West Warwick, Rhode Island 02893
Telephone 401-884-6300
LBC Series Bottom Connection Bladder Series
Pressurized Expansion Tanks (ASME)
READ CAREFULLY THE PRODUCT INSTALLATION, OPERATING AND MAINTENANCE MANUAL.
INSTRUCTIONS AND WARNINGS IN THE MANUAL MAY RESULT IN SERIOUS OR FATAL INJURY AND/OR PROPERTY DAMAGE, AND
WILL VOID THE PRODUCT WARRANTY. THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED PROFESSIONAL. FOLLOW ALL APPLICABLE LOCAL AND
STATE CODES AND REGULATIONS, IN THE ABSENCE OF SUCH CODES, FOLLOW THE CURRENT EDITIONS OF THE NATIONAL PLUMBING CODE AND
NATIONAL ELECTRIC CODE, AS APPLICABLE.
EXPLOSION OR RUPTURE HAZARD A relief valve must be installed to prevent pressure in excess of local code requirement or
maximum working pressure designated in the Product Manual, whichever is less. Do not expose Product to freezing temperatures
or temperatures in excess of 240° F. Do not adjust the pre-charge or re-pressure this Product except for any adjustments required at the time of initial
installation, especially if Product corroded, damaged or with diminished integrity. Adjustments to pre-charge must be done at ambient temperature only.
Failure to properly size the Product or follow these instructions may result in excessive strain on the system lead to Product failure, serious or fatal personal
injury, leakage and/or property damage.
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO POTENTIAL PERSONAL INJURY AND OTHER HAZARDS. OBEY ALL SAFETY
MESSAGES THAT FOLLOW THIS SYMBOL TO REDUCE THE RISK OF PERSONAL INJURY AS WELL AS PROPERTY DAMAGE.
Part #9017-095 (04/07)
INSTALLATION, OPERATION &
SERVICE INSTRUCTIONS
EXTROL
®
LBC SERIES
For Models:
35 LBC
50 LBC
85 LBC
100 LBC
130 LBC
165 LBC
200 LBC
300 LBC
400 LBC
500 LBC
600 LBC
FAILURE TO FOLLOW THE
Advertisement
Related Manuals for Amtrol EXTROL 100 LBC
Summary of Contents for Amtrol EXTROL 100 LBC
- Page 1 West Warwick, Rhode Island 02893 Telephone 401-884-6300 LBC Series Bottom Connection Bladder Series Pressurized Expansion Tanks (ASME) READ CAREFULLY THE PRODUCT INSTALLATION, OPERATING AND MAINTENANCE MANUAL. INSTRUCTIONS AND WARNINGS IN THE MANUAL MAY RESULT IN SERIOUS OR FATAL INJURY AND/OR PROPERTY DAMAGE, AND WILL VOID THE PRODUCT WARRANTY.
-
Page 2: Operating Instructions
Maximum Operating Pressure: As stamped on nameplate Maximum Operating Temperature: 240 °F Minimum Operating Temperature: 35°F (non-glycol application) If unit is being installed in a glycol system where minimum temperatures fall below 35°F, contact the AMTROL technical service department at ALERTS APPEAR (401) 535-1216. - Page 3 SUGGESTED PIPING DIAGRAMS ALTERNATE PIPING DIAGRAMS...
- Page 4 What is covered by this Warranty AMTROL warrants to the purchaser or first user of the new Product that at the time of manufacture, the Product is free from defects in material and workmanship. Any warranty claim must be made within one (1) year unless another time period is set forth in the Manual, measured from the time the Product was purchased.
