AMW M510 Operating Instructions Manual

Portable dvd/cd/mp3 player
Hide thumbs
Table of Contents

Advertisement

Quick Links

M
510
PORTABLE
DVD/CD/MP3 PLAYER
OPERATING INSTRUCTIONS
Dear Customer
Thank you for purchasing this product.
For optimum performance and safety, please read the enclosed instructions completely and carefully
before connecting, operating or adjusting this product, keep this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M510 and is the answer not in the manual?

Questions and answers

Related Manuals for AMW M510

Summary of Contents for AMW M510

  • Page 1 PORTABLE DVD/CD/MP3 PLAYER OPERATING INSTRUCTIONS Dear Customer Thank you for purchasing this product. For optimum performance and safety, please read the enclosed instructions completely and carefully before connecting, operating or adjusting this product, keep this manual for future reference.
  • Page 2 BEFORE USING THIS PLAYER Important! Please read the following instructions before attempting to operate the player To prevent fire of shock hazard, do not expose the unit to rain or moisture. Warnings Use only shielded cables to connect I/O devices to this equipment. Types of Warning Signs There are two types of warning in this manual, indicated by the following symbols:...

  • Page 3: Battery Warnings

    Power Cord Warnings ! If operating the portable DVD player from battery power, refer to Chapter 3 of this manual. Use an approved power cord. If the original power cord is missing or lost, purchase a power cord: - That is approved for use in your country. - That is rated for the product and for the voltage and current marked on the product's electrical ratings label.

  • Page 4: Important Safety Instructions

    Caution! 01. To reduce the risk of electric shock, do not remove cover (front or back). No user-serviceable parts inside. Refer servicing to qualified service professional. 02. THIS PRODUCT APPLIES U.S. PATENT NOS. 4,631,603, 4,577,216, 4,819,098, AND 4,907, 093 LICENSED FOR LIMITED VIEWING USES ONLY. 03.The angle between panel and machine must not exceed 130 .

  • Page 5: Notes On Discs

    the DVD-Player from the system unit and refer servicing to qualified service personnel under the following conditions: 1. When the power cord or plug is damaged or frayed. 2. If liquid have been spilled onto the DVD-Player. 3. If the DVD-Player has been exposed to rain or moisture. 4.

  • Page 6: Table Of Contents

    Table of Contents CHAPTER 1. (ACCESSORY LIST) ............... 6 CHAPTER 2. (QUICK USER GUIDE) ..............8 CHAPTER 3. (PREPARATIONS) Parts and controls......................10 Remote control......................11 The meaning of indicators.....................12 Using the AC adapter....................12 Using the battery pack....................12 CHAPTER 4. (PLAYBACK (THE BASICS) Playing back........................14 CHAPTER 5.

  • Page 7: Chapter 1. (Accessory List)

    CHAPTER 1. (ACCESSORY LIST) Check the contents of the package to make sure nothing is missing or damaged. Some parts may be optional. Contact your dealer with any questions. POWER ADAPTER+POWER CORD 2. COMPOSITE VIDEO CABLE 3. STEREO AUDIO CABLE 4.
  • Page 8 COMPOSITE VIDEO CABLE POWER ADAPTER+POWER CORD CAR ADAPTER AUDIO CABLE BATTERY PACK REMOTE CONTROL PORTABLE DVD/CD/MP3 PLAYER OPERATING INSTRUCTIONS EARPHONE Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Before connecting, operating or adjusting this product, please read these instructions completely.

  • Page 9: Chapter 2. (Quick User Guide)

    CHAPTER 2. (QUICK USER GUIDE) 2-1 Connecting the Power Refer to Chapter 3 for instructions on how to install and use the battery pack. 1.Connect the power cord to the AC adapter. 2.Connect the power cord to a power source. 3.Connect the AC adapter to the DC IN jack on the left side of the player.

  • Page 10: Turning The Power On

    2-4 Placing a Disc in To place a disc in the player: 1.Open the disc cover. 2.Align the disc on the player. 3.Gently press the disc into place. 4.Close the disc cover. DO NOT TOUCH THE LASER HEAD. AND AVOID DUST OR DIRT ON THE LASER HEAD.

  • Page 11: Chapter 3. (Preparations)

    CHAPTER 3. (PREPARATIONS) Parts and controls Main unit (front, left and right side) CD/DVD/MP3 PLAYER AUDIO ANGLE SEARCH MUTE TITLE Liquid crystal display 14 PREVIOUS button/PAST REWIND button Do not push the liquid crystal display . 15 SLOW button DISPLAY MENU 16 PAUSE button LEFT PLAY button...

  • Page 12: Remote Control

    Remote control POWER button PROGRAM button REPEAT button NUMBER buttons A-B button MUTE button PREVIOUS button FAST FORWARD button NEXT button FAST REVERSE button SUBTITLE button PAUSE button STOP button LANGUAGE button PLAY button SETUP button ANGLE button MENU button buttons Insert the battery (Lithium battery) Button-type battery (Lithium battery)

  • Page 13: The Meaning Of Indicators

    Indicators There are two indicators at the front side of the player. 1.The left indicator indicates the capacity of the battery. If the battery pack is not full, the color of the indicator is red. If the battery pack is full, indicator turns green.

  • Page 14: Battery Pack

    The Duration to Recharge the Battery Recharge time Recharge and playback time depends on battery pack capacity and the temperature condition. Option Standard Capacity 4000 mAh 4500 mAh Recharge Time 6-8 hours 3-5 hours Playback Time 3 hours 2 hours * The table above is based on the temperature condition of 20 C (68 F).

  • Page 15: Playing Back

    CHAPTER 4. (PLAYBACK (THE BASICS) Playing back Slide POWER switch on the main DC IN ON/OFF unit toward ON to turn the power on The power cannot be turned ON using the POWER POWER ON/OFF button on the remote control. When using the battery pack, the power may not be turned on at once.

  • Page 16: To Turn The Power Off

    Playing back (continued) DVD : Use or the number buttons to select which program you would like to view. Then press ENTER to begin playback. Press TOP MENU or MENU to return to the menu screen. Video CD : Use the number buttons to select which sound track you would like to listen to. Playback begins.
  • Page 17 Playing back (continued) To clear the resumed point Press again during stop. 2 ) ( 4 ) ( 8 ) ( 16X) ( 32X) It is also cleared when the disc cover is opened. To return to normal playback Press (Play).
  • Page 18 NOTE " " Press " " two buttons simultaneously to When using the using with the AC adaptor, access the Factory Menu options. the liquid crystal display is brighter when the power is turned on. When using with the battery pack, the liquid Press "...

  • Page 19: Information About On Screen Display (Osd)

    CHAPTER 5. (OPERATION WITH OSD) Information about On Screen Display (OSD) This unit features OSD Menu Icons showing disc information ( title, chapter, track, number, elapsed playing time, audio/subtitile language, angle, and sound) and player information (repeat play, play mode, marker, etc.). Some icons only show the indicated information.

  • Page 20: Using A Title / Dvd Menu

    Using a Title / DVD Menu Using a Title Menu Using a DVD Menu Some movie discs may contain two or more Some DVDs have unique menu structures titles. If the disc has a title menu recorded called DVD menus. For example, DVDs on it, the TITLE button can be used to select programmed with complex contents provide guide menus, and those recorded with various...

  • Page 21: Changing Audio Soundtrack Language

    Changing Audio Soundtrack Language It is possible to change the audio soundtrack language (or encoding method, channel number) to a different language from the one selected at the initial setting in case of DVD disc. This operation works only with discs on which multiple audio soundtrack languages are recorded. And it is possible to change the audio channel in case of audio CD.

  • Page 22: Repeat Play

    Repeat Play Repeat viewing (listening) Press REPEAT during playback. Each time this button is pressed, the disc will repeat a chapter or title (DVD) or a track (CD/Video CD). Repeating viewing(listening) Press REPEAT during playback. Each time this button is pressed, the LCD screen changes as shown below and the disc will repeat a chapter or title (DVD) or a track (CD/Video CD).

  • Page 23: Zoom Feature

    Zoom Feature Zoom feature (DVD and Video CD only) The Zoom function allows you to enlarge the video image and to move through the enlarged image. Press ZOOM during playback or still playback to activate the Zoom function. Each time this button is pressed, the enlarged image changes as followed: 2X 3X 4X 1/2X 1/3X 1/4X restore image's normal size.

  • Page 24: What Is Wma

    What is WMA WMA, short for Windows Media Audio, is also a digital audio files similar to a MP3. WMAs are more efficient than 3s because they can be compressed to an even smaller size than 3s. This simply means that a WMA takes up less space on your computer like a MP3 but only works with Windows Media player.

  • Page 25: Chapter 6. (Initial Settings)

    CHAPTER 6. (INITIAL SETTINGS) Changing setup values Use the Setup Menu display to change the system configuration. In this section, each item on the Setup Menu display will be described. Use " "buttons to select the item you want and press " PLAY" or "ENTER" button to confirm. General Setup Page TV Display: The type of TV display(4:3 or 16:9) connected to the...

  • Page 26: Audio Setup Page

    Changing setup values (continued) Audio setup options should only be changed Audio Setup Page if the DVD player is connected to a LEFT or RIGHT surround sound processor. Speaker Setup Downmix: Switches the mixing down methods wh en yo u pla y a DVD with rear signal components.

  • Page 27: Video Setup Page

    Changing setup values (continued) Equalizer EQ Type: There are 7 types of EQ setting.You may select the favorite sound effect depending on the playing disc. Bass Boost: Enable the "Bass Boost" function. Super Bass: Enable the "Super Bass" function. This function only works when "Bass Boost" is on. Equalizer Treble Boost : Enable the "Treble Boost"...
  • Page 28 Changing setup values (continued) Sharpness: There are three selective items: High, Medium and Low. Press " " to select which item you want to set. Press PLAY or " ENTER" to confirm. Brightness: Press PLAY or "ENTER" to enter Brightness setup window.

  • Page 29: Preference Page

    Preference Page TV Type : Press " " to select "TV Type". Select the TV type according to the TV set. (Including NTSC, PAL and Multi.) PBC : Playback control. This is the function especially for VCD. Press "PBC" (On) to allow to program selected chapter.

  • Page 30: Password Setup Page

    Password Setup Page Password Mode: Press " / " to select "Password Mode" to"On" or "Off". Password : The initial factory setting for "Old Password" is 123456 . You need to enter this number if you want to change the password. Note: Do not forget your password.

  • Page 31: Connecting To A Wide Tv/ An Av Tv

    CHAPTER 7. (CONNECTION) Before connecting Turn off the power of this unit and the equipment to be connected. Refer to the instructions for the equipment to be connected. Connecting to a wide TV/ an AV TV VOLUME PHONE/OPTICAL AUDIO VIDEO S-VIDEO To VIDEO OUT jack To AUDIO OUT jack...

  • Page 32: Connecting To An Audio Equipment

    Connecting to an audio equipment VOLUME PHONE/OPTICAL AUDIO VIDEO S-VIDEO To audio input jacks To AUDIO OUT jack Audio connecting cable(supplied) Connecting to an active speaker system VOLUME PHONE/OPTICAL AUDIO VIDEO S-VIDEO To audio input jacks EARPHONE/OPTICAL Optical Audio connecting cable( optional...

  • Page 33: Output Sound From The Optical Output Terminals Of This Unit

    Output sound from the optical output terminals of this unit Playing disc Audio recording system Output audio signals Dolby digital (AC-3) Bit stream of Dolby digital (AC-3) (2ch-5.1ch) PCM (48kHz/16bit) (2ch)*1 Select it in the initial setting "Digital output". Linear PCM 48kHz/96kHz Linear PCM (48kHz/16bit) (2ch)*2 16/20/24 bit Bit stream of Dolby digital...

  • Page 34: Chapter 8. (Others)

    CHAPTER8. (OTHERS) Troubleshooting If something seems to be wrong with your DVD player, first check the items in the table below. Pictures are distorted during forward / back- General ward search. The power does not turn on. This is not a malfunction. Connect the AC adapter correctly or insert the battery pack correctly.

  • Page 35: Language Codes

    Troubleshooting (continued) Remote control The remote control does not work. Make sure the battery is inserted with the correct polarity. If the battery has very little power, replace it with new one. Point it toward the remote sensor. Operate it within 5 meters from the remote The DVD player is a piece of precision sensor.

  • Page 36: Explanation Of Terms

    Explanation of terms Interactive DVD Linear PCM audio( LPCM) With this DVD disc, the story is changeable by This is the signal recording system for audio CD. user's selection, and/or the direction of view is While the signals are recorded by 44.1 kHz/16 changeable.
