CalGym CG-7505 Owner's Manual

Pectoral contractor maintenance & assembly instructions

Advertisement

Quick Links

NOTICE
It is the Purchaser's/Owner's obligation:
1. To disclose and post all Rules & Regulations, Danger, Warning and Caution
labels affi xed on the machine to their customers/users.
2. Equipment to be installed by Tuff Stuff Authorized Dealer or a service
company approved by Tuff Stuff .
3. Provide trained personnel, supervision and correct usage of the equipment.
4. Provide scheduled inspection, maintenance & repairs and must be performed
by Tuff Stuff Authorized Dealer or a service company approved by Tuff Stuff .
5. Must use only genuine Tuff Stuff replacement parts.
6.
Machine must be anchored to a solid and level surface.
OWNER'S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
BY TUFFSTUFF FITNESS
CG-7505
Pectoral Contractor
Revision Date 7-25-2012
CG-7505_Rev0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CG-7505 and is the answer not in the manual?

Questions and answers

Summary of Contents for CalGym CG-7505

  • Page 1 Maintenance & Assembly Instructions IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE NOTICE It is the Purchaser’s/Owner’s obligation: BY TUFFSTUFF FITNESS 1. To disclose and post all Rules & Regulations, Danger, Warning and Caution CG-7505 labels affi xed on the machine to their customers/users.
  • Page 2: Table Of Contents

    Should additional information be required, or should situations arise that are not covered by this manual, the matter should be directed to Customer Service at Tuff Stuff Fitness Equipment Inc. in Chino, California. CG-7505 Pectoral Contractor...
  • Page 3: Danger, Warning, & Caution Labels Information

    Carefully read ALL Danger, Warning & Caution labels posted on the machine CG-7505 Pectoral Contractor...
  • Page 4 Carefully read ALL Danger, Warning & Caution labels posted on the machine CG-7505 Pectoral Contractor...
  • Page 5 .net service promptly. DO NOT ATTEMPT to use or fix any piece of equipment that is not functioning properly. ASTM F1749-96 TUFFSTUFF FITNESS EQUIPMENT INC. CHINO, CA 91710 CG-7505 Pectoral Contractor...
  • Page 6: Anchoring Unit

    ANCHORING UNIT BY TUFFSTUFF FITNESS Holes on shoe plates are provided for anchoring the unit to the fl oor. (See anchoring hole locations below) 7/16” DIAMETER HOLE CG-7505 Pectoral Contractor...
  • Page 7: Important Safety Instructions

    CAUTION: indicates a hazardous situation which, if not avoided, could injury or death. result in minor or moderate injury. CG-7505 Pectoral Contractor...
  • Page 8: Registration, Service & Assembly

    Registration, Service & Assembly BY TUFFSTUFF FITNESS Thank you for purchasing the CALGYM CG-7505 Pectoral Contractor. This machine is part of the Tuff Stuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly.
  • Page 9: Inspection/Maintenance

    Professional Service Company approved by Tuff Stuff . Keep a service log of all maintenance and repair activities. Extra copies can be downloaded from our website. INSPECTION/MAINTENANCE RECORD DATE REPLACEMENT REPAIRS INSPECTED BY WARRANTY REPAIRS CG-7505 Pectoral Contractor...
  • Page 10: Cable Inspection

    A BREAK ON THE CABLE CABLE END SLIPPING OUT IMPORTANT NOTE: DAMAGED OR WORNED CABLE (AS SHOWN ABOVE) MAY DAMAGE THE PULLEY(S). YOU MUST INSPECT THE PULLEYS AT THIS TIME FOR WEAR AND TEAR. REPLACE IF NEEDED. CG-7505 Pectoral Contractor...
  • Page 11: Step 1

    Step 1 BY TUFFSTUFF FITNESS FULLY FASTEN WARNING IT IS RECOMENDED TO HAVE ANOTHER PERSON ASSIST YOU WITH THE INSTALLATION ON THIS UNIT. CG-7505 Pectoral Contractor...
  • Page 12: Step

    Step 2 BY TUFFSTUFF FITNESS FULLY FASTEN CG-7505 Pectoral Contractor...
  • Page 13: Step 3

    Step 3 BY TUFFSTUFF FITNESS CG-7505 Pectoral Contractor...
  • Page 14: Step 4 Cable Routing

    FIG. A FIG. B FIG. C FIG. D NOTE: 1. SOME PARTS CUT OUT/NOT SHOWN FOR CLARITY. REMOVE ANY PULLEYS NECESSARY TO INSTALL CABLE. 3. MAKE SURE THE CABLE RUNS BETWEEN THE PULLEYS AS SHOWN. FULLY FASTEN CG-7505 Pectoral Contractor...
  • Page 15: Step 5

    WEIGHT PLATE (#18) or if there is excess slack in the cable system, loosen regular nut (#38) and adjust split hex tap bolt (#70) in/out to give the cable proper tension (taut). Once achieving the proper tension, re-tighten regular nut (#38). CG-7505 Pectoral Contractor...
  • Page 16: Step

    Important Safety Instructions Step 6 BY TUFFSTUFF FITNESS FULLY FASTEN THESE AND ANY LOOSELY FASTEN HARDWARE CG-7505 Pectoral Contractor...
  • Page 17: Basic Exercise Guide

    It is the responsibility of the fl oor personnel to instruct users on proper operation of the equipment and review the exercise label as shown below. The intended use of this equipment is for Pectoral Contractor exercise only. CG-7505 Pectoral Contractor...
  • Page 18: Parts List

    NYLON INSERT LOCK NUT Z/P 1/4 20 BNH2983 BNH2916 BNH2979 LABEL IMPORTANT FOR SMOOTH PERFORMANCE... LABEL CALGYM BY TUFFSTUFF FITNESS FINISHED HEX NUT Z/P 1/2 13 BNH0206 LABEL TUFFSTUFF FITNESS BNH2933 LABEL WEIGHT RESIST 4/C ON 10M LEXAN 9 1/2 X 25 3/8 BNH2195...
  • Page 19: Exploded View

    Exploded View BY TUFFSTUFF FITNESS CG-7505 Pectoral Contractor...
  • Page 20: Warranty

    BY TUFFSTUFF FITNESS WARRANTY This warranty applies only in the United States to the products manufactured or distributed by Tuff Stuff Fitness Equipment Inc. under the CalGym brand name. Tuff Stuff warrants to the original purchaser that CalCym equipment will be free from defects in material and workmanship.
