Palstar AA30 Owner's Manual

Active antenna

Table of Contents

Download this manual

Enlarged version

AA30 Active

Palstar Incorporated

Antenna

9676 N. Looney Rd.,

Piqua, OH 45356 USA

Customer Service and Sales Telephone:

1-800-773-7931

Fax:

1-937-773-8003

Owner's Manual

Email:

info@palstar.com

Printed in the U.S.A.

REV 2.1 03.18.2009

Table of Contents

Need help?

Do you have a question about the AA30 and is the answer not in the manual?

Page 1 AA30 Active Palstar Incorporated Antenna 9676 N. Looney Rd., Piqua, OH 45356 USA Customer Service and Sales Telephone: 1-800-773-7931 Fax: 1-937-773-8003 Owner’s Manual Email: info@palstar.com © Copyright 2010 Palstar Inc. Printed in the U.S.A. REV 2.1 03.18.2009...
Page 2: Specifications
AA30 Active Antenna Description: When sending in a product for service, Limited Warranty The AA30 Active Antenna is designed for the avid SWL please “double” box it carefully and Palstar Inc. warrants products manu- ship it insured for your protection.
Page 3 Front Panel AA30 Schematic 1. Telescoping Whip Socket. Insert Telescoping Whip into this hole and screw it down until it is snug. Be care- ful when starting so not as to cross-thread the fittings. (Do not mount telescoping whip if you are using an ex- ternal wire antenna.
Page 4 3. Select the power source with the switch on the back. 4. Connect the AA30 output to the antenna jack of your re- ceiver. 5. Select the frequency range you wish to use with the Band Switch (number 6, page 3), and set the Gain Control (number 1.
