- Page 1 DF169 ECO AIR COOLER EVAPORATIVE AIR COOLER IONIZER WITH USER’S MANUAL...
- Page 2 WHAT IS AN ECO AIR COOLER ? The ECO AIR COOLER uses evaporative cooling to pro- vide an airflow that is cooler than the surrounding air. Water from the tank is pumped up and dripped onto the cooling pad inside of the air cooler. As hot ambient air is pulled through this cooling pad, the water in the cooling pad evaporates.
- Page 3 For a short demonstration video of the ECO AIR COOLER, please visit www.floater.ca. Enjoy your ECO AIR COOLER.
-
Page 4: Description Of Components
DESCRIPTION OF COMPONENTS 1. Indicator Panel 7. Water Tank 2. Wind Outlet 8. Water Tank Lock 3. Power Cord 9. Ice Packs 4. Water Level Indicator 10. Remote Control 5. Casters 11. Drain Plug 6. Dust Filter CONTROL PANEL... -
Page 5: Control Panel Operation
CONTROL PANEL OPERATION ON/SPEED BUTTON: On/Speed button is used for starting the unit and changing the wind speed. Wind speed is started from medium speed and changed to low speed 3 seconds later, then you can press the On/Speed button to set the speed you need. Wind speed is divided into HIGH, MEDIUM and LOW by indicator lights. -
Page 6: Mode Button
SWING BUTTON: This function will oscillate the wind louvres automatically from side to side. TIMER BUTTON: Can be set between 0.5 to 7.5 hours easily. Press once for each 0.5 hour incre- ment added to the desired set time. The set time is indicated by the combina- tion of timer indicator lights that are on. -
Page 7: Off Button
B. When set at MEDIUM speed at the beginning, the fan will work at ME- DIUM speed for half an hour, then the fan will switch to LOW speed. The fan will stop at the preset time (if the Timer function is used) or when- ever the power is shut off, otherwise it will stay in LOW speed mode. -
Page 8: Operation Guide
OPERATION GUIDE 1. OPEN THE PACkAGE AND TAkE THE UNIT OUT. Remove foam protection and plastic bag before connecting to power. Figure 1 Figure 2 Figure 3 2. ADDING WATER: Before connecting to power, unlock the Water Tank Lock on the back of the unit and pull the water tank out as far as possible. -
Page 9: Remote Control
4. IF YOU WISH TO ADD THE COOLER/HUMIDIFIER FUNC- TION, PRESS THE COOLER/HUMIDIFIER BUTTON. NOTE: THE ECO AIR COOLER IS EQUIPPED WITH A FLOAT SWITCH. IF THERE IS NOT ENOUGH WATER IN THE WATER TANK, THE UNIT WILL EMIT A WARN- ING SOUND AND THE COOLER/HUMIDIFIER FUNCTION WILL AUTOMATICALLY SHUT OFF. -
Page 10: Dust Filter
8. USING THE ICE PACkS The unit comes with two ice packs to be used for cooling the water in the water tank (see Figure 1). This allows the water in the water tank to stay cooler for lon- ger periods of time so that the evaporative process can work at its optimal. CLEANING DUST FILTER Disconnect power. -
Page 11: Points For Attention
OUTER COVER Clean with gentle detergent and soft cloth. ATTENTION: ANY PART OF THE CONTROL PANEL SHOULD BE KEPT DRY AT ALL TIMES. POINTS FOR ATTENTION • When adding water and ice packs, do not overfill above “MAX” water level. •... -
Page 12: Specifications
Top of Cooling Pad Frame Top of Cooling Pad Frame CORRECT INCORRECT floater imports would like to thank you for your purchase. For other great products from floater and a short demonstration video of the ECO AIR COOLER, please visit www.floater.ca.
