Summary of Contents for Vredefort SDP-708MB
- Page 1 SDP-708MB SDP-708MB User Guide www.techtuit.co.jp/dev/dpf/...
-
Page 2: Table Of Contents
SDP-708MB User-Guide CONTE NTS FOLDER Safety Instructions ………………………………………… 21 …………………………… 4 CLOCK ………………………………………………… 4 Warning …………………………………………… 21 ………………………………………………… 5 Cautions Using the MENU key ………………………… 22 Product Features ……………………………… 6 SETUP …………………………………………… 24 Productand Components …………………… 7 …………………………………………… 25 Slide Show Name of each part ……………………………... -
Page 3: Safety Instructions
Safety Instructions Please use the product properly after reading the instructions carefully to ensure the user’s safety and prevent the damage of wealth. Warning ● Do not touch the power plug, the body, the adapter with wet hands - It could be the cause of electric shock. - Do not use it outside or near the water’s edge under the snow or rain. -
Page 4: Cautions
SDP-708MB User-Guide Safety Instructions Cautions ● Do not vent or pull, and suppress with heavy things the power line by constraint. - It could be the cause of electric shock and the fire. ● Put the power plug deeply to the end of inner side and do not use the damaged power plug or a loosed outlet. -
Page 5: Product Features
Product Features Flash memory device Remote control Input/output of the data via Conveniently operates avail- flash memory card able functions. High quality LCD panel Convenient function for life Use LCD panel of which is a Clock, calendar view, alarm video device for next genera- setting function tion (Slim, High resolution) MP3 Player... -
Page 6: Productand Components
SDP-708MB User-Guide Product and Components This product is organized with following items. Please check the contents clearly. Remote control USB Cable Body Adapter Manual... -
Page 7: Name Of Each Part
Name of each part The back of the product It describes the appearance and the name of each part. It maybe has some difference in appearance and function depending on the option. ② Speaker ① Power switch ③ Stand Unit ⑤... -
Page 8: How To Use The Button
SDP-708MB User-Guide Name of each part How to use the button There are 6 buttons in the back side of the product. This describes the name and function of each button as follows. It maybe has some difference in appearance and function depending on the option. -
Page 9: How To Use The Button Of Remote Contro
Name of each part How to use the button of remote control Name Description Turns the product on or off. Used to run various functions and change the previous settings. Stops the previous function (including Slideshow) and moves to the home menu. Starts or stops the slideshow with background music. -
Page 10: Installation And Power Connection
1. Connect the adapter with connection part of the back for the power. Connect the power plug of the adapter with the outlet. Note The adapter can be used in AC 100~240V. 2. Push the power switch. And then LCD screen is on and the Vredefort logo is displayed. -
Page 11: Transmitting Data
Transmitting data 1. Fetching the data stored on PC such as photos, musics, and movies Note In case of connection between PC and the product at first, some time is required (Max 1 or 2 minutes) 2. Fetching the data from the external memory device... -
Page 12: Selecting The Memory Card And Connectingtheusb
SDP-708MB User-Guide Selecting the memory card and connecting the USB ■ Selecting the memory card When you insert a memory card, it will display Select Card the main menu. Memory Stick And the device read flash memory automatically. Internal Flash... -
Page 13: Connecting Pc Through Usb
Selecting the memory card and connecting the USB Connecting PC through USB You can store pictures, moving images, and music files on your PC after connecting through the USB cable. When connecting your PC through USB When sending data from PC to TECHTUIT... -
Page 14: Photo
SDP-708MB User-Guide PHOTO The preview displays available pictures. Select any of them to see in the digital photo frame. ※Parenthesis( ) is the button of the main body. ■ Moving to the PHOTO menu Move to the MENU screen by pressing the button. -
Page 15: Movie
MOVIE Using this menu, you can play back movies such as digital camera movies, music albums, etc. ■ Moving to the MOVIE menu Move to the MENU screen by pressing the ) button. Select the MOVIE button after using the ) buttons. - Page 16 SDP-708MB User-Guide MOVIE ■ Playing back the previous/next movie During playback, you can move to the previous or next movie by pressing the ) button. ■ Stopping the playback Press the button to stop the playback. ■ Pausing the playback Press the ) button to pause the playback.
-
Page 17: Music
MUSIC It plays back the MP3 files. ■ Moving to the MUSIC menu Move to the MENU screen by pressing the ) button. Select the MUSIC button after using the ) buttons. ■ Selecting the desired music file Select the desired music file using the Direction buttons. Time 03:50 Title... - Page 18 SDP-708MB User-Guide MUSIC ■ Stopping the music Press the button during playback. Time 04:08 Title Good bye Artist Jessica Album NOW 5 ■ Pausing the music Info Press the button during playback. ■ Turning off the sound volume Time 04:08...
- Page 19 MUSIC ■ Playing back the previous/next music During playback, you can move to the previous or next music by pressing the ) button. Time 04:08 Time 04:08 Title Good bye Title Never end.. Artist Jessica Artist Limahl Note Album NOW 5 Album Info Info...
-
Page 20: Folder
SDP-708MB User-Guide FOLDER You can play back the files in the desired folder. ■ Moving to the FOLDER menu Move to the MENU screen by pressing the ) button. Select the FOLDER button after using the ) buttons. ■ Checking the file information... -
Page 21: Using The Menu Key
Using the MENU key You can access available functions using the MENU key. Slide Show ■ Slide Show Select Card After pressing the MENU key, select Slide Show. Edit ▶ It works the same as the button. Sort Order ▶ Goto ▶... - Page 22 SDP-708MB User-Guide Using the MENU key Slide Show ■ Sort Order Select Card After pressing the MENU key, select Sort Order. Edit ▶ by Name You can sort the files by Name/Date/Size/Folder or randomly shuffle. Sort Order ▶ by Date...
-
Page 23: Setup
SETUP It can configure multiple environmental settings. ■ Moving to the SETUP menu Move to the MENU screen by pressing the ) button. Select the SETUP button after pressing the ) buttons. SETUP Slide Show Time Alarm Auto Power Management Audio System Configuration SETUP... -
Page 24: Slide Show
SDP-708MB User-Guide SETUP Slide Show ■ Slide Show Interval Slide Show You can set the interval for slide show. (1 sec to 10 minute) Slide Show Interval 5 minutes Auto Slide Show 10 minutes Select transition effect Interlace ■ Auto Slide Show... -
Page 25: Time
SETUP Time ■ Date Setting Time It sets the date : Year-Month-Day. Date Setting 2007-05-22 Time Setting PM 02:33:12 ■ Time Setting It sets the current time. Alarm ■ Set Alarm ■ Set Period Alarm It determines whether or not to use It sets the alarm interval. -
Page 26: Auto Power Management
SDP-708MB User-Guide SETUP Auto Power Management ■ Set Auto Power On ■ Set Auto Power Off Auto Power Management It automatically turns the power On. It automatically turns the power Off. Set Auto Power On Auto Power On Time PM 02:33:12... -
Page 27: System Configuration
SETUP System Configuration ■ Language System Configuration It sets the language to be displayed on the screen. Language English Info. Bar Show Hide (It supports Hangul Korean, English, Chinese, Spanish, German and Japanese basically. Auto Fill Image The other language is option fact.) ■... -
Page 28: System Information
SDP-708MB User-Guide SETUP System Information ■ Checking the system information System Information You can see the versions for firmware and hardware. (c) 2007, SR I-Tech, All rights reserved HW Version 708MB The memory capacity and free memory space are also displayed. -
Page 29: Troubleshooting
Troubleshooting Problem Solution Power remains turned off. - Check the plug-insertion hole of the adapter, adapter itself, and connection status between adapter and outlet. - Check the type of memory card. - This product supports 5 kinds of memory cards such as SD/MMC/xD/MS/CF. Power is on but the initial - Check the file name extension when the connection between memory card and power is normal. -
Page 30: Specifications
SDP-708MB User-Guide Specifications Model SDP-708MB Size / Resolution 7” / 800 * 480 Display Brightness 350cd/m+ Contrast 300cl / R-400 : 1 Built-in memory 128MByte Memory Storage device slot SD / MMC / xD / MS / CF Photo-View : Image files... -
Page 31: The Warranty
The warranty Model SDP-708MB Serial No. Purchasing date Seller ■ Service related ● TECHTUIT Ltd has the guarantee as follows in accordance with compensation rules for the customer’s damage per item (the Finance and Economy Ministry Notice No. 2000-12). ● TECHTUIT Ltd or the service will be served from the specified dealer or on the site where you purchased. - Page 32 www.techtuit.co.jp/dev/dpf/...
