Onkyo TX-NR727 Specifications

2013 NEW PRODUCT RELEASE
TX-NR727
Transform Your Days and Nights with THX
Extract every last drop of performance from your home cinema budget with the THX
Inverted Darlington Circuitry for all seven channels ensures reference-level playback of your hi-res media. DSX
MultEQ speaker calibration, and real-time Dynamic EQ
®
experience that's so realistic you can almost smell the popcorn. For music lovers, built-in Wi-Fi allows you to stream 192/24 hi-res, lossless,
and compressed audio directly from smartphone and tablet, or from PC and NAS using our remote app to control playback. The app
also enables quick selection of internet radio and streaming service channels. Or, if you prefer, simply pair and stream using onboard
Bluetooth technology. To expand beyond the living room, a selection of powered outputs and line-outs are on hand for synchronized
audio in up to three zones around the home. With eight 4K- and 3D-ready HDMI
upscaling via Qdeo technology, the TX-NR727 takes its place at the very top of the class.
™
ADVANCED FEATURES
• THX Select2 Plus-Certified for Studio Reference
® ™
Playback
• HDMI ® Video Upscaling to 4K with Qdeo ™
Technology by Marvell
• 4K Passthrough from Compatible Source Devices via HDMI
• Built-in Wi-Fi-Certified Wireless LAN Capability
• Bluetooth Version 2.1 + EDR Capability (Compatible
Profile: A2DP v1.2, AVRCP v1.3)
• Three-Stage Inverted Darlington Circuitry with
Discrete Output Stage for All Channels
• Frontside MHL for 1080p Video and Stills from
™
Smartphone and Tablet
• Internet Radio and Music Streaming Service Connectivity
(TuneIn Radio, Last.fm, Spotify, AUPEO!, and Simfy)
• Playback of Audio Files Over Wireless Home Network
(MP3, WMA, WMA Lossless, FLAC, WAV, Ogg Vorbis,
AAC, Apple Lossless, DSD, LPCM , and Dolby
*2
• Supports Onkyo Remote Apps for iPod touch/iPhone
and Android Devices
*4
• Picture-in-Picture InputVideo Preview with InstaPrevue
Technology
• Phase-Matching Bass Boost
• Audyssey MultEQ for Room Acoustic Correction
®
• Audyssey DSX ® and Dolby ® Pro Logic ® IIz Upmixing
for Seven-Channel Surround Sound
• Overlaid On-Screen Display (OSD) via HDMI with
Quick Set-Up and Home Menu
• Powered Zone 2 and Zone 2/3 Line-Out for Distributed
Audio Playback in Multiple Rooms
• Hybrid Standby Power-Saving for Video and Network
Connectivity in Standby
• Smart Grid-Ready
7.2-Channel Network A/V Receiver
technology—all from class-leader Audyssey—treat the listener to a cinematic
®
• Bi-Amping Capability for Front Channels
*1 Availability of services depends on region. Some services may require a
firmware update. Availability of third-party services advertised here is accurate
at the time of publication, but may be subject to change without notice.
*2 LPCM is available via DLNA only. *3 Compatible with iPod touch (3rd
Processing
generation or later) and iPhone 3GS or later. All models require iOS 4.2 or
later. *4 Requires Android OS 2.1 or later.
AMPLIFIER FEATURES
• 170 W/Ch (6 Ω, 1 kHz, 1% THD, 1 Channel Driven,
IEC);185 W/Ch (6 Ω, 1 kHz, 1 Channel Driven, JEITA)
• WRAT (Wide Range Amplifier Technology)
• H.C.P.S. (High Current Power Supply) Massive High-
Power Transformer
• Discrete Output Stage Circuitry
• Optimum Gain Volume Circuitry
*1
• PLL (Phase Locked Loop) Jitter-Cleaning Circuit
Technology for S/PDIF Audio
PROCESSING FEATURES
TrueHD)
®
• HDMI Support for 3D,Audio Return Channel,
*3
DeepColor , x.v.Color , LipSync, Dolby TrueHD,
™ ™
DTS-HD Master Audio , DVD-Audio, Super Audio
™
™
CD, Multichannel PCM, and CEC
• TI Burr-Brown 192 kHz/24-Bit DAC for All Channels
• Advanced 32-Bit Processing DSP Chip
• 4 DSP Modes for Gaming: Rock, Sports,Action, and RPG
• Advanced Music Optimizer for Compressed Digital Music
• Theater-Dimensional Virtual Surround Function
• Direct Mode
• Pure Audio Mode
• Double Bass Function
• Non-Scaling Configuration
• A-Form Listening Mode Memory
Entertainment
®
Select2 Plus-certified TX-NR727. Three-Stage
® ™
inputs, two outputs (one with ARC), and 4K video
®
CONNECTION FEATURES
• 8 HDMI Inputs (1 Front/7 Rear) and 2 Outputs
• Front-Panel USB Port for Mass Storage Class Devices
(Wide Selection of File Formats Supported)
• HDTV-Capable (720p/1080i) Component Video
Switching (1 Input and 1 Output)
• 4 Composite Video Inputs and 1 Output
• 3 Digital Audio Inputs (1 Optical and 2 Coaxial)
• 6 Analog Audio Inputs
• Phono Input for Turntable Connection
• 2 Parallel Subwoofer Pre-Outs
• Color-Coded, Banana Plug-Compatible Speaker Posts
• Headphone Jack
OTHER FEATURES
• Audyssey Dynamic EQ for Loudness Correction
®
• Audyssey DynamicVolume Listening-Level Adjustment
®
• Independent Crossover Adjustment for Each Channel
(40/50/60/70/80/90/100/120/150/200 Hz)
• A/V Sync Control (Up to 800 ms in 10 ms Steps at 48 kHz)
• Tone Control (Bass/Treble) for Front L/R Channels
• 3-Mode Display Dimmer (Normal/Dim/Dimmer,
Volume Knob LED: On/Off)
*
• RDS (PS/RT/PTY/TP) (European Model Only)
• 40 FM/AM Random Presets
• Certified with DLNA Version 1.5
• Firmware Updates via Network and USB
• Aluminum Volume Control Knob
• Compatible with RI Dock for iPod/iPhone and AirPlay (DS-A5)
• RIHD (Remote Interactive over HDMI) for System Control
• Preprogrammed RI (Remote Interactive) Remote Control
*Note: Volume knob LED is always off when display is dimmed
BLACK SILVER
Microphone for
Audyssey
surround expansion,
®
