- Page 1 JuiceRack & JuiceBlock 50 0 ser ies P o wer Sup plies Operating Manual V 1.1...
-
Page 2: Table Of Contents
3.2 Mains Voltage ......................5 4 Module Installation ......................5 5 Power up ......................... 6 6 Juicerack 1 ........................6 7 Juicerack 3 & Juiceblock3 .................... 6 7.1 Audio Routing: ......................6 8 Juicerack 8 ........................7 8.1 Audio Routing: ......................7 9 Removal of Modules ...................... -
Page 3: Safety Instructions
500 series modules. Hot Swapping, (exchanging of 500 series modules with the power on) is NOT recommended. If the Juicerack/Juiceblock power is on whilst exchanging modules, the pins on the modules edge connector may short and burn the regulator. For this reason, hot swapping of modules is not covered under the SM Pro Audio warranty. -
Page 4: Foreword
Dear Customer, Thank you very much for expressing your confidence in SM ProAudio products by purchasing this unit. Our 500 series power supplies have been designed for use as a standard tool for home/pro studios, P.A. rental companies, Schools and in many other situations where audio products would be used. -
Page 5: Introduction
Mains Voltage Juicerack 8 can be used with voltages ranging from 100V AC to 250V AC. Please make sure that you have selected the correct voltage on the rear voltage switch before switching the unit ON. Any damage occurring as a result of incorrect voltage selection may not be granted a warranty repair. -
Page 6: Power Up
JuiceRack1 is a single-slot power source for operating one 500-series module. It is a half-rack format, and includes a connector that allows two Juicerack 1’s to be mounted into a 1 ru 19” rack. The external AC power supply design, keeps the power transformer separated from your 500 module’s sensitive electronics, and ensures reduced hum and signal interference. -
Page 7: Juicerack 8
8 Juicerack 8 JuiceRack 8 is a 19” rack-mount power source designed to house up to eight 500-series single slot modules in a vertical configuration. The rear panel sports eight slots of balanced XLR inputs and outputs along with eight slots of unbalanced 1/4” inputs and outputs. - Page 8 The signal then flows (LINKS) through to module 6 (with NO processing from inputs 3, 4 & 5) then gets processed in module 6 and outputs to (FEEDS) module 7. (got that?) SM Pro Audio Page 8 of 11 Juicerack / Juiceblock manual ...
-
Page 9: Removal Of Modules
9 Removal of Modules The Juicerack 1 and Juicerack 3 have small slots in the top of the chassis that allows the removal of modules. After unscrewing the module, this is done using a small straight head screwdriver, which can be inserted into the top slot and pushed forward to release the module. -
Page 10: Claim For Damages
This warranty does not exclude or limit the buyer‘s statutory rights provided by national law, in particular, any such rights against the seller that arise from a legally effective purchase contract. SM Pro Audio Page 10 of 11 Juicerack / Juiceblock manual ... -
Page 11: Fcc And Ce Regulation
SM Pro Audio. ALL RIGHTS RESERVED © 2013 SM Pro Audio SM Pro Audio Page 11 of 11 Juicerack / Juiceblock Manual ...
