Summary of Contents for Mitaka Kohki PSMS2
- Page 1 Operating / User’s Manual MITAKA KOHKI Co., Ltd. POINT SETTER PSMS2 MODEL: PSMS2-M01 Last update February 14, 2010...
-
Page 2: Introduction
INTRODUCTION Thank you for purchasing the MITAKA Point Setter (holding system for surgical MITAKA KOHKI Co., Ltd. instruments). has been producing many products in the area of astronomical instruments, industrial measuring instruments, and medical instruments since 1966. The pride of true workmanship goes into each component of all our products. -
Page 3: Safety Guidelines
◆ Repair, remodeling, maintenance and other technical services must be performed exclusively by an appointed service person of MITAKA KOHKI or those technicians trained by MITAKA KOHKI. MITAKA KOHKI’s guarantee will not cover any mechanical failure or liability caused by an act not in accordance with this instruction. - Page 4 CAUTION！ Conditions of installation and operation must correspond to microsurgical requirements and standards: ◆ Careful handling ◆ Clean environment ◆ Avoidance of extreme mechanical stress or impact ◆ Low vibration ◆ Check for proper condition of the unit and its accessories prior to start up ◆...
-
Page 5: Table Of Contents
OR Table Adapter Brake Knobs ------------------------------------------- 18 4. Further Safety Instructions --------------------------------------------------------------- 19 5. Operational Test ------------------------------------------------------------------------------ 20 6. Troubleshooting ---------------------------------------------------------------------------- 23 7. Labeling -------------------------------------------------------------------------------------- 24 8. Technical Data ------------------------------------------------------------------------------- 25 9. Addresses ------------------------------------------------------------------------------------ 27 Annex: EC DECLRATION OF CONFORMITY EDITION PSMS2-M01 December 26, 2007... -
Page 6: Summary
1. SUMMARY The Point Setter acts as a third arm that can firmly hold an endoscope for a surgeon. Surgeons can operate it quite easily with only one switch required to allow it to be free or to be locked. Surgeons can position their surgical instruments in the desired angle with the use of the Point Setter. -
Page 7: Parts List
2. Part List ① ② ③ ④ ⑤ ①Endoscope holder ②Free switch ③ ② ① ③Safety lock knob ④Arm ⑤OR table adapter ⑥Manual ball joint ⑥... - Page 8 Accessories for Endoscope “endoscope holder” PSBU-045 PSSU-040 Endoscope Holder Endoscope Holder (Universalφ10~15mm) (Universalφ5~10mm) PSBU-046 PSFS-070 Endoscope Holder Endoscope Holder Karl Storz Flexible (Universalφ10~15mm, Pediatric 7mm width) PSNS-060 PSWH-050 PSZH-060 PSGH-055 Nitrogen hose with Endoscope Holder Endoscope Holder Endoscope Holder Shrader connector, (for Wolf scope) (for Zamorano scope) (for Gaab scope)
-
Page 9: Handling Instructions
3. Handling Instructions A. Sterilization of Endoscope Holder Warning: The Point Setter arm and OR table adapter are never sterilized. Instead they are covered by a sterile drape as referenced in 3. D. (page 15). Sterilize the endoscope holder using the following instructions. Please follow these instructions carefully. - Page 10 ■ Cleaning Instructions for the Endoscope Holder Caution: Wear protective gloves, clothing, and a face mask for cleaning of contaminated endoscope holder. Caution: Hot water (greater than 49 degrees C or 120 degrees F) will alter organic materials (blood and tissue), making them difficult to remove.
- Page 11 After cleaning, inspect the endoscope holder for cleanliness and damage. Before sterilization, lubricate all moving parts of the endoscope holder with a non-silicone water soluble instrument milk or lubricant (e.g., Codman Preserve per manufacturer’s instructions). Silicon- or oil-based lubricants are not recommended for use because sterilants cannot penetrate the silicone or oil.
-
Page 12: General Care Of Point Setter Surfaces
Flash Sterilization Flash sterilization can be accomplished in either a pre-vacuum or gravity displacement type of sterilization unit. Flash sterilization in a gravity displacement unit proceeds without a drying phase. We have validated flash sterilization using a gravity displacement unit and the following conditions: Temperature: 132.2 to 133.3 degrees C or 270 to 272 degrees F Pressure:... -
Page 13: Before Draping Patient
C. Before Draping Patient Perform this part before covering the patient with sterile cloth. Set up OR table adapter on the side rail of the operating table. Try to locate the arm at the best position during operating considering the C-arm X-ray or other possible interfering surgical instruments. - Page 14 3. Connect hoses Plug the arm hose into the nitrogen connector of the hospital. Set pressure to 6 ~ 8 kgf/cm or 90 Connector from Connector of Nitrogen hose ~ 115 psi or 6.2 to 7.9 bar. “Point Setter” arm (PSNS-060) NOTE: The PSMS comes with a male Schrader connector.
-
Page 15: Draping The Point Setter
D. Draping the Point Setter 1. Cover the Point Setter with the drape. 2. Secure the drape with adhesive tape, which is attached to the drape. When securing the drape, do not tighten it excessively. The adhesive tape -15-... -
Page 16: Attaching The Endoscope To The Point Setter
E. Attaching the Endoscope to the Point Setter 1. Installing an endoscope Attach the endoscope to the endoscope holder after sterilization in advance. Use the appropriate endoscope holder for each endoscope. Secure firmly so no movement is present. Install an endoscope holder after sterilization over the drape. -
Page 17: Safety Instructions
4. Ready to use Pushing free switch (which is colored gold) allows the arm to move freely. The arm will remain locked at the point by releasing the free switch. CAUTION! Safety instructions Operating table Since the Point Setter is attached to the operating table, the strength of the side rails of the operating table affects the stability of the Point Setter. -
Page 18: Or Table Adapter Brake Knobs
OR Table Adapter Brake Knobs – Special Function This knob enables the fitting to rotate. When the knob is in the way, Pull it straight out and rotate. When the knob causes interference. The position of the knob can be adjusted by pulling straight out and rotating the knob. -
Page 19: Further Safety Instructions
MITAKA KOHKI for inspection. 6. Failure: In the event of a failure, indicate the problem properly. An appointed MITAKA KOHKI Co. Ltd. technical service person or those who are trained by MITAKA KOHKI Co. Ltd. must repair the apparatus. -
Page 20: Operational Test
5. POINT SETTER inspection & operation test (Recommend Monthly Test) Measures required result inspect the outside look no damage, no dirt or no looseness any parts no damage all connectors are connected accurately inspect the air hoses and connectors ６kgf/cm ２ ～８kgf/cm ２ or 6.2 to 7.9 bar inspect the nitrogen gas or air pressure supply (or 90 –... - Page 21 Retention > 2 kg or greater of Brake 1 Inspect the retention of brake 1 by pushing the torque gauge sideways on the arm switch is inactivated when the knob is at LOCK inspect the lock knob switch on all brakes get free switch off all brakes get fixed immediately switch off slowly...
- Page 22 these parts must be firmly fixed with the clamps inspect the clamps inspect firmness the entire system must be able to be firmly fixed -22-...
-
Page 23: Troubleshooting
6. Troubleshooting Failure Remedy Page No function at all Connect Nitrogen Hose Use pressure 6~8 kg/cm or 6.2 to 7.9 bar Or 90-115 psi Turn the safety lock knob on Holding force too weak Check weight of the instrument, Maximum load is 2 kg Check joints of arm Endoscope or device slips Check each of the clamps... -
Page 24: Labeling
7. Labeling ④ ⑤ ① ② ③ ⑤ ① ⑤ ⑤ ⑤ ⑤ ⑤ ⑤ ⑤ ⑤ ① ② ④ Make sure that part is ③ ⑤ securely clamped. -24-... -
Page 25: Technical Data
8. Technical Data POINT SETTER Catalog No. PSMS2 Joint number 6 (includes 1 manual joint) Arm length 650 mm (nominal length) Weight 6 kg Maximum load : Model No. PSMS2 OR Table Adapter Joint number 3 axes and 1 slide... - Page 26 Instrument holders Catalog No. Standard holders : Universal holder, small (φ5～10mm) PSSU-040 Universal holder, large (φ10～15mm) PSBU-045 Universal holder, pediatric (φ10～15mm) PSBU-046 Flexible Storz endoscope PSFS-070 Optional holders : Holder for endoscope Wolf PSWH-050 Zamorano PSZH-060 Gaab PSGH-055 Others Holder for brain spatula PSBH-075 Special holder, ordered (Inquire with local representative for service)
-
Page 27: Addresses
9. Address as of December 26, 2007 Manufacturer of POINT SETTER Mitaka Kohki Co., LTD. 1-18-8 Nozaki, Mitaka, Tokyo 181-0014 Japan Work: 81-422-49-1491 Fax: 81-422-49-1117 Local representatives for service EUROPE, other Countries (including USA): KARL STORZ GMBH & CO. Mittelstrasse 8, D-78532 Tuttlingen, Germany phone: +49 –... - Page 28 MITAKA KOHKI CO., LTD. 1-18-8 Nozaki, Mitaka, Tokyo 181-0014 Japan Work: 81-422-49-1491 Fax: 81-422-49-1117 sales@www.mitakakohki.co.jp e-mail: http://www.mitakakohki.co.jp -28-...
