- Page 1 OWNERS MANUAL Model S1600/S1610 VHF Wireless Microphone 3149 MacArthur Blvd. Northbrook. IL 60062 1 -800-AmpliVox...
- Page 2 The AmpliVox S1600 wireless microphone system is compact, lightweight and compatible with all AmpliVox and Perma Power Sound Systems currently being produced or that were produced since 1961. The S1600 operates in an authorized VHF band and has a useful range of up to 200’ in line-of sight applications.
- Page 3 FEATURES & CONTROLS Flexible Antenna Power ON Indicator Phone Out Jack—connect this jack to amp Mike Out Jack Power ON/OFF Switch Channel Selector Switch 9V DC Power input Jack Mike Input Jack Receiver Power ON Indicator Power ON/OFF Switch Channel Selector Switch S2030 Lapel Mic Transmitter...
- Page 4 OPERATION POWER SOURCE The transmitter and receiver are each operated by a 9V alkaline battery. Before use, install a battery as shown. Make certain the battery is fully seated in its compartment so the cover slides in place easily. Battery life with alkaline batteries is approximately 8 hours of operating time.
- Page 5 RECEIVER OPERATION Each unit provides two selectable receiving frequencies. 1) Switch the Frequency Selector Switch to the same channel as the one selected on the transmitter (A or B) 2) Attach the receiver to the amplifier by inserting the mounting bracket foot into the amplifiers accessory shoe (if available) or with the supplied Velcro.
- Page 6 MOUNTING The receiver can be mounted to some AmpliVox units by means of the supplied mounting bracket or velcro self-adhesive patch.
- Page 8 3149 MacArthur Blvd. Northbrook. IL 60062 1 -800-AmpliVox 1-800-AmpliVox (800-267-5486) FAX 847-498-6691...
