  • Page 1 Version 1.0 XDS1 V2 CD/SACD PLAYER OWNER’S MANUAL © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 2: Welcome

    Welcome XDS1 V2 CD/SACD PLAYER OWNER’S MANUAL ank you for choosing EMM Labs... © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 3: Table Of Contents

    Front Panel & Functions Rear Panel & Functions Connecting and Operation Infrared Remote Control Appendix A - Serial Remote Control (RS232) © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 4: Safety Instructions

    EEC: This product has been designed and tested to comply with the limits set out in EN55013, EN55020 and EN 60065:2009 (electrical safety). © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 5: Information To The User 005

    User Alteration or modi cation carried out without appropriate approval may invalidate the user’s right to operate the equipment. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 6: Warranty 006

    EMM Labs product purchased from non-authorized dealers or from a dealer selling outside his / her authorized territory will automatically void product warranty. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 7: Xds1 V2 Cd/Sacd Player

    XDS1 V2 is the culmination of years of research and development resulting in EMM Labs nest all in one CD/SACD player to date. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 8: Features & Specifications

    • USB also supports DSD streaming Digital Outputs: • AES/EBU (XLR) PCM digital audio output for CD and SACD • EMM Labs OptiLink © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
  • Page 9 • Power consumption: 45W General • Dimensions W x D x H: 435 x 400 x 145mm • Weight: 17kg © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 10: Front Panel & Functions

    4. XDS1 V2 Front Panel Buttons and Indicators: • -> SOURCE: Toggles between CD/SACD playback, AES, TOSLINK, COAXIAL and USB inputs. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
  • Page 11 In this mode pressing the NEXT button immediatly a second and third time causes the forward speed to increase. To exit press PLAY. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 12: Rear Panel & Functions

    Warranty void if model/serial number indicator is not attached to unit, missing or damaged whereby serial number cannot be seen. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
  • Page 13 RESET button used to temporarily access the backup rmware. • Only for diagnostic purposes. Should not be used during normal operation. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 14: Connecting And Operation

    © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
  • Page 15 6. Kernal, ASIO and WASAPI (Vista and Windows 7) drivers will be installed. *Not using proper cables will cause audio issues between digital source and DAC. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
  • Page 16 5. When setup correctly and DSD data is detected, the XDS1 V2 will display DSD on its front display window as the digital audio format. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 17: Infrared Remote Control 017

    To exit press PLAY. © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
  • Page 18 Toggles polarity inversion performed in the digital domain. MUTE Mutes the XDS1 V2 analog outputs. MODE REPEAT PLAY PAUSE STOP TRACK PHASE MUTE © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.

  • Page 19: Appendix A - Serial Remote Control (Rs232) 019

    Toggles through the SACD playback layers. Only works when not playing. Toggles through the di erent repeat modes Jumps ahead a track Jumps back a track © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
  • Page 20 Byte 1 Seconds tens in ASCII Byte 2 Minutes ones in ASCII Byte 3 Minutes tens in ASCII Byte 4 Hours ones in ASCII © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
  • Page 21 5 - Not used bit 6 - 1 when in pause bit 7 - 1 when clock is locked Byte 9 <CR> (x0D) © 2013 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
