Mercury LPSA70 User Manual

This manual is guidance for how to use the Mercury 70W (LPSA70) / 90W (LPSA90) auto voltage
selection laptop adaptor.

Specification:

Input
Output
Max Power Output
Max Current Output
Dimension

LED display:

At auto operation status (slider at "AUTO"):
Auto Search
Working
Standby
Reset
At manual select status (Slider at 15-16V/19.5V):
Working
Standby

AUTO mode:

At auto mode, device will automatically detect and select the required working voltage for the laptop connected.
1- Connect the AC power to device, both Blue and Green LED will lit once to indicate de device is powered
up properly.
2- Push slide selector to "AUTO" if not already done so, the Blue LED will lit for 2 seconds and off.
3- Select the tip that is compatible with your laptop and connects it to the DC output tip, the fixed tip on this
product is 5.5 x 2.5mm.
4- Connect the device to the laptop, the Blue LED will lit for 2 second and start flashing, this indicates the
product is searching for the correct required working voltage for the laptop. When the Blue LED stay lit,
the device is working at the correct required voltage.
5- When laptop is standby or switched off, the device will enter standby mode too. This indicates by the LED
remained switched off. When the laptop is switched on on the next use, the device will automatically
switch back on.
6- This device will only require search for working voltage once and remember the voltage as long as it
remained plugged in with power. To establish a new search for different laptop, unplug the device from
Auto Voltage Selection Laptop Power Adaptor
CAUTION:
The appliance is not intended for use by children or infirm
persons without supervision. Please read through this manual
carefully before use.
Blue and Green LED on at the same time
Item ref: 661.130UK/661.131UK
LPSA70
100 – 240Vac 50/60Hz
15-16/19.5Vdc (Manual)
15-20Vdc (Auto)
70W
3.60A
110 x 47 x 31mm
Blue LED Flash
Blue LED on
LED off
Green LED on
LED off
LPSA70/90
User Manual
LPSA90
90W
4.62A
118 x 55 x 32mm
