Summary of Contents for EMC 1UP
- Page 1 EMC 1UP Owner’s Manual...
- Page 2 Owner’s Manual EMC 1UP Reference CD Player 24 Bit Upsampler 192kHz DAC Warning: To avoid risk of fire or electric shock, do not expose this appliance to rain or moisture. Verify line voltage before use. Do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personnel.
- Page 3 For optimal sonic performance, the EMC 1UP should be burned in for a mini- mum time of 72 hours. The easiest way to burn in your EMC 1UP is to put a disc in REPEAT mode with the rest of your system turned off. In daily operation, switch off the CD player by using the STANDBY button on the remote.
- Page 4 Set up procedure How to remove and UN secure transport necessities. 1. Remove the two wing bolts and the wing nut located underneath the unit. 2. Unscrew the Allen screws hol- ding the gold sign marked «Mechanical Cancellation Sys- tem» with the smallest Allen key and remove the bracket.
- Page 5 How to avoid noise problems The EMC 1UP contains delicate circuits that are sensitive to magnetic strayfields. The unit should not be place near mains transformers, TVs etc. Care should also be taken regarding placement of the interconnect cables. Do not run interconnect cables in parallel with mains cords and loudspeaker cables.
- Page 6 Connecting the audio components Balanced...
- Page 7 Single ended...
- Page 9 Remote control Single ended STANDBY DISC – No function. SCAN – Play 10 seconds of each track. PROG a. Set the CD player in STOP MODE. b. Select tracks with the numeric buttons (9), or step to the number using buttons no.
-
Page 10: Connecting The Audio Components
The display will go dark. The e- sign on top of the unit will still be lit, indicating Standby mode. When not using the EMC 1UP for a long period, turn the main switch off and disconnect the unit from the mains outlet. - Page 11 Signal to noise 100 dB -100 dB Frequency response (20 - 20 kHz) 0 dB Output S/PDIF Power consumption 23 W The EMC 1UP has DC coupled analog output Dimensions Width 483 mm inch Depth 450 mm 17.7 inch Height 120 mm...
- Page 12 If Service is needed Your dealer will have all relevant information regarding the service centre in your area, and will ensure that your unit is serviced with minimum delay. It is our general policy to have your unit returned to you within five working days. This is an average time, and can vary locally, depending on the workload at that particular service station.
