INSTALLATION AND OWNER'S MANUAL

Corona Discharge

CD10 /AD

Ozone generator

Table of Contents

Need help?

Do you have a question about the Corona Discharge CD10 and is the answer not in the manual?

Questions and answers

Summary of Contents for AWE Corona Discharge CD10

Page 1 INSTALLATION AND OWNER’S MANUAL Corona Discharge CD10 /AD Ozone generator...
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS PLEASE FOLLOW ALL INSTALLATION INSTRUCTIONS. A licensed, qualified electrician should make all electrical connections. Before attempting any electrical connections, be sure all power is off at the main circuit breaker. Install the ozone generator at least five feet from the water using nonmetallic plumbing.
Page 3: Uncrating And Inspection
CORONA DISCHARGE (CD) OZONE SYSTEMS Ozone is manufactured in the CD ozone generator by drawing in air, which is composed of 20% oxygen (02), and exposing it to multiple high voltage electrical discharges. This causes the oxygen molecules to dissociate and reassemble as ozone (03). The ozone is drawn into the water by an injector/mixer, killing any bacteria, viruses or mold spores it contacts.
Page 4: Product Description
PRODUCT DESCRIPTION The Advanced Water Engineering, Inc. corona discharge ozone system consists of two main components: • Ozone Generator with built-in Air Preparation • Venturi Injector Manifold Ozone Generator The ozone generator houses the ozone reaction chamber, power supply and all electrical components directly related to the production of ozone.
Page 6 PRODUCT DESCRIPTION (continued) Injector Manifold The ozone gas is injected into the filtered water return line by means of the injector manifold. This allows the ozone to be injected into the water under a vacuum condition, which is the safest technology available.
Page 8: Installation
INSTALLATION Placement of Equipment Select a location for the ozone equipment that is as close as possible to the ozone injection point. Situate the unit in a manner suitable for convenient electrical access. The CD1 0/AD enclosure is not rain proof, so it is important to choose a location that will keep the system away from direct weather and excessive heat.
Page 9 INSTALLATION (continued) SIDE STREAM BOOSTER PUMP AND INJECTOR MANIFOLD PLUMBING CONNECTIONS This alternative set up utilizes a two-inch side stream ozone treatment method. Typically, the feed water for the side stream is pulled from the main filtered water return after the filter, before the heater and returned at a point after all other equipment and before the residual chemical injection point.
Page 10: Tubing Installation
Install the injector manifold after the ozone booster pump, making sure to note the correct flow direction of the injector manifold. The location of the injector manifold and booster pump is dictated by the mechanical blueprints. The check valve assembly is strapped to the injector manifold.
Page 11 SIDE STREAM OZONE INJECTION SYSTEM Typical Commercial Ozone Schematic with Contact Column...
Page 12: Electrical Connections
INSTALLATION (continued) ELECTRICAL CONNECTIONS 0/AD is IMPORTANT: The CD1 capable of accepting input from 90 to 260 volts AC, 43 to 63 hertz (10 only). Installations of 120 or 240 VAC, 50-60 Hz fall within this range. The objective is to have the ozone generator come on whenever the pooi pump comes on for filtration. All local codes must be observed.
Page 14 OZONE GENERATOR OPERATION INITIAL START-UP AND CALIBRATION After the installation has been completed, the water system operating parameters should remain the same as before installation of the ozone generator. The cooling fan will start and the air dryer portion of the unit will begin to produce heat if the unit is functioning properly. The air preparation system on the Advanced Water Engineering, Inc.
Page 15 OZONE GENERATOR OPERATION (continued) INITIAL START-UP AND CALIBRATION (continued) Adjusting Air Flow with the CD1 0/AD Flowmeter Kit (Optional - order Part # GAG4O The other method of adjusting the flow is to add the optional CD1 0/AD Flowmeter Kit. This consists of an SCFH gauge and tubing which is installed permanently on the CD1 0/AD, fitting into the external air preparation access loop fittings.
Page 18: System Running Time
OZONE GENERATOR OPERATION (continued) System Running Time On residential pools, the ozone generator should operate for six to eight hours per day. Normally, the ozone system will run whenever the pool filtration system is operating. Since commercial pool and spa filtration systems normally operate 24 hours a day, the ozone system will run continuously on a commercial pool.
Page 19 Always maintain the recommended residual levels of bromine or chlorine (at least 1 .0 PPM) to help control algae. Brushing poolside once a week is also effective, as is any algaecide. Note: Please consult your AWE, Inc. distributor before using any algaecide Shock Treatment If an unusually high bather load causes cloudiness in the water, it is recommended that a chlorine shock treatment he used to assist the ozone in cleaning the water.
Page 21 MAINTENANCE Filter Care Ozone will keep the water much cleaner than any other type of water purification system. This is due to the fact that ozone neutralizes body oils and soaps. After ozone kills the bacteria, the by-products of the process are oxygen, carbon dioxide and filterable solids.
Page 22 the oven. 6. Return the desiccant granules to the cartridge, recap and reverse the above steps to replace the chamber.
Page 23 CD10/AD MAINTENANCE & TROUBLE SHOOTING MANUAL PARTS & WARRANTY...
Page 29: Limited One-Year Warranty
1) The warranty period shall begin on the installation date if the installation is performed within 90 days of the original shipment from AWE,INC; 2) The warranty period shall begin on the date of the bill of sale to the end user if the installation date is more 90 days after the original shipment date.
Page 30 AWE, INC direct at (321) 777-4909. Exclusive Warranty There is no other expressed warranty on AWE, INC products and/or parts. Neither this warranty, or any other warranty, expressed or implied, including any implied warranties or merchantability of fitness, shall extend beyond the warranty period.
