TW-3G Router

(USB interface)

Wireless access Point

802.11b/g/n 300 Mbps

User Guide

Table of Contents

Need help?

Do you have a question about the TW-3G Router and is the answer not in the manual?

Questions and answers

Summary of Contents for TeleWell TW-3G Router

Page 1: User Guide
TW-3G Router (USB interface) Wireless access Point 802.11b/g/n 300 Mbps User Guide...
Page 3: Table Of Contents
INDEX 1. I NTRODUCTION ...................... 4 1.1. P ackage c ontents .............................. 4 1.2. F eatures .................................. 5 1.3. S ystem r equirements f or c onfiguration ...................... 5 1.4. ...
Page 4: Introduction
When used as backup connection, in case of main WAN xDSL connection failure device can automatically connect to 3G or Flash-OFDM network. 1.1. Package contents TW-3G Router package should contain the items listed below. If any of the items are missing, please contact your reseller. • TW-3G Router •...
Page 5: Features
• Connects multiple computers to a Broadband either WCDMA or EV-DO even HSDPA modem to share the Internet connection. Note: TW-3G Router is designed to work with either EVDO or WCDMA (UMTS) even up to 3.5G HSPA PC interface. Please refer to your service provider for detailed feature information.
Page 6: Rear Ports
1.4. Rear ports WAN port for ADSL cable LAN 1-4 LAN ports for Ethernet cables USB port for connecting with 3G USB modem POWER Receptor for Power adapter 1.5. Front LEDs Mobile Green light as 3G card is connected and ready LAN 1-4 Green light as connected to local Ethernet and blinks during data transmission...
Page 7: Configuring Tw-3G Router
RF (radio frequency) noise in your home or business. To maximize your wireless range, please follow these guidelines: 1. Keep the number of walls and ceilings between the TW-3G Router and other network devices to a minimum. Each wall or ceiling can reduce the TW-3G Router’s range from 3-90 feet (1-30 meters).
Page 8 3. Connect the power adapter to the receptor on the back panel of your TW-3G Router. Then plug the other end of the power adapter into a wall outlet or power strip.
Page 9: Establishing Wan Connection
1. Open a web-browser. 2. Type in the IP Address (http://192.168.0.254) of the TW-3G Router Note: If you have changed the default IP Address assigned to the TW-3G Router, ensure you enter the correct IP Address now. 3. The default language of the web GUI is English. You can change the language settings after logging in.
Page 10 5. From the left sidebar you can choose between Settings wizard (chapter 3) or modifying all settings separately (chapter 4) 6. At the top right corner you can also find shortcuts to quick start, firmware upgrade and system log.
Page 11: Settings Wizard
3. SETTINGS WIZARD With wizard setting steps, you could configure the router in a very simple way. This configuration wizard includes settings of Login Password, Time Zone Setup WAN Setup Wireless Setup, Press “Next” button to start configuration. Step 1: Allow you to change the system password. It is recommended that you change the system password into the one you prefer to on the basis of security •...
Page 12 Step 2 Setting up the Time Zone • Your TW-3G Router automatically detect the right Time Zone, if not press “Detect Again” to let router automatically search the right Time Zone • You can also select the right Time Zone from the dropdown menu...
Page 13 Step 3 If chosen Setup WAN type manually, configure the WAN settings • LAN IP Address: Change your LAN IP Address (Default is 192.168.0.254) • WAN Interface: Select your WAN type from dropdown menu, Wireless or Ethernet • WAN Type: Select WAN type for WAN Interface. ->...
Page 14 Step 3 Configuring 3G Dial-Up Profile manually • Country: Select your country from dropdown menu • Telecom: Select your 3G operator from dropdown menu • 3G Network: Select the right 3G network from dropdown menu • APN: Enter the APN for your 3G modem here. •...
Page 15 Step 3 If chosen Ethernet WAN and Static IP Address, configure the Static IP Address settings Write used IP address, Subnet Mask, Gateway, Primary DNS and • Secondary DNS on reserved fields -> Next Step 3 If chosen Ethernet WAN and Dynamic IP Address, configure the Dynamic IP Address settings •...
Page 16 Step 4: Configure the wireless settings. • Select Enabled or Disabled. The default setting is Enabled. • Network ID (SSID) will be as a default TW-3G_ofdm_router. It is recommended that you change the SSID for making it easier to identify. •...
Page 17 • WEP: Choose between 64 / 128 bits, and hexadecimals / ASCII 64 bits + HEX= 10 numbers 128 bits + HEX= 26 numbers 64 bits + ASCII= 5 letters or numbers 128 bits + ASCII= 13 letters or numbers Type your WEP password in ”Key 1”...
Page 18 Step 6: Summary Make sure that the settings are correctly. By clicking ”Back” you can go back to change the settings. -> Apply Settings Once settings have been saved the router will notify you “Configuration is completed. Please click “finish” to back to status page.” ->...
Page 19: Additional Settings
4. ADDITIONAL SETTINGS You may first edit the settings with Settings Wizard (chapter 3), and then, if necessary, adjust them from the additional settings menu at the left sidebar. Each link opens up a submenu with further options. Status: Summary, 3G status, Wireless Status, System Logs, Statistics – section 4.1 Main settings: Quick Start, DHCP Server, Wireless, Change Password –...
Page 20: Status
4.1. Status Summary- page presents a summary of the router's status. Separate tables of each topic can be found under links 3G Status, Wireless Status and Statistics. System Logs -link is a shortcut to system logs. 4.2. Main Settings Main Settings > Quick Start Select the WAN types you prefer to get on the internet connection Example for Flash-OFDM connection •...
Page 21 Example for 3G connection Please refer to your documentation or service provider for additional information. • Choose "3G" from the WAN Type dropdown –menu • Dial-up Profile: If you want to set up Dial-up Profile manually select “Manual” (Default is Auto-Detection) •...
Page 22 Connection Control: is auto reconnect and always on by default. You • can disable it, if desired. • AT Command: leave empty if not required • Allowed Connection Time: Always is default. • Keep Alive: Here you can change your keep alive settings. ->...
Page 23 Example for ADSL connection (Dynamic IP Address) • Choose the Dynamic IP Address option from the WAN Type dropdown – menu • Activate WWAN for Auto-Failover: If desired, you can Enable WWAN for Auto-Failover, and setup wanted Remote Host for keep alive. •...
Page 24: Main Settings > Dhcp Server
Main Settings > DHCP Server • DHCP Server: Choose either Disable or Enable • IP Pool Starting/Ending Address: Whenever there is a request, the DHCP server will automatically allocate an unused IP address from the IP address pool to the requesting computer. You must specify the starting / ending address of the IP address pool •...
Page 25: Main Settings > Wireless
• Primary WINS/Secondary WINS: This feature allows you to assign a WINS Servers • Gateway: The Gateway Address would be the IP address of an alternate Gateway. This function enables you to assign another gateway to your PC, when DHCP server offers an IP to your PC. ->...
Page 26: Main Settings > Change Password
• Security: Wireless network security is enabled by default (default key: 1234567890). Either WPA-PSK or WPA2-PSK are recommended. They perform better than WEP. • WPA-PSK / WPA2-PSK: Choose encryption type, TKIP or AES. With WPA- PSK you should choose TKIP-encryption, with WPA2-PSK-you should choose AES-encryption.
Page 27: Forwarding Rules
4.3. Forwarding Rules Forwarding Rules > Virtual Server This product’s NAT firewall filters out unrecognized packets to protect your Intranet, so all hosts behind this product are invisible to the outside world. If you wish, you can make some of them accessible by enabling the Virtual Server Mapping.
Page 28: Forwarding Rules > Miscellaneous
Forwarding Rules > Miscellaneous IP Address of DMZ Host DMZ (Demilitarized Zone) Host is a host without the protection of firewall. It allows a computer to be exposed to unrestricted 2-way communication for Internet games, Video conferencing, Internet telephony and other special applications. NOTE: This feature should be used only when needed.
Page 29: Security Settings
4.4 Security Settings Security Settings > Packet filters Packet Filter enables you to control what packets are allowed to pass the router. Outbound filter applies on all outbound packets. However, inbound filter applies on packets that are destined to Virtual Servers or DMZ host only.
Page 30: Security Settings > Domain Filters
For source or destination port, you can define a single port (80) or a range of ports (1000-1999). Add prefix "T" or "U" to specify TCP or UDP protocol. For example, T80, U53, U2000-2999, No prefix indicates both TCP and UDP are defined. An empty implies all port addresses. Packet Filter can work with Scheduling Rules, and give user more flexibility on Access control.
Page 31: Security Settings > Url Blocking
Security Settings > URL Blocking URL Blocking will block LAN computers to connect to pre-defined Websites. The major difference between “Domain filter” and “URL Blocking” is that Domain filter requires user to input suffix (like .com or .org, etc), while URL Blocking requires user to input a keyword only.
Page 32: Security Settings > Mac Control
Security Settings > MAC Control MAC Address Control allows you to assign different access rights for different users and to assign a specific IP address to a certain MAC address. • MAC Address Control: Check “Enable” to enable the “MAC Address Control”.
Page 33: Security Settings > Pptp Client
Security Settings > PPTP Client You can set the router to connect to the PPTP server via PPTP client programme. • Enable PPTP client by clicking on the enable box. • Enable each server by clicking on the enable box on that line. •...
Page 34: Security Settings > Pptp Server
Security Settings > PPTP Server VPN gateway may serve also as a PPTP server, and allows for wireless access to the network after establishing a PPTP connection with it. The router supports three authentication protocols: PAP, CHAP, MSCHAP(v1) and MSCHAP(v2). If using MSCHAP-protocol, you may also enable MMPE security.
Page 35: Security Settings > Miscellaneous
Security Settings > Miscellaneous Remote Administrator Host/Port In general, only Intranet user can browse the built-in web pages to perform administration task. This feature enables you to perform administration task from remote host. If this feature is enabled, only the specified IP address can perform remote administration.
Page 36: Advanced Settings
4.5 Advanced Settings Advanced Settings > System Log This page supports two methods to export system logs to specific destination by means of syslog (UDP) and SMTP(TCP). • IP Address for Syslog: Host IP of destination where syslog will be sent to. •...
Page 37: Advanced Settings > Dynamic Dns
Advanced Settings > Dynamic DNS To host your server on a changing IP address, you have to use dynamic domain name service (DDNS). So that anyone wishing to reach your host only needs to know the name of it. Dynamic DNS will map the name of your host to your current IP address, which changes each time you connect your Internet service provider.
Page 38: Advanced Settings > Qos
Advanced Settings > QoS QoS feature allows you to set priorities to different IP addresses, and thus limit their speed. • Enable QoS by clicking on the enable box • Define preferred upstream bandwidth speed. This can not be defined as 0. •...
Page 39: Advanced Settings > Snmp
Advanced Settings > SNMP In brief, SNMP, the Simple Network Management Protocol, is a protocol designed to give a user the capability to remotely manage a computer network by polling and setting terminal values and monitoring network events. • Enable SNMP: You must check either Local or Remote or both to enable SNMP function.
Page 40: Advanced Settings > Routing
Advanced Settings > Routing Routing Tables Allow you to determine which physical interface address to use for outgoing IP data grams. If you have more than one routers and subnets, you will need to enable routing table to allow packets to find proper routing path and allow different subnets to communicate with each other.
Page 41: Advanced Settings > System Time
Advanced Settings > System Time • Time Zone: Select a time zone where this device locates and router automatically adjusts its clock to right time. • Press “Sync with Time Server” if you want to synchronize your router’s clock with time server or press “Sync with my PC” if you want to synchronize your router’s clock with your PC.
Page 42: Advanced Settings > Scheduling
Advanced Settings > Scheduling You can set the schedule time to decide which service will be turned on or off. Select the “Enable” item. Press “New Add” You can write a rule name and set which day and what time to schedule from “Start Time”...
Page 43: Tools
4.6 Tools Tools > System Info You can view the System log and Routing Table information in this page. With “<<Previous”, “Next>>”, “First Page” and “Last Page” buttons you can browse system logs. If desired, you may empty the system log by clicking on clear-logs button.
Page 44: Tools > Firmware Upgrade
Tools > Firmware Upgrade Newest firmware upgrade files can be found on our web page http://www.telewell.fi. Save the file on your computer, and then search for it on this page. Clicking on the upgrade button will update your firmware. You may also upload a previously saved settings file in the same way.
Page 45: Tools > Miscellaneous
Tools > Miscellaneous MAC Address for Wake-on-LAN Wake-on-LAN is a technology that enables you to power up a networked device remotely. In order to enjoy this feature, the target device must be Wake-on-LAN enabled and you have to know the MAC address of this device, say 00-11-22-33-44-55. Clicking "Wake up"...
