CELOT CTR-180 User Manual

M2m router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CTR-180 M2M Router Manual
CTR-180 User Manual
V1.3
SEP 2012
CELOT WIRELESS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTR-180 and is the answer not in the manual?

Questions and answers

Summary of Contents for CELOT CTR-180

  • Page 1 CTR-180 M2M Router Manual CTR-180 User Manual V1.3 SEP 2012 CELOT WIRELESS...

  • Page 2: Table Of Contents

    CTR-180 M2M Router Manual Contents 1. Introduction 1.1 Feature 1.2 Package Contents 2. Name of each section and features description 2.1 Name of each section 2.2 LED Display 2.3 Getting Started. 3. Using Configuration Menu Connecting CTR-180 to PC 3. 1 OverView 3.

  • Page 3: Introduction

    CTR-180 supports multi-interfaces including USB, Full UART (RS232C/RS485), ● Lite-UART, I2C and RJ. CTR-180 supports direct serial works as if a serial device is directly connected ● to a remote server by server mode or client mode. DATA back-up during the operation of direct serial.

  • Page 4: Package Contents

    CTR-180 M2M Router Manual 1.2 Package Contents 5V DC Power Adaptor CDMA Antenna Battery Pack (optional) CTR-180 GPS Module (optional) Note ※ Pictures in User Manual might be different from the actual product you purchased. Furthermore, some of the components might be changed for better performance without any prior notice.

  • Page 5: Name Of Each Section And Features Description

    CTR-180 M2M Router Manual 2. Name of each section and features description 2.1 Name of each section ■ Front View ■ Rear View CELOT WIRELESS...

  • Page 6: Led Display

    CTR-180 M2M Router Manual ※ External Interface 2.2 LED Display Assignment Color Status Remarks Yellow Green -> Orange -> Red LED1 3G RSSI Various (from Strong to week signal) When the device is connected to 3G LED2 network. LED3 WLAN When WLAN is activated.

  • Page 7: Using Configuration Menu

    Connecting CTR-180 to PC 1). Connect CTR-180 to PC through LAN cable or WIFI 2). For WIFI connection, the default Network ID (SSID) from the factory is CTR-180 3). To access to Web UI page, Input http://10.10.10.254 in the address window as shown below and press Enter Key 4).

  • Page 8: Overview

    CTR-180 M2M Router Manual 3. 1 OverView Basic network information can be displayed. Select Language: Supported languages can be selected. ● 3. 2 Internet 3.2.1 Internet > WAN CELOT WIRELESS...

  • Page 9: Internet > Lan

    CTR-180 M2M Router Manual WAN connection mode for CTR-180 is “3G/LTE” as default but other types of WANs can be selected as follow, 1) STATIC (Fixed) 2) DHCP (Auto Config) 3) PPPoE(ASDL) 4) L2TP 5) 3G/LTE Mode Provided User ID, Password, Dial Number and APN should be input.
  • Page 10 DHCP, etc.. IP Address: The basic IP address for CTR-100 is “10.10.10.254”. IP address ● for CTR-180 can be changeable on this menu. Subnet Mask : You can change Subnet Mask ● Default Gateway : You can change Default Gateway.

  • Page 11: Internet > Dhcp Clients

    You need to Input IP address and MAC address for the client PC and then click Apply Changes. Up to 3 Static IP can be available. 3.2.3 Internet > DHCP Clients DHCP Clients connected to CTR-180 can be monitored on this page. 3.2.4 Internet > Advanced Routing. CELOT WIRELESS...

  • Page 12: Wireless Setting

    You can select Disable/Enable 3.3 Wireless Setting 3.3.1 Wireless > Basic 1). CTR-180 was released from the factory without any wireless security for user’s convenience. You can easily set up wireless security and network setting in Setup Wizard. 2). Click Wireless > Basic then the window below will be displayed.
  • Page 13 Access Point. You can change wireless encryption settings as well as wireless network parameters. 1). WIFI OFF : WIFI shall be OFF by clicking it. 2). Network Mode : You can select Wireless Standard of CTR-180 11b/g/n mixed mode- 2.4GHZ(B+G+N) Using 802.11b/g/n.(Recommended) 11b/g mixed mode- 2.4GHZ(B+G) Using 802.11b/g.

  • Page 14: Wireless > Advanced

    CTR-180 M2M Router Manual 3). Network name SSID: You can change Network SSID, up to 30 characters can be input based on ASC II type. Also you can select Hidden or Isolated not to show the SSID to other clients.

  • Page 15: Wireless > Security

    CTR-180 M2M Router Manual ※ Note We do not recommend any changes on the advanced setup if you are not aware of these features or you are not an expert 3.3.3 Wireless > Security Encryption Type Description Disable No use of Encryption.

  • Page 16: Wireless > Ap Client

    CTR-180 M2M Router Manual 2). And chose one of types from TKIP, AES and TKIPAES for WPA Cipher Type. 3). Input passwords which you want to set in Pass Phrase, if required. 3.3.4 Wireless > AP Client CTR-110 can be used as an AP client.

  • Page 17: Wireless > Wps

    CTR-180 M2M Router Manual - Select AP Client - Input SSID for AP - Select Security mode for AP - Select Encryption Type for AP - Input Password for AP. - Click [Apply] 4) If AP Client IP is displayed as the picture above, CTR-120W works as an AP client.

  • Page 18: Wireless> Statistics

    CTR-180 M2M Router Manual 3.3.7 Wireless> Statistics Wireless LAN TX & TX DATA is available on this menu. CELOT WIRELESS...

  • Page 19: Firewall

    CTR-180 M2M Router Manual 3. 4 Firewall 3.4.1 Firewall > MAC/IP/Port Filtering Settings 1). Basic Settings: MAC/IP Port Filtering : If Enabled, Filtering will be available. ● Default Policy : ● Dropped : Only allowed MAC/IP Port (listed) in the “MAC/IP/Port Filtering ●...

  • Page 20: Firewall > Port Forwarding Settings

    CTR-180 M2M Router Manual 3.4.2 Firewall > Port Forwarding Settings It will allow Client PC to be used for specific service or server. IP Address: IP address for server needs to be input and the server PC should ● operate by server S/W.

  • Page 21: Firewall > System Security

    CTR-180 M2M Router Manual It will allow the PC to be open for every internet user. PC with DMZ enabled can communicate all of internet users and servers. Select Enable DMZ Setting to use DMZ. ● DMZ IP Address: Input client IP address.

  • Page 22: Firewall > Contents Filtering

    CTR-180 M2M Router Manual 3.4.5 Firewall > Contents Filtering Contents Filter Settings ● You can set certain contents of WEB to be restricted. Webs URK Filter Settings ● You can set certain Web sites to be restricted to access. Input URL address and click [ADD] then it will be shown in the “Current Webs URL Filter”...

  • Page 23: Administration

    CTR-180 M2M Router Manual 3.5. Administration 3.5.1 Administration>Status You can check the current status of CTR-180 CELOT WIRELESS...

  • Page 24: Administration>Statics

    CTR-180 M2M Router Manual 3.5.2 Administration>Statics You can check all of Statistics information for CTR-180 including Memory, WAN/LAN and Clients DATA CELOT WIRELESS...

  • Page 25: Administration>Management

    CTR-180 M2M Router Manual 3.5.3 Administration>Management Administrator Setting ● This menu is to change Account (User name) and Password for the first log in page. Factory default for administrator settings is “admin” for User name and “admin” for password as shown below.

  • Page 26: Administration>Upload Firmware

    Note ※ If you choose the wrong BIN file to upgrade CTR-180, it will cause an error or malfunction and CTR-180 will be out of order. So please make sure to use the BIN file officially released from CELOT Wireless only! 3.5.5 Administration>Settings Management...
  • Page 27 [Upload] button. Then, the setting of CTR-180 will be changed to the saved [Config.dat file] Note ※ If you upload the wrong dat file, it will cause error or malfunction of CTR-180. You must use [Config.dat file] of CTR-180. 3). Load Factory setting CELOT WIRELESS...

  • Page 28: Administration> Reboot Settings

    CTR-180 will be changed to the factory setting 3.5.6 Administration> Reboot Settings You can manage CTR-180 system reset in this menu. 1) Auto Reboot In case Auto Reboot is enable, CTR-180 can be reset based on pre-defined schedule. CELOT WIRELESS...

  • Page 29: Administration>System Log

    CTR-180 M2M Router Manual 3.5.7 Administration>System log This page is to set remote log server and show the system log. CELOT WIRELESS...

  • Page 30: Service> Direct Serial

    CTR-180 M2M Router Manual 3.6.1 Service> Direct Serial CTR-180 supports “Direct Serial” via Full UART and Lite UART to transfer Serial raw DATA from a device to a server. The Serial device can work as if it is connected to the server directly.

  • Page 31: Service> Serial Test

    CTR-180 M2M Router Manual 3.5.8 Service> Serial Test CTR-180 supports Full UART and Lite UART for interface with other device. This menu is to test Full UART and Lite UART and to see the DATA from the devices connected to CTR-180 via Full UART or Lite UART.
  • Page 32 CTR-180 M2M Router Manual CELOT WIRELESS...

  • Page 33: Technical Specification

    CTR-180 M2M Router Manual Technical Specification ● Standards : IEEE 802.11g ,IEEE 802.11b, ,IEEE 802.11b ● Security : 64/128-bit WEP, WPA-PSK, WPA-PSK2 ● WLAN Frequency Range : 2.4GHz to 2.483GHz ● Memory : RAM 64MB, Flash Memory 8MB (4MB is reserved for customer S/W) ●...
  • Page 34 CTR-180 M2M Router Manual CELOT Wireless CO., Ltd 4Fl.,NongHyup Bldg.,#1588-10 Gwanyang-Dong, Dongan-Gu, Anyang City, Gyeonggi-Do, Korea (Postal Code : 431-727) Tel : +82 70 7458 5501 Fax: +82 31-388 5501 http://www.celotw.co.kr/ CELOT WIRELESS...
