Hubbell TD300 Specifications

Hubbell TD300 Specifications

Digital programmable timer

Advertisement

Quick Links

Digital Programmable Timer
KEY FEATURES
• Supports multiple timer intervals
• Energy code presets for Title 24, IECC, and ASHRAE 90.1
• Visual and audible turnoff warning
• 3 Way and Multiple Way Switching
• No Neutral Required
• No Load Requirement
• Dip switch control of features
• Zero Arc Point Switching
• UL and cUL listed
• Five-year warranty
OVERVIEW
With its aesthetically pleasing features, the TD300 combines style with functionality as it provides energy saving control of in-
candescent and fl uorescent lighting, as well as certain motor loads such as fans, hot tub heaters and circulating pumps. The timer
offers two presets for energy code compliance – two hour timing for Title 24 and IECC and 4 hour timing for ASHRAE 90.1. A
timed override allows lights and HVAC (heating, ventilating and air conditioning) to remain on for a specifi ed amount of time for
after-hours cleaning crews. The TD300 is easy to install and can replace any wall switch.
FEATURES and BENEFITS
Features
Energy Code Presets
Supports multiple timer intervals
Timed manual override option
Visual and audible warnings
Zero Arc Point Switching
Hubbell Building Automation, Inc.
Benefi ts
• 2 hour timer for Title 24 and IECC
• 4 hour timer for ASHRAE 90.1
• A turnoff timer can be set in the following intervals
• A button push keeps lights and HVAC on past the preset
• Adjustable to accommodate lighting for after-hours cleaning
• Provides one second fl icker or beep warning:
• Provides support for any lighting load, such as:
|
9601 Dessau Road
|
Building One
hubbell-automation.com
5.2013
TD300
- 5 minute steps between 5 minutes – 1 hour
- 10 minute steps between 1-4 hours
- 30 minute steps between 4-12 hours
-1 hour steps between 12-24 hours
turnoff for a specifi ed amount of time
crews
- Flicker warning is at two minutes before the turnoff
- Beep warning starts two minutes before turnoff
and continues every fi fteen seconds
- Electronic ballasts
- Incandescent lighting
- Motor loads (the maximum electrical loads for a circuit)
|
Austin, Texas 78754
|
{512} 450-1100
|
{512} 450-1215 fax

Advertisement

loading
Need help?

Need help?

Do you have a question about the TD300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hubbell TD300

  • Page 1 OVERVIEW With its aesthetically pleasing features, the TD300 combines style with functionality as it provides energy saving control of in- candescent and fl uorescent lighting, as well as certain motor loads such as fans, hot tub heaters and circulating pumps. The timer offers two presets for energy code compliance –...
  • Page 2: Specifications

    Certifi cations • UL and cUL listed Warranty • Five years ORDERING INFORMATION TD300 MODEL COLOR TD300 W White. Digital Programmable Timer Hubbell Building Automation, Inc. 9601 Dessau Road Building One Austin, Texas 78754 {512} 450-1100 {512} 450-1215 fax hubbell-automation.com...
