RLH Industries 10M ETHERNET User Manual

USER GUIDE
Ethernet Over Fiber
4RU Plug-in Card
10/100/1000M ETHERNET
Introduction
The RLH 10/100/1000 Ethernet 4RU Interface Card converts a
copper 10Base-T or 100/1000Base-TX to a 1000Base-SX/LX
fiber optic transmission signal of either multimode or single-
mode. The cards transmit the data signals over fiber optic
cable which allow for network extension over long distances,
and provide electrical isolation between both ends of the
network.
The Ethernet over fiber card may be used as a system, with a
card at each end, or the fiber optic cable may be connected
directly to any 1000Base-SX/LX compatible device.
This hardened, rugged system is covered by our Exclusive
Unconditional Lifetime Warranty.
Key Features
• Ideal for critical, high voltage, remote or un-manned
locations that must remain operating 24/7/365
• Compatibility with IEEE 802.3/AB
• RJ45 UTP port with 10/100/1000 auto-negotiation
• Extends network span up to 1.2 miles (2km) on multimode and
up to 74 miles (120km) on single-mode fiber
• Convenient LED status indicators
• Link alarm function for status monitoring
• Dual and Single (bi-directional) fiber models available
• Environmentally hardened to operate in -40°F to +158°F
(-40°C to +70°C) environments
• Standard RLH 4RU form factor
• Covered by our Exclusive Unconditional Lifetime Warranty
RLH Industries, Inc.
RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com
The leader in
rugged fiber optic
technology.
RLH 10/100/1000 Ethernet over Fiber Card
Contents
Introduction _________________________
General Safety Practices _________________
Special Handling Requirements
Acronyms ___________________________
Applications _________________________
Installation __________________________
LED Indicators _______________________
DIP Switch Settings _____________________
Link Alarm __________________________
Ordering Information __________________
General Specifications ___________________
Troubleshooting _______________________
Warranty ___________________________
Technical Support _____________________
Specifications subject to change without notice.
 Unconditional
Lifetime Warranty
2012D-1105
1
2
____________ 2
3
3
4
5
5
6
6
7
8
8
8
Page 1
