Summary of Contents for Handlink Technologies WG-604

  • Page 1 WG-604/WG-604P Easy HotSpot Kit User’s Manual Handlink Technologies Inc.
  • Page 2 Copyright Notice Copyright © 2005-2015 Handlink Technologies Inc. All rights reserved. No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission. Protected by TW patent 223184, JPN patent 3099924 and China patent ZL 03 2 04640.5.

  • Page 3: Table Of Contents

    Table of Contents Introduction ----------------------------------------------------------------------------------------------------------------- 5 1-1 Package Contents -------------------------------------------------------------------------------------------------------- 5 1-2 Features --------------------------------------------------------------------------------------------------------------------- 6 1-3 Precautions ----------------------------------------------------------------------------------------------------------------- 6 1-4 Outlook----------------------------------------------------------------------------------------------------------------------- 6 1-4-1 Top Panel --------------------------------------------------------------------------------------------------------- 7 1-4-2 Rear Panel-------------------------------------------------------------------------------------------------------- 7 1-5 Technical Specifications ------------------------------------------------------------------------------------------------ 8 1-5-1 Hardware Specifications -------------------------------------------------------------------------------------- 8 1-5-2 Software Specifications --------------------------------------------------------------------------------------10 Installation -----------------------------------------------------------------------------------------------------------------12...
  • Page 4 3-2-3-5 SNMP ---------------------------------------------------------------------------------------------- 87 3-2-4 SECURITY ------------------------------------------------------------------------------------------------------88 3-2-4-1 Pass Through ------------------------------------------------------------------------------------ 88 3-2-4-2 Filtering -------------------------------------------------------------------------------------------- 90 3-2-4-3 Share ----------------------------------------------------------------------------------------------- 92 3-2-4-4 Secure Remote ---------------------------------------------------------------------------------- 94 3-2-5 SYSTEM ---------------------------------------------------------------------------------------------------------95 3-2-4-1 System --------------------------------------------------------------------------------------------- 95 3-2-4-2 WAN/LAN ----------------------------------------------------------------------------------------- 98 3-2-4-3 Server -------------------------------------------------------------------------------------------- 105 3-2-4-4 Keypad ------------------------------------------------------------------------------------------- 108 3-2-4-5...
  • Page 5 3-4-3 Boot Code ----------------------------------------------------------------------------------------------------- 162 3-4-4 System Account ---------------------------------------------------------------------------------------------- 162 3-4-5 SSL Certificate------------------------------------------------------------------------------------------------ 167 3-4-6 Pin Command------------------------------------------------------------------------------------------------- 168 3-4-7 Restart ---------------------------------------------------------------------------------------------------------- 169 3-4-8 Logout ---------------------------------------------------------------------------------------------------------- 169 Appendix A Signal Connection Arrangements ------------------------------------------------------------------------ 170 Appendix B Regulations/EMI Compliance ----------------------------------------------------------------------------- 171 LIMITED WARRANTY------------------------------------------------------------------------------------------------------- 172 Easy Hotspot Kit...

  • Page 6: Introduction

    (HTTP Proxy) or load any special software to access hotspot service. It’s completely Plug’ Play with any browser. 1-1 Package Contents Please inspect your package. The following items should be included: ◎ WG-604 One Wireless Subscriber Gateway Three antennas One AC Power Adapter for Wireless Subscriber Gateway One CD containing User’s Manual and MIB file...

  • Page 7: Features

    1-2 Features Wireless data rates up to 54Mbps Supports 100 Simultaneous Users IP Plug and Play (iPnP) Comprehensive security 64/128-bit WEP encryption WPA encryption WPA2 Encryption IP/URL filtering Intelligent Management Built-in AAA (Authentication/Accounting/Authorization) and Billing mechanism Note: The "PnP" Function only can be used with TCP/IP-based Network. 1-3 Precautions Never remove or open the cover.

  • Page 8: Top Panel

    1-4-1 Top Panel The top panel of the Wireless Subscriber Gateway is shown below. Figure 2 Wireless Subscriber Gateway Top Panel LEDs Indication State Description The Wireless Subscriber Gateway is not receiving electrical power. Green The Wireless Subscriber Gateway is receiving electrical power. The Wireless Subscriber Gateway status is defective.

  • Page 9: Technical Specifications

    1. LAN (1-4): The rear panel supports four auto-sensing RJ-45 ports and all ports can be auto-switched to MDI-II connections. The LAN ports used for linking hosts or other network devices. The individual port can be either connected to 100BaseTX networks or 10BaseT networks. When connecting to a 100BaseTX network, the ports operate at 100Mbps in half-duplex mode or 200Mbps in full-duplex mode.
  • Page 10 LED Indicators One POWER LED One WAN 10/100M Link/Activity LED Four LAN 10M/100M Link/Activity LEDs One Wireless Link/Activity LED One System LED Power Requirement External Power Adapter Input: 100-240 VAC, 50/60 Hz Output: 12V, 1.5A Environment Conditions Operating Temperature: 0 to 50°C Storage Temperature: -10 to 60°C Operating Humidity: 10~80% non-condensing Storage Humidity: 10% to 90% non-condensing...

  • Page 11: Software Specifications

    1-5-2 Software Specifications Networking • IEEE802.3 10BaseT Ethernet • IEEE802.3u 100BaseTX Fast Ethernet • IEEE802.11b Wireless LAN • IEEE802.11g Wireless LAN • IEEE802.11n Wireless LAN • Supports update to 200 Simultaneous Users • IP Plug and Play (iPnP) • HTTP Proxy Support •...
  • Page 12 Security and Firewall • Layer 2 Isolation Security • SSL User Login page/ Configuration Page • SSL Administration • VPN Pass through (IPSec/PPTP) • Customize SSL Certificate • Pass Through IP/MAC/URL Address • Restricted Destination Filtering IP/URL • VPN (IPSec/PPTP) Pass through •...

  • Page 13: Installation

    Installation The followings are instructions for setting up the Wireless Subscriber Gateway. Refer to the illustration and follow the simple steps below to quickly install your Wireless Subscriber Gateway. Wall-Mounting The Wireless Subscriber Gateway can be wall-mounted on a wall by applying the two mounting brackets on screws.

  • Page 14: Connecting The Antennas

    2-1 Connecting the Antennas The Wireless Subscriber Gateway provides two antenna connectors on the rear of the unit. Figure 6 Antenna Connectors 2-2 Installation Requirements Before installing the Wireless Subscriber Gateway, make sure your network meets the following requirements. System Requirements The Wireless Subscriber Gateway requires one of the following types of software: Windows 98 Second Edition/NT/2000/XP/Vista Red Hat Linux 7.3 or later version...
  • Page 15 ISP Requirements Verify whether your ISP use fixed or dynamic IP. If it is a fixed IP, be sure to get the IP from your ISP. For dynamic IP, which is mostly used, the PC will get the IP automatically whenever it hooks up on the modem.

  • Page 16: Getting Start

    2-3 Getting Start 1. Place the Wireless Subscriber Gateway and AG-300E Printer on a flat work surface. 2. Connect the Ethernet cable to the Wireless Subscriber Gateway’s LAN port. 3. Connect the other end of the Ethernet cable to the AG-300E Account Generator Printer’s RJ45 port. 4.

  • Page 17: Configuring The Wireless Subscriber Gateway

    3 Configuring the Wireless Subscriber Gateway 3-1 Setting Wizard Step 1: Start your browser, and then enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter. Figure 8 Web Browser Location Field (Factory Default) Step 2: The Wireless Subscriber Gateway configuration tools menu will appear. In the Username and Password field, type the factory default user name admin and password admin and click Login.
  • Page 18 Figure 11 System Quick View Click on reset button to clear the username and password data. Note: This Web agent is best viewed with IE 5.0 or Netscape 6.0 and above browsers. If you would like to change the password please see Step 10. Username and Password can consist of up to 20 alphanumeric characters and are case sensitive.
  • Page 19 Step 3: Internet Connection Setting Select the appropriate Internet connection type to connect to your ISP. Figure 12 Internet Connection Setting Screen DHCP Client The device can work as a DHCP client. This allows the device to obtain the IP address and other TCP/IP settings from your ISP.
  • Page 20 Static IP Setting If Static IP Setting is selected, then this screen will appear. Enter the IP address information provided by your ISP. Figure 14 Internet Connection Setting Screen—Static IP Setting Item Default Description IP Address 0.0.0.0 Enter the IP address provided by your ISP. Subnet Mask 0.0.0.0 Enter the subnet mask for the IP address.
  • Page 21 PPPoE (Point-to-Point Protocol over Ethernet) If “PPPoE” is selected, then this screen will appear. Enter the username, password and other major fields. Figure 15 Internet Connection Setting Screen—PPPoE Setting Item Default Description Enter the user name provided by your ISP. The user name can consist Username Empty of up to 80 alphanumeric characters and is case sensitive.
  • Page 22 Item Default Description Connect on Demand and Max Idle Time Connect on You can configure your Wireless Subscriber Gateway to cut your Enable Demand connection with your ISP after a specified period of time (Max Idle Time). If you have been disconnected due to inactivity, Connect on Demand enables your Wireless Subscriber Gateway to automatically re-establish your connection as soon as you attempt to access the Internet again.
  • Page 23 PPTP Client (Point-to-Point Tunneling Protocol) If “PPTP” is selected, then this screen will appear. Fill out all the information provided by your ISP. Figure 16 Internet Connection Setting Screen—PPTP Client Setting Item Default Description My IP Address Empty Enter the PPTP local IP address provided by your ISP. Enter the PPTP local Subnet Mask IP address for the IP My Subnet Mask Empty...
  • Page 24 Item Default Description Enter the PPTP server Gateway IP address provided by your Gateway IP Address Empty ISP. PPTP Server IP Address Empty Enter the PPTP server IP address provided by your ISP. Enter the user name provided by your ISP. The user name Username Empty can consist of up to 80 alphanumeric characters and is case...
  • Page 25 Step 4: Wireless Setting This page allows you to define ESSID, Channel ID and WEP/WPA encryption for wireless connection. Figure 17 Wireless Setting Screen Item Default Description Wireless Connection Enable Enable or Disable Wireless connection ESSID Wireless The ESSID is the unique name that is shared among all points in a wireless network.
  • Page 26 Step 5: E-mail Server Setting Wireless Subscriber Gateway allows an extra Email server parameter to forward the subscriber’s E-mail. Figure 18 E-mail Service Setting Screen Item Default Description Email Server Redirect Disables or enables email server redirect function. To prevent some subscriber’s original Email server may protect by firewall or NAT network.
  • Page 27 Step 6: Authentication Service Setting Figure 19 Authentication Service Setting Screen Item Default Description Yes― Built-in Authentication/ No Authentication No Authentication) Wireless Subscriber Gateway provides Built-in Authentication for service provider to build up an Internet service without any extra authentication software.
  • Page 28 Step 7: Billing Profile Setting The function is used to setup a billing profile. A billing profile is a description of how you want to charge your customer. Figure 20 Billing Profile Setting Screen Item Default Description Time to Finish Options: Time to Finish or Accumulation. Service Time to Finish―...
  • Page 29 Item Default Description Currency Enter the appropriate currency unit or currency symbol. Number of Enter the billing decimal value. The field maximum value is 3. decimals places The index number of billing profile. In Wizard setup, we provide only 01~03 3 billing profile.
  • Page 30 Button B Button Button C Figure 22 Account Generator Printer Step 9: Accounting Setting Three-buttons Printer Setting Figure 23 Accounting Setting Screen (Three Button Printer) Easy Hotspot Kit...
  • Page 31 Figure 24 Billing Profile Setting Screen Item Default Description Define each button’s billing profile. Select Button A~ C one billing profile by clicking in the list box. Printout The system allows you to print all your bills. Number of copies to print This value is number of copies.
  • Page 32 Web-based Account Generator Setting Figure 25 Web-based Account Generator Setting Screen Item Default Description Billing Profile (Button Define each button’s billing profile. Select one billing profile by clicking A~C) in the list box. Printout Number of copies to The system allows you to print all your bills. Select one print number of copies by clicking in the list box.
  • Page 33 Click on button to preview and operate account generator panel. Button Button B Button C Figure 26 Account Generator Panel Click on button to create a new account. Easy Hotspot Kit...
  • Page 34 Click “View Account List” to display current account information. Figure 27 Account List Click on refresh button to update the account list page The field name button in this list show that this list can be sorted in ascending/descending order according to the corresponding field name.
  • Page 35 Customize Printout Text This function allows you to produce custom bill based on your requirements. Figure 28 Customize Printout Text Setting Screen Click the button to displays the account on the screen as it would appear when printed. Easy Hotspot Kit...
  • Page 36 Figure 29 Example- PC-connected printer Printout (Time to Finish) Figure 30 Example- PC-connected printer Printout (Accumulation) Easy Hotspot Kit...
  • Page 37 Figure 31 Example- Account Generator Printer Printout (Time to Finish) Figure 32 Example- Account Generator Printer Printout (Accumulation) Easy Hotspot Kit...
  • Page 38 Figure 33 Example-Post-paid Printout Easy Hotspot Kit...
  • Page 39 Step 10: System Setting Figure 34 System Setting Screen Item Default Description Username admin Enter the user name. The user name can consist of up to 80alphanumeric characters and is case sensitive. Password admin Enter the user password. The password can consist of up to 80 alphanumeric characters and is case sensitive.

  • Page 40: Advanced Setup

    3-2 Advanced Setup The Advanced Setting enables you to configure advanced settings related to accessing the Internet, including, AUTHENTICATION AUTHENTICATION RADIUS BILLING BILLING ACCOUNTING CREADIT CARD MANAGEMENT LAN DEVICES SYSLOG SESSION TRACE BANDWIDTH SNMP SECURITY PASS THROUGHT FILTERING SHARE SECURE REMOTE SYSTEM SYSTEM WAN/LAN...

  • Page 41: Authentication

    AUTHENTICATION 3-2-1 3-2-2-1 Authentication Figure 36 Authentication Setting Screen Item Default Description Option: No Authentication, Built-in Authentication or User Authentication Type Agreement. Authentication No Authentication― Subscriber can direct access the Internet without enter username and password. Built-in Authentication― Wireless Subscriber Gateway provides “Built-in...
  • Page 42 Item Default Description Current User 1 Min(s) The system provides automatically backup account Information Backup information and unused account to flash ROM. This function allow administrator to adjust the backup time. The default value is 1 minute. The Current User Information Backup valid range is 1 to 1440.
  • Page 43 Copy and paste the following HTML Code into your home page to produce user agreement login page. Figure 37 Preview Redirect Login Page Code Item Default Description SSL Login Page Disable Enables or disables SSL security of login page. User Idle Time Out 5 Minutes The user idle time out valid range is 1-1440.

  • Page 44: Radius

    3-2-2-2 RADIUS Figure 38 Authentication Setting Screen Easy Hotspot Kit...
  • Page 45 Item Default Description RADIUS Authentication Disable Option: No Authentication or RADIUS Server. Disable (No Authentication) ― Subscriber can direct access the Internet without enter username and password. Enable (RADIUS Authentication) ― Wireless Subscriber Gateway provides “RADIUS Authentication” for service provider to build up an Internet service with RADIUS server.
  • Page 46 Item Default Description Retry Frequency ~ The field default value is 3 seconds. Seconds Accounting Service Disable Enables or disables the accounting service. Interim Update Time 5 Minutes Specify the interim update time. Authentication Method CHAP Enter the authentication method of RADIUS server. WISPr Smart Client Enable Disable...

  • Page 47: Billing

    BILLING 3-2-2 3-2-2-1 Billing The function is used to setup a billing profile. A billing profile is a description of how you want to charge your customer. Figure 39 Billing Setting Screen Easy Hotspot Kit...
  • Page 48 If you change billing mode (Pre-paid Post-paid or Post-paid Pre-paid), the system will erase all account and disconnect all on-line users. Figure 40 Message Box Item Default Description Enable Credit Card Service Disable Enables or disables the credit card service. Before you enable credit card service, make sure that your credit service is configured to work and the currency is American dollars.
  • Page 49 Figure 41 Credit Service Setting Screen Easy Hotspot Kit...
  • Page 50 Figure 42 Error Dialog Box (Credit Card Service=Enable) Item Default Description Time to Finish Enable The subscriber can access Internet only one time with one account. Once subscriber login, the pre-defined usage time will start until run out even the subscriber stop to access the Internet before run out. Accumulation Accumulation Disable...
  • Page 51 Item Default Description Post-Paid Disable The subscribers can access Internet without pre-defined usage time. This can be operated with an optional external PS/2 keypad that is connected with exclusive printer. The printout will only show the username/password. An account can also to be terminated with the optional keypad.
  • Page 52 Figure 45 Post-paid Procedure Diagram Click Apply button to save the new settings. Figure 46 Success Dialog Box Easy Hotspot Kit...

  • Page 53: Accounting

    3-2-2-2 Accounting This function allow service provider to generate the subscriber accounts. Figure 47 Accounting Setting Screen Easy Hotspot Kit...
  • Page 54 Figure 48 Item Default Description Expiration Un-used account will be 24 hours Enter the number of hours/minutes/days. The field maximum deleted after ~hours value is 30 hours/minutes/days. automatically Accumulation account 3 months Enter the number and select time unit from list box. The field will be deleted after maximum value is 30 month/ days/ hours.
  • Page 55 Figure 49 Account Process DiagramCan be replenished by subscriber=Enable Three-Button Printer/ Web-based Account Generator Panel Figure 50 Three-Button Printer/ Web-based Account Generator Panel Setting Screen Item Default Description Button A~C Define each button’s billing profile. Select one billing profile by clicking in the list box. Print to…...
  • Page 56 Item Default Description Use ~ for Discount Button A, Select one button (A~C) by clicking in the list box to Price Plan based on Disable assign the base charge and select enable to active the “Button Presses” discount price plan. Click on button to preview and operate account generator panel.
  • Page 57 Figure 53 PC-connected Printer Printout (Time to Finish) Easy Hotspot Kit...
  • Page 58 Figure 54 Web-based Account Generator Printout (Accumulation) Easy Hotspot Kit...
  • Page 59 Figure 55 PC-connected Printer Printout (Accumulation) Note: Before configuring the accounting, you have to setting the billing profile of Web-based account generator panel. Easy Hotspot Kit...
  • Page 60 Example: If press 7 times Discount Price Plan based on “Button Presses” is disabled. Figure 56 Example 1 Amount: 7 x $2.00= $14.00 Figure 57 Account Printout Easy Hotspot Kit...
  • Page 61 Discount Price Plan based on “Button Presses” is enabled. The Charge by level is disabled. Figure 58 Example 2 Amount: 7 x $ 1 = $ 7.00 Easy Hotspot Kit...
  • Page 62 Below is an example of the account printout. Figure 59 Account Printout Easy Hotspot Kit...
  • Page 63 Discount Price Plan based on “Button Presses” is enabled. Charge by level is enabled. Figure 60 Example 3 Amount: 2 x $2.00 + 4 x$ 1.50+1x$1= $11.00 Easy Hotspot Kit...
  • Page 64 Below is an example of the account printout. Figure 61 Account Printout Easy Hotspot Kit...
  • Page 65 Discount Price Plan based on “Button Presses” Figure 62 Discount Price Plan Setting Screen Item Default Description Charge by levels Enable Enables or disables the charge by levels function. Level 1~10 This field displays the level number of charge rate. Conditions When>= The discount condition.

  • Page 66: Credit Card

    3-2-2-3 Credit Card Wireless Subscriber Gateway provides three credit card services (Authorize.net, iValidate.net, Secure Pay and Paypal) that allow service provider to authorize, process, and manage credit transactions directly from Internet. Figure 64 Credit Card Setting Screen Easy Hotspot Kit...
  • Page 67 Item Default Description Authorize.net Version This field displays the merchant version. Merchant ID Empty Enter your Merchant ID. This is a Merchant Identification Number that you’re received from your Merchant Provider. The maximum character of the Merchant ID is 50. Merchant Password This is a Merchant password that you’re received from your Merchant Provider.
  • Page 68 Item Default Description Secure Server Address https://www. Enter the secure server address. vious.net/m erchant/proc esscc.asp Secure Pay Merchant ID Empty Enter your Merchant ID. This is a Merchant Identification Number that you’re received from your Merchant Provider. The maximum character of the Merchant ID is 7. Secure Pay Address https://www.
  • Page 69 Item Default Description The currently support currencies are as follows: GBP (Pounds Sterling), World Pay Japanese Yen, AUD (Australian dollar), CAD (Canadian Dollar), Eur (Euro), New Zealand Dollar, Indian Rupee, Singapore dollar and USD (US Dollar). Enter the payment gateway address. The default value is Payment Gateway “select.worldpay.com/wcc/purchase”.
  • Page 70 Click Click Figure 66 Login Page Easy Hotspot Kit...
  • Page 71 2: Select Service and enter payment information. Currency: American Dollars Figure 67 Service & Payment Information Setting Screen (Authorize.net) Item Default Description Payment Information Credit card number Empty Enter your credit card number. Credit card expiration date Empty Enter the credit card expiration date. The allowed format is MMYY.
  • Page 72 Figure 68 Service & Payment Information Setting Screen (iValidate.net) Item Default Description Payment Information Credit card number Empty Enter your credit card number. Credit card expiration date Empty Enter the credit card expiration date. The allowed format is MMYY. Enter Email Address Empty Enter your email address.
  • Page 73 Figure 69 Service & Payment Information Setting Screen (Secure Pay) Item Default Description Payment Information Credit card number Empty Enter your credit card number. Credit card expiration date Empty Enter the credit card expiration date. The allowed format is MMYY. Enter Email Address Empty Enter your email address.
  • Page 74 Figure 70 Service & Payment Information Setting Screen (Paypal and WorldPay) Easy Hotspot Kit...
  • Page 75 Step 3: After valid payment information has been provided, the subscriber will obtain one valid account to login screen will appear. Figure 71 User Account Information Figure 72 Easy Hotspot Kit...

  • Page 76: Management

    MANAGEMENT 3-2-3 3-2-3-1 LAN Devices Administrator can direct remote control to LAN Devices via the Wireless Subscriber Gateway implemented the feature. Figure 73 LAN Devices Setting Screen Easy Hotspot Kit...
  • Page 77 Item Default Description Polling Interval 5 Min. The default value is 5 minutes. The Polling Interval valid range is 1 to 1440. Device Name Empty The LAN device name. The maximum character of the device name is 20. Virtual Port The virtual port number valid range is 60001 to 60050 or 5900 to 5910.

  • Page 78: Syslog

    3-2-3-2 Syslog The function allows the device to transmit event messages to your syslog server or your email address for monitoring and troubleshooting. Syslog Setting Figure 74 Syslog Setting Screen Item Default Description Syslog Disable Enables or disables the syslog server function. Syslog on LAN Server IP Address Empty...
  • Page 79 Item Default Description Syslog on WAN Empty Enter IP address of first syslog server. Server 1 IP Address Empty Enter IP address of second syslog server. Server 2 IP Address Send to Email Disable Enables or disables the send to e-mail function. E-mail Server IP Address or Domain Empty...
  • Page 80 Log Categories Figure 76 Log Settings Screen Easy Hotspot Kit...
  • Page 81 Item Interval Time Description System Device Information 5~60 minutes The log included system information would be sent according to specified interval time. Format： PRODUCT=WG-604;VER=2.00.00;LOGNAME=DVI; DATE=07Mar26;TIME=11:30:00; WANMAC=09-00-0e-00-00-01;LANMAC=09-00-0e-00-00-02; WLANMAC=09-00-0e-00-00-03; IP_ADDRESS=210.66.37.21; SYS_UP_TIME=14D23H34M21S;WANTXOK=99999; WANRXOK=99999;WANTXERROR=99999;WANRXERROR=99999; LANTXOK=99999;LANRXOK=99999;LANTXERROR=99999; LANRXERROR=99999;WIRELESSTXOK=99999;WIRELESSRXOK=99999; WIRELESSTXERROR=99999;WIRELESSRXERROR=99999; WAN_QUALITY=5; System Up Notice When system If device have been rebooted or restarted, the log would rebooted or restarted be sent.

  • Page 82: Wireless Association

    Interval Time Description Wireless Association 5~60 minutes. A log including wireless users information will be sent Information according to specified interval time. Format: PRODUCT=WG-604;VER=2.00.00;LOGNAME=WAI; DATE=07Mar26;TIME=15:23:32; WANMAC=09-00-0e-00-00-01;LANMAC=09-00-0e-00-00-02; WLANMAC=09-00-0e-00-00-03; IP_ADDRESS=210.66.37.21; USER_NUM=15;SEQ=1-5;USER_MAC=02-34-3e-01-00; User User Login A log including users information will be sent when user When user logged-in logged –in...

  • Page 83: Lan Devices

    Currency = AUD | CHF | EUR | GBP | JPY | RIY | USD Billing Amount When received A log will be sent when received amount Format: amount PRODUCT=WG-604;VER=2.00.00;LOGNAME=BLA; DATE=07Mar26; TIME=15:23:32;WANMAC=09-00-0e-00-00-01; LANMAC=09-00-0e-00-00-02; WLANMAC=09-00-0e-00-00-03; IP_ADDRESS=210.66.37.21;USER_NAME=username; BILL_TYPE=Cash, BILL_AMOUNT= USD50.00 Billing Type= Cash | Credit_Card； Billing Amount = xx.xx Currency = AUD | CHF | EUR | GBP | JPY | RIY | USD……...
  • Page 84 Click Apply button to save the new settings. Click Apply button, the success dialog box appears. Click on Back to return to Logs setting screen. Figure 77 Success Dialog Box Easy Hotspot Kit...

  • Page 85: Session Trace

    3-2-3-3 Session Trace Session Trace is an intelligent function to help service provider to trace every user’s access behavior. When “session trace” is enable , the system will collect information such like destination IP, destination port, source IP, source MAC, source port by every user and send the collected information in text format file to specified TFTP server or Email Server.
  • Page 86 Item Default Description Send to Email Disable Enables or disables the send to e-mail function. E-mail Server IP Address or Domain Empty Enter the SMTP server IP address or domain name. The Name maximum allowed characters length is 50. SMTP Port Empty The SMTP port allowed range is 25 or 2500 to 2599.

  • Page 87: Bandwidth

    3-2-3-4 Bandwidth The function enables administrator to limit bandwidth usage on a per user basis (MAC address). That prevents users from consuming a disproportionately large amount of bandwidth so every user gets a fair share of the available bandwidth. Figure 79 Bandwidth Setting Screen Item Default Description...

  • Page 88: Snmp

    3-2-3-5 SNMP The SNMP Agent Configuration screen enables you to access to your device via Simple Network Management Protocol. If you are not familiar with SNMP, please consult your Network Administrator or consult SNMP reference material. You must first enable SNMP on the SNMP Agent Configuration screen.

  • Page 89: Security

    Item Default Description Privileges Read/Write Choose “Read”, “Write”, “Trap Recipients” and “All” for different privileges. The default setting of the entry 2 is “write” and others are “read”. Status Valid/Invalid Chosen “Valid” or “Invalid”. The default setting of entry 1, 2 are valid and others are invalid.
  • Page 90 Item Default Description Pass Through Disable Enables or disables the pass through function. Destination URL/IP Address Pass Through URL or Website Empty Enter the URL Page; please use this format such like “http://www.yahoo.com”. The maximum character of the URL Page is 50.

  • Page 91: Filtering

    3-2-4-2 Filtering Filtering allows the system administrator to have a list of restricted destinations, which is useful to block specified Internet websites or Intranet areas. Figure 82 Filtering Setting Screen Item Default Description Filtering Disable Enables or disables filtering function. HTTP Message The Web Site Enter the http message.
  • Page 92 Item Default Description Restrict Destination URL or Website Empty Enter the URL Page of you wants to filter; please use this format such like “http://www.yahoo.com”. The maximum character of the URL Page is 50. Start IP Address Empty Enter the start IP address of you wants to filter. End IP Address Empty Enter the end IP address of you wants to filter.

  • Page 93: Share

    3-2-4-3 Share This feature allows sharing the network devices after subscriber successful login. Figure 84 Share Device Setting Screen Item Default Description Share LAN resource Disable Enables or disables share LAN resource function. Resource Name Empty Enter the device name. The maximum character of the resource name is 30.
  • Page 94 Click Computers or People. Click “A computer on the network”. In Computer, type the IP address of the device you want to find. Click Search. 2. The function support only Unicast and IP Protocol. Click Add to List button to add a new entry. Click Apply button to save the new settings.

  • Page 95: Secure Remote

    3-2-4-4 Secure Remote This feature allows you to create a secure connection to a remote site or back end system with VPN PPTP Client. If “Secure Remote” is enabled, the RADIUS packet/ syslog will be transferred to this secure connection. Figure 85 Secure Remote Setting Screen Item Default...

  • Page 96: System

    SYSTEM 3-2-5 3-2-4-1 System Define the Wireless Subscriber Gateway System configuration. Figure 86 System Setting Screen Easy Hotspot Kit...
  • Page 97 Figure 87 System Setting Screen Item Default Description The system name can consist of up to 40 System/Host Name Empty alphanumeric characters. The Domain name can consist of up to 80 Domain Name Empty alphanumeric characters. Location Information Empty Enter your location information. Date/Time System The system date of the Wireless Subscriber Gateway.
  • Page 98 Item Default Description Enables or disables NTP (Network Time Protocol) Time Server. Network Time Protocol can be utilized to NTP Setting Disable synchronize the time on devices across a network. A NTP Time Server is utilized to obtain the correct time from a time source and adjust the local time.

  • Page 99: Wan/Lan

    Item Default Description Option: default or customize certificate, These are two ways to create a certificate, one is purchase a SSL Certificate Default certificate from a certificate authority (Ex. Verisign or Thawte), and another is creating a self-certificate (For example: Uses OpenSSL tool). Click Apply button to save the new settings.
  • Page 100 Figure 90 Restart Dialog Box Device IP (LAN IP) Setting Figure 91 Device IP (LAN IP) Setting Item Default Description IP Address 10.59.1.1 The internal LAN IP address of your Wireless Subscriber Server Gateway. Subnet Mask 255.0.0.0 Enter the subnet mask for the IP address. WAN MAC Address Figure 92 WAN MAC Address Setting Item...
  • Page 101 DHCP Client The device can work as a DHCP client. This allows the device to obtain the IP address and other TCP/IP settings from your ISP. If your xDSL/Cable comes with this feature, please enable Use DHCP Client. Figure 94 DHCP Client Setting Screen Static IP Figure 95 Static IP Setting Screen Item...
  • Page 102 PPPoE Figure 96 PPPoE Setting Screen Item Default Description User Name Empty Enter your PPPoE account name. The user name can consist of up to 80 alphanumeric characters and is case sensitive. Password Empty Enter your PPPoE password. The password can consist of up to 80 alphanumeric characters and is case sensitive.
  • Page 103 Item Default Description Service Name Empty Enter the service name provided by your ISP. The service name can consist of up to 64 alphanumeric characters and is case sensitive. Connect on Demand and Max Idle Time Connect on Demand Enable You can configure your Wireless Subscriber Gateway to cut your connection with your ISP after a specified period of time Max Idle Time...
  • Page 104 PPTP Figure 97 PPTP Setting Screen Item Default Description My IP Address Empty A PPTP local IP address for the xDSL/Cable connection (provided by your ISP). My Subnet Mask Empty Enter the PPTP local IP address for the xDSL/Cable connection. Gateway IP Address Empty A PPTP local default gateway for the xDSL/Cable...
  • Page 105 Item Default Description Password Empty Enter your PPTP password. The password can consist of up to 80 alphanumeric characters and is case sensitive. PPP MTU Setting 1460 MTU (Maximum Transfer Unit) specifies maximum transmission unit size. TCP MSS Setting 1400 MSS (Maximum Segment Size) specifies maximum segment size.

  • Page 106: Server

    3-2-4-3 Server Figure 98 Server Setting Screen Item Default Description Web Server Enter the HTTP port number. The HTTP port allowed range is 80 or 8010 to 8060. For access the Wireless HTTP Port Subscriber Gateway system under NAT, please tab the “http://HTTP Port IP Address: Port Number”.
  • Page 107 Item Default Description There are three types of DHCP Services. DHCP Disable—Disable the DHCP server function. DHCP Server Enable DHCP Relay—Enable DHCP Relay function. DHCP Server—Enable DHCP server function. To route DHCP through an external server, the administrator needs to DHCP Relay enable the DHCP relay and assign a valid DHCP server IP address.
  • Page 108 Static DHCP This function allows subscriber to assign IP address on the LAN to specific individual computers based on their MAC Address. Figure 99 Server Setting Screen Item Default Description Enter the IP address that subscriber want to assign to the IP Address Empty computer on LAN with the MAC address the subscriber will...

  • Page 109: Keypad

    3-2-4-4 Keypad Figure 100 Keypad Setting Screen Easy Hotspot Kit...
  • Page 110 Item Default Description Use for Pre-Paid Billing The system provides ten user definable hot keys through the use of the + Key plus the 1 through 0 keys across the top of the keypad. Keypad Hot Key +1~+0 It is the combination hot key for keypad application. Billing Profile Select the billing profile you want to assign to the combination hot key.
  • Page 111 Step 2: Click the Keypad in Advanced Setup Menu, define the Billing plan of pre-paid, and click Apply. Figure 102 Keypad’s Hot Key Setting Screen Step 3: You can use keypad to create subscriber accounts now. Press keypad hot key and then press Enter.
  • Page 112 Step 4: Subscriber can use this account to access Internet now. Use for Post-Paid Billing Step 1: Click the Billing in the Advanced Setup menu, select enable Post-paid, click Apply. Figure 104 Billing Setting Screen Step 2: Click the Keypad in Advanced Setup Menu, Define the billing plan of post-paid, click Apply. Figure 105 Keypad’s Hot Key Setting Screen Easy Hotspot Kit...
  • Page 113 Enter, a new subscriber Step 3: You can use keypad to create subscriber accounts now. Press account is generated, and the account information should be printed. This account information is including serial number, username, password and account create time. Figure 106 ”, serial number and then Step 4: When subscriber wants to terminate the Internet service, press”...
  • Page 114 Account Generator Printer Enter the date (MonthDate ) PS/2 Keypad Figure 108 Keypad’s Hot Key List Daily Account Report Printout Press ABCAA Billing Profile Purchase Unit Figure 109 Daily Account Easy Hotspot Kit...
  • Page 115 Monthly Account Report Printout Press ABCBB Billing Profile Purchase Unit Figure 110 Monthly Account System Status Report Printout Press ABCCC Figure 111 System Status Report Printout Easy Hotspot Kit...
  • Page 116 Network Report Printout Press ABCAB Figure 112 Network Report Printout Easy Hotspot Kit...

  • Page 117: Customization

    3-2-4-5 Customization Login Page The Wireless Subscriber Gateway provides three different login page formats, including standard, redirect, advanced and frame format. Standard For some service providers, they may hope to have a customize subscriber’s login page to the users. This function helps them to realize the ideal. The page elements are including login page title, background color, subtitle etc.
  • Page 118 Item Default Description Copyright Enable The copyright is allowed the administrator to input a paragraph in the subscriber login page for copyright information. The maximum character of the copyright is 80. Background Color FFFFFF The background text color can be specified color. For the specified text color format please views the color grid.
  • Page 119 Redirect This allow service provider to redirect the subscriber’s browser to a specified home page. Figure 116 Redirect Login Page Setting Screen Copy and paste the following HTML Code into your home page to produce redirect subscriber login page. Figure 117 Redirect Login Page Code Screen Easy Hotspot Kit...
  • Page 120 Advanced This function allow user to design login page of Wireless Subscriber Gateway. Figure 118 Advanced Login Page Setting Screen Item Default Description Welcome Slogan Welcome The maximum allowed characters length is 80. Page Background None The page background can be none or specified color. For the background color format please views the color grid.
  • Page 121 Figure 119 Color Gird Frame If “Frame” is selected the subscriber login page will be separate into Top Frame and Bottom Frame. Bottom Frame is a default format for username and password input, Top Frame is allowed to be specified a URL to link. www.caesarpark.com Figure 120 Frame Login Page Setting Screen Item...
  • Page 122 Figure 121 Example-Login Page Screen Logo This function allows service provider to upload the customer’s logo image file which can be shown on the standard login page and account printout of PC-connected printer. Figure 122 Logo Setting Screen Easy Hotspot Kit...
  • Page 123 Item Default Description File Path Empty Enter the file pathname of the logo file in the File Path field. Click Apply button to save the logo file to system. Click Delete button to delete the logo file. Figure 123 Logo Setting Screen Figure 124 Login Page Easy Hotspot Kit...
  • Page 124 Information Window This function allow service provider can decide whether they want an “Information Window” pop-up on subscriber PC when authenticate successful or not and specified text of information window. Subscriber can type “http://1.1.1.1/info” to open the information window again or enter “http://1.1.1.1/logout”...
  • Page 125 Figure 126 Example-Login Page Screen Billing Type=Time to Finish Can be replenished by subscriber=Disable Figure 127 Information Window Billing Type=Time to Finish Can be replenished by subscriber=Enable Figure 128 Information Window Easy Hotspot Kit...
  • Page 126 Billing Type=Accumulation Can be replenished by subscriber=Disable Figure 129 Information Window Billing Type=Accumulation Can be replenished by subscriber=Enable Figure 130 Information Window Easy Hotspot Kit...
  • Page 127 Account Printout This function allow service provider to specified text of account printout. Figure 131 Account Printout Customization Setting Screen Easy Hotspot Kit...
  • Page 128 Click Apply button to save the new settings. Click Apply button, the success dialog box appears. Click on Back to return to Account Printout Customization setting screen. Figure 132 Success Dialog Box Figure 133 PC-connected Printer Printout Easy Hotspot Kit...
  • Page 129 Figure 134 Account Generator Printer Printout Figure 135 Account Generator Printer Printout Easy Hotspot Kit...
  • Page 130 Credot Standard Login Page This function allow service provider to customize the additional credit card message for the standard login page. Figure 136 Credit Customization Setting Screen Figure 137 Standard Login Page(Enable Credit Card Service=enable) Figure 138 Billing Setting Scree Easy Hotspot Kit...

  • Page 131: Customer Information

    Service Selection Page This function allow service provider to customize the additional credit card message for the standard login page. Customer Information Figure 139 Service Selection Page Setting Screen(Authorize.net) Easy Hotspot Kit...
  • Page 132 Figure 140 Service Selection Page Setting Screen (iValidate.net) Figure 141Service Selection Page Setting Screen (Secure Pay) Easy Hotspot Kit...
  • Page 133 Figure 142 Service Selection Page Setting Screen (PalPay and WorldPay) Figure 143 Service Selection Page Setting Screen(Authorize.net) Easy Hotspot Kit...
  • Page 134 Figure 144 Service Selection Page Setting Screen (iValidate.net) Figure 145Service Selection Page Setting Screen (Secure Pay) Easy Hotspot Kit...
  • Page 135 Figure 146 Service Selection Page Setting Screen (PalPay and WorldPay) Successful Page Figure 147 Successful Page Setting Screen Easy Hotspot Kit...
  • Page 136 Figure 148 Example-Successful Page Fail Page This function allow service provider to customize the message for the fail page. Figure 149 Fail Page Setting Screen Click Apply button to save the new settings. Easy Hotspot Kit...
  • Page 137 Figure 150 Fail Page Click Apply button, the success dialog box appears. Click on Back to return to Credit Card Customization setting screen. Figure 151 Success Dialog Box Easy Hotspot Kit...
  • Page 138 User Agreement Page This function allow user to design user agreement page of Internet Subscriber Server. Figure 152 User Agreement Page Setting Screen Figure 153 User Agreement Page Easy Hotspot Kit...

  • Page 139: Portal Page

    3-2-4-6 Portal Page This feature allows redirecting subscriber’s browser to a specified portal page after successful login. Figure 154 Portal Page Setting Screen Item Default Description URL Link Empty Enter the URL Link page. The input format can be “http://www.yahoo.com”. The maximum character of the URL Link is 200. Click Apply button to save the new settings.

  • Page 140: Advertisement

    3-2-4-7 Advertisement The system allow service provider to input 10 URL links for advertisement link purpose. Figure 156 Advertisement URL Link Setting Screen Item Default Description Frequency One Time One Time Only—One Time Only means to send the advertisement link Only once after the subscriber Login.

  • Page 141: Walled Garden

    Click Apply button, the success dialog box appears. Click on Back to return to Advertisement URL Link setting screen. Figure 157 Success Dialog Box 3-2-4-8 Walled Garden We prepare ten URL links that allows subscriber to access the specific Web pages even they didn’t have a username or password.
  • Page 142 Name Figure 159 Login Page Item Description Link 1~10 Name The name is allowed user to set the prompt string in user customize login page. The maximum allowed characters length is 80. URL 1~10 The input format can be “http://www.yahoo.com”. The maximum character of the Link# is 200.

  • Page 143: Ddns

    3-2-4-9 DDNS The DDNS service (Dynamic Domain Name Service), an IP Registry provides a public central database where information such as email addresses, host names, IP addresses etc. can be stored and retrieved. This solves the problems if your DNS server uses an IP associated with dynamic IP addresses. When the ISP assigns the Wireless Subscriber Gateway a new IP, the Wireless Subscriber Gateway must inform the DDNS server the change of this IP so that the server can update its IP-to-DNS entry.
  • Page 144 Item Default Description Force to update every 1 day Enter a number in the field to set the force update interval ~day(s) when WAN IP (in days). address keeps no change 01~03 The index number of a DDNS account. Active Disable Click on check box, active or inactive the DDNS record.
  • Page 145 Figure 162 Success Dialog Box Easy Hotspot Kit...

  • Page 146: Wireless

    3-2-4-10 Wireless Figure 163 Wireless Setting Screen Easy Hotspot Kit...
  • Page 147 Item Default Description General Settings Wireless Connection Enable To Enable or Disable wireless connection. The ESSID is the unique name that is shared among all ESSID Wireless points in a wireless network. It is case sensitive and must not exceed 32 characters. Channel Select the channel ID for wireless connection.
  • Page 148 Item Default Description This selects which of the Keys the Wireless Subscriber Gateway uses when it transmits. You can change the selected encryption key every now and then to increase the security of your network. Note: You have to configure all WEP keys (1~4), and select one of the four WEP key.
  • Page 149 Item Default Description This setting determines the size at which packets are Fragmentation fragmented. Enter a setting ranging from 256 to 2432 bytes. 2432 Use a low setting in areas where communication is poor or Threshold where there is a great deal of radio interference. The preamble type is a section of data at the head of a packet that contains information the Wireless Subscriber Preamble Type...

  • Page 150: Account Generator

    Figure 164 Restart Dialog Box This operation will load the default manufacturer configuration to the system. All this page (Wireless) configuration setup will be replaced by default settings. 3-2-4-11 Account Generator Figure 165 Account Generator Printer Setting Screen Easy Hotspot Kit...
  • Page 151 Figure 166 Application Easy Hotspot Kit...

  • Page 152: System Status

    3-3 System Status Display Wireless Subscriber Gateway system basic status, including, System Account List Account Log Current User DHCP Clients Session List LAN Devices Figure 167 System Status Item Screen Easy Hotspot Kit...

  • Page 153: System

    3-4-1 System The System Information Menu displays current system basic information including the service connection message, host name, LAN, WAN, DHCP Configuration, DNS, E-mail Redirection, SSL Certificate, network traffic Information and the system firmware version number. Figure 168 System Status Screen Easy Hotspot Kit...
  • Page 154 Figure 169 System Status Screen Easy Hotspot Kit...

  • Page 155: Account List

    3-4-2 Account List You can display a list of all the account information on this device. This table includes the username, password, usage time, time created, login time, expiration time and status. Figure 170 Account List Click on refresh button to update the account list page. Click the column button to sort the column in ascending/descending order.

  • Page 156: Account Log

    3-4-3 Account Log The account log shows the accounts’ log information. Figure 171 Account Log This allow you to export the account logs to a text file format. (export.log) Click on Clear Log to remove all account log entries. Click on refresh button to update the account log page. Click the column button to sort the column in ascending/descending order.

  • Page 157: Current User

    3-4-4 Current User Display the current logged-in subscribers’ status. It allow service provider to disconnect any subscribers. Figure 172 Current User List Figure 173 Current User List (super account) Figure 174 Current User List (No Authentication) Click on refresh button to update the current user list page. Type Username IP Address...

  • Page 158: Dhcp Clients

    3-4-5 DHCP Clients The DHCP client table shows the current DHCP users on the LAN. Figure 175 Current User Screen 3-4-6 Session List The remote site administrator could monitor the real time usage status of Wireless Subscriber Gateway via this page. Figure 176 Session List Screen Easy Hotspot Kit...

  • Page 159: Lan Devices

    3-4-7 LAN Devices You can manage all devices by clicking on device name to access device’s Web-based interface. Click Figure 177 LAN Devices Status Screen Figure 178 Example- Ethernet Switch Management Screen 3-4 System Tools This allows service provider or administrator to process Firmware upgrade, change password and backup or restore configuration.

  • Page 160: Configuration

    3-4-1 Configuration Use the Configuration item to save, restore or reset configuration parameters of the Wireless Subscriber Gateway. Figure 180 Configuration Setting Screen Item Default Description Backup Click it to save the system configuration to your computer. (export.cfg) Remote TFTP Server IP Empty Enter the IP address of TFTP Server.

  • Page 161: Firmware Upgrade

    3-4-2 Firmware Upgrade The Firmware Upgrade menu loads updated firmware to be permanent in flash ROM. The download file should be a binary file from factory; otherwise the agent will not accept it. After downloading the new firmware, the agent will automatically restart it. Manual Firmware Upgrade Figure 181 Manual Firmware Upgrade Setting Screen Item...
  • Page 162 Scheduled Firmware Upgrade Scheduled Firmware Upgrade is a program that enables an automatic upgrade to the latest firmware version through the TFTP server. Figure 182 Scheduled Firmware Upgrade Setting Screen Item Default Description Disable/Enable Disables or enables the scheduled firmware upgrade function. TFTP Server IP Empty Enter the IP address of TFTP Server.

  • Page 163: Boot Code

    3-4-3 Boot Code Figure 184 Boot Code Upgrade Setting Screen 3-4-4 System Account Use the System Account screen to change the system accounts. Figure 185 System Account Setting Screen Easy Hotspot Kit...
  • Page 164 Item Description Username The username can consist of up to 20 alphanumeric characters and is sensitive. Password The password can consist of up to 20 alphanumeric characters and is sensitive. Confirm The password for confirmation. Super Subscriber Disables or enables the super account function. Idle Time Out The user idle time out valid is 1 to 1440 minutes.
  • Page 165 Figure 188 System Quick View Web-Based Accounting Manager Step 1: Start your Web browser and enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter. Figure 189 Web Browser Location Field (Factory Default) Easy Hotspot Kit...
  • Page 166 Step 2: The Wireless Subscriber Gateway configuration main menu will appear. Enter account as the Username and account as the password and click Login Username: account Password: account Figure 190 Web-Based Accounting Manager Login Screen Step 3: After a valid user name and password have been provided, the account Generator Panel homepage will appear.
  • Page 167 Supervisor Account Step 1: Start your Web browser and enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter. Figure 192 Web Browser Location Field (Factory Default) Step 2: The Wireless Subscriber Gateway configuration main menu will appear. Enter supervisor as the Username and supervisor as the password and click Login.

  • Page 168: Ssl Certificate

    Super Subscriber Account Start your Web Browser; a subscriber login page will appear. Enter super as the Username and super as the password and click Enter, you can use Internet now Username: super Password: super Figure 195 Subscriber Login Page 3-4-5 SSL Certificate The function allows you to download the registered CA certificate into the Wireless Subscriber...

  • Page 169: Pin Command

    3-4-6 Pin Command The Ping function can check the Wireless Subscriber Gateway networking connective or not. Figure 197 Ping Command Screen Item Description IP or URL Enter the IP address or the URL link. Easy Hotspot Kit...

  • Page 170: Restart

    3-4-7 Restart If your Wireless Subscriber Gateway is not operating correctly, you can choose this option to display the restart Wireless Subscriber Gateway screen. Clicking the apply button restart the Wireless Subscriber Gateway, with all of your settings remaining intact. Figure 198 Restart Screen 3-4-8 Logout...

  • Page 171: Appendix A Signal Connection Arrangements

    Appendix A Signal Connection Arrangements RJ-45 Ethernet Port The Wireless Subscriber Gateway RJ-45 Ethernet port can connect to any networking devices that use a standard LAN interface, such as a Hub/Switch Hub or Router. Use unshielded twisted-pair (UTP) or shield twisted-pair (STP) cable to connect the networking device to the RJ-45 Ethernet port. Depending on the type of connection, 10Mbps or 100Mbps, use the following Ethernet cable, as prescribed.

  • Page 172: Appendix B Regulations/Emi Compliance

    Appendix B Regulations/EMI Compliance FCC Regulatory Statement Part 15-Class B compliant device This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including that which may cause undesired operation.

  • Page 173: Limited Warranty

    LIMITED WARRANTY Easy Hotspot Kit What the warranty covers: We warrant its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, we will at its sole option repair or replace the product with a like product with a like product.
  • Page 174 P/N:6830604-0010G V1.00...

This manual is also suitable for:

Wg-604p

Table of Contents
