TV & Radio Player. You now have access to TV channels, radio stations and podcasts from all over the world via internet connection. To maximize your enjoyment of this product, please read this manual carefully – it contains important information on how to use your LookeeTV device effectively.

  • Page 5: Product Features

    2.2 Product Features Stream thousands of TV channels, radio stations, podcasts and apps from all over the world via  Wi-Fi or Ethernet connection. Optional subscriptions for selected premium partner content.  Built-in LookeeTV SmartController™ Technology seamlessly syncs and integrates the ...

  • Page 6: Featured Apps

    2.3 Featured Apps These are just some of the great media applications that you can enjoy on your LookeeTV. • Lookee TV • Lookee Radio • SHOUTcast • Podcast • Revision3 • Media Player • Blubrry • Ur Llama •...

  • Page 7: Getting Started

    Getting Started 3.1 Locations of Controls on the Main Unit - Rear MENU: Press once to go back to the previous directory or sub directory. Hold for about 3 seconds to go to the main menu. POWER: Hold for two to three (2-3) seconds to turn power ON/OFF. Press to activate/deactivate low light sleep mode when LookeeTV is on.

  • Page 8: Location Of Connectors On The Main Unit - Rear

    3.2 Location of Connectors on the Main Unit - Rear SD/MMC Card Slot HDMI Output RJ45 Ethernet Jack USB Mini 5P and AC/DC Power jack Earphone Jack CVBS Output FM/Line in (Audio)

  • Page 9: Location Of Controls On The Remote Control

    3.3 Locations of Controls on the Remote Control...
  • Page 10 2. LCD/TV: switch LCD/TV 3. MUTE 4. NETWORK: Shortcut key to open Network Settings quickly 5. I-TV: Lookee TV shortcut key 6. I-RADIO: Lookee Radio shortcut key 7. FULL SCREEN: Switch three screen display mode 8. FUNCTION: Multi-use key specially made for use with certain apps 9.

  • Page 11: Operational Instructions

    Operation Instructions 4.1 Start Menu After plugging in your LookeeTV device, press the POWER button on the unit for two (2) seconds to turn it on. After the LookeeTV logo page, you will be brought to the main menu as seen below. Use the directional buttons and select options.

  • Page 12: Lookeetv

    LOOKEETV 1a: Two types of network: Encrypted network: Show a “lock” icon and a password is required for access to the  network. Unencrypted network: There’s no “lock” icon and a password is not required for access to  the network. Use the directional buttons on your remote control to select a network and press ENTER on the remote or OK on the unit to connect.
  • Page 13 If the system is successfully connected to the selected network, a notification will show “Wi-Fi Connected Successfully”; otherwise “Wi-Fi Password Invalid” will appear. Please ensure you selected the correct network, and have the correct password, and try again. If a “Wi-Fi Connection time out”...
  • Page 14 4.3 Lookee TV When you select Lookee TV on the main menu, your LookeeTV device connects to an internet portal and provides a list of TV channels. These channels are organized based on region, genre, and language. Use the directional buttons, and ENTER on the remote control or OK on the main unit to choose different channels.
  • Page 15 Pressing OK on the main unit. Pressing ENTER OR FULL SCREEN on the remote control. Other instructions: UP/DOWN or VOL+/VOL-: Adjust the volume +/- LEFT/RIGHT: Go to the next/previous channel STOP/EXIT: Exit from the current playing channel and go back to the Lookee TV Menu...

  • Page 16: Lookee Radio

    ENTER on the remote control or OK the main unit to choose different stations. The Lookee Radio option functions similarly to the Lookee TV option. This image below is the screenshot of the Lookee Radio playing mode: 4.5 Revision3...

  • Page 17: Inmoo

    4.6 Inmoo Gain access to original content from 100 countries in more than 60 languages. This includes thousands of films ranging from comedy and drama to documentaries. Inmoo is reshaping the way independent movies are being distributed, and now you can take part simply by watching it happen right on your LookeeTV.

  • Page 18: Lookeesound

    4.9 LookeeSound Powered by the renowned SoundCloud audio distribution platform, LookeeSound allows you free access to original music from established and up-and-coming artists from all over the world. Collaborate, record, upload, promote and share the sounds you create with the world’s largest community of sound creators on the planet. 4.10 SHOUTcast The SHOUTcast internet radio app offer thousands of internet radio stations from all over the world.

  • Page 19: Lookeetv Smartcontroller™ Technology

    You can view programs stored by Podcast publishers and sort them by genre. Use the directional buttons, and ENTER on the remote control or OK on the main unit to choose different stations. Please refer to the Lookee TV mode instructions at 4.3.

  • Page 20: Media Player

    4.13 Media Player 1) Playing Video/Music/Picture Files from the Local Disk (Built-in Memory) The LookeeTV Desktop unit comes with built-in memory. You can transfer the data between this unit and your computer via a USB cable. When you first connect your device to your computer, please format your Local Disk by doing the following: 1.
  • Page 21 Once the formatting is complete, a pop up window will indicate “Format complete” and your LookeeTV device will be ready for data transfer from your PC. 4: Go to Main Menu > Media Player > Disk (As depicted below) Press ENTER on the remote or OK on the unit to select Local Disk. There will be three folders: Video, Music and Picture.
  • Page 22 8. I Love LookeeTV – Lookee Crew Press UP/DOWN to select the songs and press ENTER on the remote or OK on the unit to play.

  • Page 23: Upnp

    Other instructions: LEFT/RIGHT: Select the previous/next song; hold for fast backward/forward. VOL-/VOL+: Adjust the volume EXIT: Exit from the current music playing mode. Once it’s selected, a prompt, “Turn Off Music” appears. Press YES to exit and stop playing music, or NO to exit to leave music on as background music.
  • Page 24 3. Click the “Internet Radio” icon and click “Allow” button to activate the sharing function. Press “OK” to confirm the settings. 4. Go to Library > Add to Library and then Select “My folders and those of others that I can access”. Then Click “Advanced Options”...
  • Page 25 6. Click “Close” when the adding process is complete. 7. Go to Main Menu  Select UPnP and press ENTER on the remote or OK on the unit to search all available UPnP devices. Press UP/DOWN on the remote control or on the LookeeTV unit to select the UPnP device on the list and press ENTER on the remote or OK on the unit.

  • Page 26: Digital Photo Frame

    Note: For the faster video performance, please try to stream smaller size videos in lower resolution. 4.15 Digital Photo Frame There are two options with the digital photo frame function: 1. Navigate to “Photos” from the main menu, Press ENTER on the remote or OK on the unit, and you will choose between “Disk”...
  • Page 27 Picture Slideshow with background music: If you want to enjoy a picture slideshow with background music: please go to Media Player, Internet Radio or FM Radio to choose the music you like and exit with the music on. Then navigate to the above mentioned “Photos”...

  • Page 28: Line In Function

    4.16 Line in Function. You can also enjoy your music from your iPod, iPhone, MP3 and any audio device through the LookeeTV’s powerful speaker system. Use a 3.5mm audio cable (optional accessories) to connect your audio output device to the “Line in” jack on the back of the LookeeTV device.
  • Page 29 Alarm Setting: Please see below for details.  Alarm On/Off: Turn on/off the alarm. Alarm Time: Press Up/Down/Left/Right on the remote control or the main unit to set the alarm. After finish the digital setting, press ENTER on the remote or OK on the unit to confirm. Snooze Setup: Snooze time options: 8, 12 and 20 minutes.

  • Page 30: Fm Radio Setup

    4.18 FM Radio Setup 1. Connect the FM antenna to the FM/Line In jack at the rear of the LookeeTV unit. 2. Go to Settings > FM setting > Region Setting and select from the available regions: FM Broadcast Band or Japanese FM Band. 3.

  • Page 31: Tv / Lcd Output

    4.19 TV / LCD Output The LookeeTV Desktop HD supports two types of video and audio output: 1. LCD output from the main unit: 7” TFT high resolution 800 X 480 pixels, 16:9 LCD 2. TV output: • HDMI output at 720p resolution (with HDTV) •...

  • Page 32: Other Settings

    Now you can enjoy all of the LookeeTV video, audio and images right on your own TV . Other Settings Select the “Settings” menu and choose the following options. 5.1 Network Setup: (See section 4.2) 5.1.1 Wi-Fi Setup: You will see the three options here: A.

  • Page 33: Key Tone Setting

    effect immediately. 5.4 Alarm: Please refer to the information provided in section 4.17. 5.5 Key Tone Setting: Tone On – Press ENTER on the remote or OK on the unit to turn on the key tone, and then you will see 5 Key tone sound options; Tone Off – Turn off the key tone. 5.6 Slideshow Setting: You can set the picture slideshow interval time (5, 10, 15 and 30 seconds) for each image, and display mode (Full screen or original).

  • Page 34: Restore Default Factory Setting

    - Visit www.lookeetv.com/support - Download the latest “BSI-6636D07HD Desktop 7” LCD Wi-Fi Internet TV & Radio Player Recovery System File”, on your computer. This is a ZIP file, so please extract all files and then save the extracted files to the root of a blank SD card (minimum 128 MB memory). Please DO NOT change any file names.

  • Page 35: User Safety Guide

    audible levels. 6.5 My remote control is not functioning. - Ensure you are operating your remote control within range of your LookeeTV unit (about 3 meters) and try again. - If problem persists, check the battery and replace if necessary. 6.6 My LookeeTV cannot connect to a Wi-Fi network.

  • Page 36: Specifications

    Specifications LCD: 7” TFT High Resolution, 16:9 LCD display AV Out: CVBS and HDMI Audio Output: 2x2W Hi-fi Speaker I/O ports: -SD/MMC Card Slot -HDMI Output -RJ45 Ethernet Jack -USB Mini 5P and AC/DC Power jack -FM Output (Audio) -Earphone Jack/CVBS Output -Line in (Audio) Wi-Fi: - WLAN security: Support WPA, WPA2, WEP...
