Meijer HYWN-23 Owner's Manual

Mantel
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Meijer.com
ELECTRIC FIREPLACE MANTEL
OWNERS MANUAL
Model HYWN-23
ONLY use this fireplace mantel and insert as described in this manual. Any other
use is not recommended by the manufacturer, and may cause fire, electric shock, or
other personal injury.
WARNING! Read and understand this entire owner's manual, including all safety
information, before plugging in or using the insert. Failure to do so could result in fire,
electric shock, serious personal injury, or death.
WARNING! INDOOR use only! NEVER use this product outdoors!
SAVE THESE INSTRUCTIONS!
CAUTION! Keep this owner's manual for future reference. If you sell or give this product
away, make sure this manual accompanies this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYWN-23 and is the answer not in the manual?

Questions and answers

Summary of Contents for Meijer HYWN-23

  • Page 1: Save These Instructions

    Meijer.com ELECTRIC FIREPLACE MANTEL OWNERS MANUAL Model HYWN-23 ONLY use this fireplace mantel and insert as described in this manual. Any other use is not recommended by the manufacturer, and may cause fire, electric shock, or other personal injury. WARNING! Read and understand this entire owner’s manual, including all safety information, before plugging in or using the insert.

  • Page 2: Important Safety Information

    Meijer.com IMPORTANT SAFETY INFORMATION! WARNING  ALWAYS keep electric cords, home furnishings, drapes, clothing, papers, or other combustibles at least 3 feet (0.9m) away from the front of this insert, and away from the bottom, sides, and rear of this insert.
  • Page 3 Meijer.com WARNING  Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside!  ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace.  ALWAYS store this insert in a dry location. NEVER use the fireplace if it has become wet.
  • Page 4 Meijer.com PREPARATION A complete electric fireplace consists of two parts; the mantle and the electric fireplace insert. Each is packed in a separate carton. Always use the electric insert with the matching mantle. Remove all parts from the carton and place them on a clean, soft, dry surface. Check the parts list to make sure nothing is missing.
  • Page 5 Meijer.com ASSEMBLY You will need: J x 2 Rear Front STEP 1. Thread wood screw (J) through bottom connector on left side panel (B) and into hole in hearth (A). Secure with Phillips screwdriver. DO NOT over-tighten. Repeat for right side panel (C).
  • Page 6 Meijer.com You will need: J x 4 Rear Front STEP 3. From behind, thread screws (J) through holes in header (F) and into holes in left and right front panels (D/E). Secure with Phillips screwdriver. DO NOT over-tighten. You will need:...
  • Page 7 Meijer.com ANT-TIP SAFETY KIT INSTALLATION Mark the wall H3 H3 Mantel A. Secure one bracket (H2) to an inside rear surface of the mantel with two 5/8” screws (H3). Tighten the screws with a Phillips screwdriver. DO NOT over-tighten. B. Position the mantel in the desired location and mark the wall where the second bracket will be mounted.

  • Page 8: Limited Warranty

    Meijer.com Limited Warranty This warrants to the original purchaser that this product is free from defects in material and workmanship as of the date of purchase and that it will, under normal use and proper care, remain so for one year from the date of purchase. Missing or initially defective parts will be replaced free of charge during the period of this limited warranty.
