ASHBERRY II PLAY SYSTEM – F23073C
INSTALLATION AND OPERATING INSTRUCTIONS
29'11
"
17'-11"
10-14 Hrs
Two person
assembly
3403073C
WARNING
and give them to any future owner of this play system. Manufacturer contact information provided below.
OBSTACLE FREE SAFETY ZONE - 29'11" x 26' area requires Protective Surfacing. See page 3.
MAXIMUM VERTICAL FALL HEIGHT - 6'5"
CAPACITY - 10 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.
RESIDENTIAL HOME USE ONLY. Not intended for public areas such as schools, churches, nurseries, day cares or parks.
Solowave Design
375 Sligo Rd. West, PO Box 10
Mount Forest, ON Canada N0G 2L0
General Inquiries:
8:00am - 4:30pm EST
Toll Free: 1-877-966-3738
support@solowavedesign.com
To reduce the risk of serious injury or death, you must read and
follow these instructions. Keep and refer to these instructions often

Table of Contents

Warnings And Safe Play Instructions. . . . . . . . . . . . . . . pg. 2
Protective Surfacing Guidelines. . . . . . . . . . . . . . . . . . . pg. 3
Instructions For Proper Maintenance . . . . . . . . . . . . . . . pg. 4
About Our Wood – Limited Warranty . . . . . . . . . . . . . . pg. 5
Keys To Assembly Success . . . . . . . . . . . . . . . . . . . . . . pg. 6
Metric Conversion Sheets . . . . . . . . . . . . . . . . . . . . . pg. 7,8
Part ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 9
Installation of I.D./Warning Plaque . . . . . . . . . . . .Final Step
Rev 01/03/2013
