Section 1 - Product Overview
LED
Power A steady green light indicates the unit is powered on. When the device is powered off this remains dark. Lights steady green during
power on self-test (POST). Once the connection status has been settled, the light will light steady green. If the indicator lights
steady red after the POST, the system has failed and the device should be rebooted.
LAN A solid green light indicates a valid link on startup. This light will blink when there is activity currently passing through the Ethernet
port.
WLAN A solid green light indicates a valid link on startup. This light will blink when there is activity currently passing through the Wireless
LAN.
DSL A steady green light indicates a valid ADSL connection. This will light after the ADSL negotiation process has been settled. A
blinking green light indicates activity on the WAN (ADSL) interface.
D-Link DSL-2740R User Manual
Hardware Overview

LEDs

Description
4
