- Page 1 Falcon User Manual...
-
Page 2: About Daymak
Daymak warranties, services, and stocks parts for everything it sells. We support our prod- ucts. Please feel free to visit our website. You’ll nd the latest in cool transportation solutions,... -
Page 3: Table Of Contents
Table of Contents Introduction..............................4 Part Diagrams ..............................5 Product Speci cations ..........................6 Components..............................7 Operating Instructions ..........................10 Operational Conditions and Maintenance ..................11 Parts Replacement Schedule........................12 Annex 1 ................................13... -
Page 4: Introduction
Canadian provincial regulations that govern e-bikes. Liability Daymak does not assume any liability for damages, loss of pro ts, or claims from third parties due to improper use of this product. Daymak does not assume any liability for dam- ages due to problems with the product resulting from service by a third party that is not certi ed by Daymak. -
Page 5: Part Diagrams
Part Diagrams Diagram 1: The Falcon This diagram illustrates the various parts of your Falcon. Please note that many of these parts are not us- er-serviceable and should be repaired only by trained professionals. This is especially true of the electrical systems and the mechanical components. -
Page 6: Product Speci Cations
Product Specifi cations Max Speed 20 km/h Battery Lithium Battery Range (from full charge) 55 km Minimum Turning Radius Zero (turns on the spot) Optimum Tire Pressure 1.0Bar/100kPa/15psi Vehicle Weight 55 kg Vehicle Footprint 65 x 49 cm Chassis Height 10.0 cm Handlebar Height 90 ~120 cm (adjustable) -
Page 7: Components
Components Handlebar The handlebar maintains balance and controls the direction of the vehicle. The front and rear of the handlebar is shown below. The height of the handlebar can be adjusted to suit the rider: Warning The handlebars cannot tilt in excess of 45 left or right around the axis point. - Page 8 Display lights in- dicate whether the Falcon is on high speed or low speed. The battery indicator consists of 6 lamp lights, all of which gradually turn o as the battery is drained. If only a single lamp light on the battery indicator is lit, it is a good idea to charge the battery.
- Page 9 Battery The battery provides power to the Falcon. The battery voltage is 70VDC. Do not open the battery compartment or the vehicle’s control panel - you may be subject to electric shock.
-
Page 10: Operating Instructions
Operating Instructions When riding for the rst time or if the Falcon has been in a reclined position for a long time, you must rst initialize the positioner. See Annex 1. To switch on the vehicle, hold the handlebar while standing in the centre near the rear of the vehicle. -
Page 11: Operational Conditions And Maintenance
While riding, if any abnormal sounds are heard, stop the vehicle, dismount, and check the entire vehicle before proceeding. Do not attempt to perform a maintenance check or repair the Falcon. In the event of fail- ure, please bring it to an authorized professional. Unauthorized repairs or any attempted repairs by a non-certi ed professional will invalidate warranties and may incur more re- pair costs. -
Page 12: Parts Replacement Schedule
Parts Replacement Schedule Directional Potentiometer replace annually or for every 1,000 km traveled Handlebar Suspension Gas replace annually or for every 1,000 km traveled Springs replace both tires if tread depth is less than Tires 0.5mm Gearbox oil change oil for every 2,000 km traveled... -
Page 13: Annex 1
