PCAN-PC Card – User Manual
Products taken into account
Product Name
PCAN-PC Card Single Channel
PCAN-PC Card Dual Channel
PCAN-PC Card Single Channel
opto-decoupled
PCAN-PC Card Dual Channel opto-
decoupled
The cover picture shows the product PCAN-PC Card Dual Channel. The Single
Channel versions have an identical form factor but in accordance only have one
breakout cable.
Windows® and MS-DOS are registered trademarks of Microsoft Corporation in the
United States and other countries.
All other product names mentioned herein may be the trademarks or registered
trademarks of their respective companies. Furthermore, "™" and "®" are not
mentioned in each case in this manual.
© 2008 PEAK-System Technik GmbH
PEAK-System Technik GmbH
Otto-Roehm-Strasse 69
D-64293 Darmstadt
Germany
Phone: +49 (0)6151-8173-20
Fax: +49 (0)6151-8173-29
www.peak-system.com
info@peak-system.com
Issued 2008-01-14
Model
One CAN channel
Two CAN channels
One CAN channel, galvanic
isolation for CAN connection
Two CAN channels, galvanic
isolation for CAN connections
2
Item Number
IPEH-002090
IPEH-002091
IPEH-002092
IPEH-002093
