2005 Pre-Delivery Instructions
Please take the time to read this booklet carefully, as it will provide you with the information you will need to ensure
the safe, secure, and timely installation of your new spa. The following sections are guidelines on how to prepare for
delivery and set-up of your new spa. Specifically covered are site selection, delivery access, ground preparation,
and electrical requirements.
Remember to carefully read the Owner's Manual that accompanies your spa, and to complete the warranty card
within 10 days of delivery. These items, along with other valuable information, will be found in the Owner's Package
which has been placed in the equipment compartment of your spa, where you will also find its serial number.
Watkins Manufacturing Corporation reserves the right to change features, specifications and design without
notification and without incurring any obligation.
DATE PURCHASED: __________________________________________________________________________
DATE INSTALLED:______________________________________________________________________________
DEALER:______________________________________________________________________________________
ADDRESS: ____________________________________________________________________________________
TELEPHONE:__________________________________________________________________________________
In most cities and counties, permits will be required for the installation of electrical circuits or the construction of
exterior surfaces (decks and gazebos). In addition, some communities have adopted residential barrier codes which
may require fencing and/or self-closing gates on the property to prevent unsupervised access to a pool (or spa) by
children under 5 years of age. Your Tiger River spa is equipped with a locking cover that meets the ASTM F1346-91
Standard for Safety Covers and as a result, is usually exempt from most barrier requirements. As a general practice,
your local Building Department will inform you of any applicable barrier requirements at the time a permit is
obtained for the installation of an electrical circuit. Your Tiger River dealer can provide information on which permits
may be required.
Tiger River Spa Pre-Delivery Instructions
Congratulations on your decision to
enjoy the finest spa available...
Welcome to the growing family of
®
Tiger River
spa owners.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Caspian and is the answer not in the manual?

Questions and answers

Summary of Contents for Tiger River Caspian

  • Page 1 (or spa) by children under 5 years of age. Your Tiger River spa is equipped with a locking cover that meets the ASTM F1346-91 Standard for Safety Covers and as a result, is usually exempt from most barrier requirements.
  • Page 2: Outdoor And Patio Installation

    • Never let water get into the subpanel (230 volt models), into the interrupter switch (115 volt models), or into the electrical outlet that your spa is plugged into. Your 115 volt Tiger River spa will come with a protective box designed to keep out rain and water from sprinkler systems. Your 230 volt spa’s subpanel is raintight when installed correctly with the door closed.
  • Page 3: Delivery Access

    Use the information on previous page to determine the requirements for access to your desired location. Model Width W Length L Height H Caspian ™ (CHP) 36” 7’ 0” 7’ 0” Bengal ®...
  • Page 4: Installation Notes

    GROUND PREPARATION Your Tiger River spa has been engineered to perform on all kinds of common yard surfaces. While a concrete slab is best for long-term use*, other foundations are acceptable so long as a level base is prepared prior to delivery. Three foundation base...
  • Page 5 Caspian ™ (Model CHP) Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. (Front view) 12 1/2" (31.8 cm) SECONDARY DRAIN 21" (53.3 cm) 1 3/4" (3.8 cm) ELECTRICAL CUTOUT 49 1/2" (125.7 cm) (location may vary 1/2"...
  • Page 6 Bengal ® (Model M & MM) Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. (Front view) SECONDARY DRAIN 13 1/2" (34.3 cm) 22" (55.9 cm) 36" (91.4 cm) 1 3/4" (3.8 cm) ELECTRICAL CUTOUT (location may vary 1/2"...
  • Page 7 Sumatran ® (Model N) Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. (Front view) 15" (38 cm) MAIN DRAIN 17 1/2" (44.5 cm) 1 3/4" (3.8 cm) ELECTRICAL CUTOUT 43 1/2" (110.5 cm) (location may vary 1/2"...
  • Page 8 Unless otherwise stipulated by your dealer, THIS IS YOUR RESPONSIBILITY. IMPORTANT: All electrical circuits must be installed by a qualified, licensed electrician. Tiger River spas are manufactured in two different electrical versions. The Caspian and Bengal (MM) models are ®...
  • Page 9 Spa Control Box and then complete the wiring connections in the control box. IMPORTANT NOTE: Three different wiring diagrams are shown: one for the Caspian‚ one for the Bengal (MM) and one for the Bengal (M) and Sumatran models. Always follow the wiring diagram for your specific model.
  • Page 10 CASPIAN 230 VOLT PERMANENTLY CONNECTED MODEL WARNING! The exact physical location of the terminals on the GFCI HEATER breaker will vary between manufacturers. Connecting the hot wire to GROUND the neutral terminal will cause irreversible damage to the control box.
  • Page 11 BENGAL (M) AND SUMATRAN 230 VOLT CONVERTED MODELS WARNING! The exact physical location of the terminals on the GFCI breaker will vary between manufacturers. Connecting the hot wire to HEATER GROUND the neutral terminal will cause irreversible damage to the control box. 230V, 50 Amp, 2–POLE, CIRCUIT BREAKER...
  • Page 12: Spa Specifications

    Spa Specifications 115V System: 36" 4,000 4,479 7'0" Caspian™ Not available Square (230 volt) Gallons Lbs. Lbs. Lbs. per 7'0" (Model CHP) 230V System: 230 Volt, .91m feet square 1,249 2,032 50 Amp single phase 2.13m foot Litres GFCI protected circuit 2.13m...
  • Page 13 General Name: ______________________________________________________________________________________ Telephone: ______________________________________________________________________________________ Name: ______________________________________________________________________________________ Telephone: ______________________________________________________________________________________ ADDITIONAL PRODUCTS AVAILABLE FROM YOUR TIGER RIVER ® SPA DEALER • EverFresh ® water care system • FreshWater ® III high output ozone purification system • Hot Spring ® MPS chlorine-free oxidizer •...
  • Page 14 SERVICES AVAILABLE FROM YOUR TIGER RIVER SPA DEALER Service Cost Pre-Delivery site inspection ______________ Deliver spa to installation site ______________ Unwrap spa and haul away packaging material ______________ Set up & level spa ______________ Fill the spa with water ______________...
  • Page 15 NOTES Page 15 Page 15 Pre-Delivery Instructions...
  • Page 16 1280 Park Center Drive Vista, California 92081 (800) 999-4688 extension 8432 ©2005 Watkins Manufacturing Corporation. Tiger River, Caspian, Bengal, Sumatran, IQ 2020, Cover Shield, EverFresh, FreshWater and The Home Relaxation Specialists are trademarks of Watkins Manufacturing Corporation. Part #62261 Rev. A (1/05)
