OWNER'S MANUAL
MODEL TC-5000
Please read carefully before using this equipment
Treasure Cove
Gold Rush Metal Detector

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Treasure Cove TC-5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gold Rush Treasure Cove TC-5000

  • Page 1 OWNER’S MANUAL MODEL TC-5000 Please read carefully before using this equipment Treasure Cove Gold Rush Metal Detector...
  • Page 2 With your new Gold Rush TC-5000 metal detector, you can easily hunt for coins, relics, jewelry, gold and silver just about anywhere. Your TC-5000 allows you to search in almost any location, including lawns, fields, snow-filled areas, mountain trails and beaches. The TC-5000 metal detector is versatile and easy to use.

  • Page 3: Assembling The Detector

    PREPARATION ASSEMBLING THE DETECTOR Assembling your detector is easy and requires no special tools. Just follow these steps: Search coil Lower shaft Main box cable Handle Arm support Lock nut Fixing knob S shaft Loosen the fixing screws and take off the main box (operating console).

  • Page 4: Installing The Batteries

    Fix the main box on the S shaft and tighten the screws properly (shown as below). Loosen the lock nut counter-clockwise on the S shaft. Insert the lower shaft into the S shaft and tighten the lock nut. Align the holes on the search coil bracket with the lower shaft. Push the connector through the holes, then replace and tighten the fixing knobs.

  • Page 5: Using Headphones

    (+ and -) marked on the inside of the compartment, then reinstall the left battery cover. Slide the battery cover on the right off in the direction the arrows point. Place a 9V battery into the battery compartment matching the polarity symbols (+ and -) marked on the inside, then reinstall the right battery cover.

  • Page 6: A Quick Look At The Detector

    hearing loss. Do not wear your headphones while operating your metal detector near  high-traffic areas. Pay attention to traffic safety. A QUICK LOOK AT THE DETECTOR MODE SWITCH DISC-The mode DISC facilitates searching for and discriminating the  target type based on the long or short tone for different metal targets. ALL METAL- This mode is used to search for all kinds of metal objects.

  • Page 7: Operation

    OPERATION Your TC-5000 has three operation modes: DISC, ALL METAL and TARGET. The DISC and ALL METAL modes are motion modes. You have to move the search coil to locate a target. While the TARGET mode is a non-motion mode.
  • Page 8 can use the TARGET mode to pinpoint the target. Then use DISC or TONE modes to determine whether the target is worth digging out. The followings are the four operation modes in detail. 1. ALL METAL- Is the general searching mode. In this mode, the metal detector will respond with a high-pitch tone to all metal objects.
  • Page 9 mode to DISC to determine which kind of metal the target is. 4. Notes: (1) If there is interference from similar metal detectors in the area you are searching, you can either lower the sensitivity level on the main box or change the location of the area you are currently searching.

  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE Your metal detector is an example of superior design and craftsmanship. The following care instructions will help you maintain your metal detector so you can enjoy it for years. Handle the metal detector gently and carefully. Dropping it can damage the circuit board and in some cases cause the metal detector to work improperly.
