- Page 1 Installation & Operation Manual Model #: CL12/16W Series 12/16 Watt Cabin Light Assembly Document #540037 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
- Page 2 PROPRIETARY NOTICE: Despite any other copyright notice, this document and information disclosed herein contains confidential, proprietary designs owned by Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used or disclosed to anyone without the written authorization of Audio International, Inc.
-
Page 3: Table Of Contents
Audio International, Inc. CL12/16 Watt Series Cabin Light Installation & Operations Table of Contents Section Description Page General Information ……………………………………………. Introduction ……………………………………………………….. Purpose of the Equipment ………………………………………. Operational Features …………………………………………….. Optional Equipment ……………………………………………… Application ……………………………………………………….. Introduction ……………………………………………………….. Installation ……………………………………………………….. Prior to Installation ……………………………………………….. -
Page 4: General Information
General Information Introduction This manual contains information for the proper installation and operation of the Audio International, Inc. (AI) 12/16 Watt Cabin Light Assembly with Internal Fan. Also included are physical and electrical characteristics of the unit. Purpose of the Equipment The CL12/16Wxx-xx series cabin lights are halogen reading lights that contain an internal fan for cooling purposes. -
Page 5: Application
24 hours and a “Return Request Authorization Number” must be obtained from AI. Refer to the front cover of this manual for address and telephone number of Audio International. Repackage the unit in its original packaging materials and return it to AI following instructions given by the AI representative. -
Page 6: Cautions & Warnings
Audio International, Inc. CL12/16 Watt Series Cabin Light Installation & Operations Cautions and Warnings 3.3.1 It is important to do a pin-to-pin power and ground check on all connectors. Ensure that power and ground are applied only where specified. Damage to the unit may result if power or ground is applied to the wrong points. - Page 7 Audio International, Inc. CL12/16 Watt Series Cabin Light Installation & Operations Connector / Mating Connector Config. Connector Mating Connector DEMA-9P P/N M24308/4-259F DEMA-9S P/N M24308/2-281F Female Screwlock P/N M24308/26-1F Male Screwlock 3-Pin Amp Receptacle P/N 350767-1 3-Pin Amp Plug P/N 350766-1...
-
Page 8: Pinout Assignment Descriptions
Audio International, Inc. CL12/16 Watt Series Cabin Light Installation & Operations Pinout Assignment Descriptions Config. Lighting Option Pin # Description Single button On/Off control + 28 VDC And dimmer Ground On/Off, BRT/DIM, MOM GND Input Emergency Power (+28 VDC) Single button On/Off control and... -
Page 9: Post-Installation Test
Audio International, Inc. CL12/16 Watt Series Cabin Light Installation & Operations Post-Installation Test With the aircraft power turned “ON”, verify all reading / table lights installed are operational. Operations All units have a single toggle switch to activate/deactivate the unit. Press the switch button to activate the unit to the “ON”... -
Page 10: Reference Drawings
Audio International, Inc. CL12/16 Watt Series Cabin Light Installation & Operations Reference Drawings Round Light Assembly The following diagrams show the unit dimensions of the round light assembly. All dimensions are shown in inches. ‘ Document #540037, Rev. B, 4/2000... - Page 11 Audio International, Inc. CL12/16 Watt Series Cabin Light Installation & Operations Square Light Assembly The following diagrams show the unit dimensions of the square light assembly. All dimensions are shown in inches. Document #540037, Rev. B, 4/2000 Page 11 of 11...
