HUSTLER Kawasaki Trimstar Hydro Walkbehind Brochure & Specs

THE TRIMSTAR HYDRO-WALKBEHIND
But where to begin?
•
No daily lube points!
They're not easily discussed, these new TrimStar Hydro walk-
•
A full two-year bumper-to-bumper warranty – parts and labor!
behinds, their benefits many, their advantages everywhere.
•
Lifetime warranty on the
So pick any reason why... productivity, ergonomic ease
leading edge of the deck
of use, quality of cut and accessibility to tight lawn
•
3-years on the blade spindle bearings
spaces, simplicity of maintenance... and let that be
•
3-years on front-caster fork bearings
your rationale for running the most innovative,
most technologically advanced walk-
Behind on the market today. The
TrimStar Hydro WalkBehind
will deliver. And we're
now about to count
the ways.
•
Patented H-Bar TM Plus
steering system – the easiest-to-learn,
easiest-to-use, walk-behind steering system. The mower
seems to glide over the lawn effortlessly! Now with cruise control!
With the addition of the Hustler Roll-On TM striping sulky you really will
glide over the lawn while creating beautiful striping.
•
The newly-designed, full-floating decks
offer the highest-quality cut and finished
appearance on the market. In side-discharge
or mulch, the TrimStar Hydro will produce an
immaculate lawn
•
Simple, efficient drive system – integrated,
serviceable IZT transmissions. No hoses, no leaks.
• Competitive price – the TrimStar Hydro is
priced lower than competitive hydrostatic,
floating-deck units for a tremendous value
in the commercial mowing market.
Engine Specifications
Model Kawasaki Kawasaki
Horsepower 15 17
No. of Cylinders 2 2
Displacement 26.3 cu in (431 cc) 30.1 cu in (585 cc)
Compression Ratio 8.5:1 8.5:1
Max. Torque 23.6 ft lbs @ 2400 rpm 36.2 ft lbs @ 2000 rpm
Starting Recoil Tire-to-tire Width: 33.25 in (84.5 cm)
Weight: 550 lbs (249.48 kg)
Ignition Electronic
W/48 in Deck Length: 73.5 in (186.69 cm)
Charging System 12-volt, 15-amp
Overall Width: 49.5 in (125.73 cm)
Fuel Unleaded gasoline
w/discharge chute up
Tire-to-tire Width: 39.5 in (100.33 cm)
Fuel Filter Replaceable, automotive-type
Weight: 550 lbs (249.48 kg)
Air Cleaner Dual element
Safety Features
Cooling Air cooled. Fly-wheel fan
Operator presence safety-interlock system. Side discharge
Governor Mechanical
deck with discharge chute
Traction Drive System
Construction Mainframe is reinforced 1/8 in welded steel
Type Dual hydrostatic. Hydro-Gear IZT
construction.
Pump Drive V-belt drive from engine crankshaft Controls Hand-operated throttle/choke, ignition switch,
mower clutch switch
Ground Speed 0-6.0 mph (0-9.7 kph) forward and 0-2 mph
(0-3.2 kph) reverse, infinitely variable
Indicators Hour meter
Steering Patented, self-centering H-Bar (Hustler Bar) Plus
™ Warranty 2-year parts and labor warranty on entire unit
Steering provides independent control of each drive wheel.
3-year limited warranty on front caster fork bearings
Speed, forward, reverse, brake, and turns are all controlled with
and blade spindle bearings Lifetime warranty on leading
the easy to learn, easy to operate H-Bar Plus Steering. Now
edge of the deck
with cruise control.
Decks 36" and 48" XR-7 Side-Discharge Decks. Free-
Turning Radius True zero turning radius. Turns within its own
floating, side-discharge mower using three blades (36"
length. Counter-rotating, independent drive wheels
deck uses 2 blades). Mower is suspended at the corners
Brakes Service: Hydrostatic dynamic braking by four height-adjustment pins. 48" XR-7 deck includes
FreeFlow™ triangles for improved cutting and reduced
Parking: Sprocket and cog
build up under the deck, deck-mounted anti-scalp rollers
Mower Drive Warner electromagnetic clutch.
to improve flotation in rolling and uneven terrain.
Tires Front: Two – 11 x 4 – 4, smooth, semi-pneumatic
Construction
Drive: 18 x 9.50 – 8, turf tread (18 x 6.50 – 8 on 36" model)
36 in Deck: 7-gauge deck plate with 7-gauge doublers.
Capacities 48 in Deck:11-gauge deck plate with 11-gauge doublers.
1-1/2" x 1/2" steel bar reinforced impact areas on front
Fuel System: 5 US gal
and trim edges, heavily-reinforced front edge. Lifetime
Dimensions
warranty on leading edge of deck. Deck housing is 4
Height: 41.4 to 45.4 in (105.16 to 115.32 cm) adjustable in deep to provide room for high-capacity mowing
Discharge Side
W/36 in Deck Length: 74 in (187.96 cm)
Cutting Heights Pin-type adjustment at four corners of
Overall Width: 37.7 in (95.76 cm)
deck in .25 in increments from 1.25 in to 4.5 in (.1 cm
w/discharge chute up
w w w . h u s t l e r t u r f . c o m
F o r m o r e i n f o r m a t i o n :
H u s t l e r T u r f E q u i p m e n t • H e s s t o n , K a n s a s 6 7 0 6 2 • 1 - 8 0 0 - 3 9 5 - 4 7 5 7
increments, 3.18 cm to 11.43 cm)
Main Blades Heavy-duty, heat-treated, 10B38 steel blades
36 in Deck 20.5 in x 2.50 in x .204 in LH blade
13.75 in x 2.50 in x .204 in RH blade
48 in Deck: 16.5 in x 2.50 in x .204 in
Fusion ™ blades feature tungsten carbon material fused to the
bottom of the blade. This material is very hard and blades stay
sharper longer necessitating sharpening less often and better
cutting quality for longer periods of time.
Blade Tip Speed 36 & 48 in Deck 18,500 fpm
Blade Drive V-belt drive to spindles. Spring tension idler pulleys
Spindles Aluminum casting with steel shafts and sealed ball
bearings
Trim Capacity (left side): 36 in Deck:0 in (0 cm)
48 in Deck: 2 in (5.08 cm)
Configurations 36" SD Deck, 15 hp
48" SD XR-7 Deck, 17 hp
Accessories
Mulch Kits Recycles clippings under deck allowing clippings to
be cut and recut, then discharged down into grass. Reduces han-
dling of clippings, improves appearance, and recycles nutrients
back to the soil
Deck-Mounted Catcher Easily-installed, side-mounted catcher
holds 3.75 bushels.
Roll-On Striping Sulky A stand-on sulky that features a strip-
™
ing roller instead of tires. Produces beautiful striping results
because weight of operator improves striping performance.
Compatible with after-market sulkies and trailers
Weight Kit
Specifications subject to change without notice.
Form No. 799163 4-06
