NEX-FS700R
Full-HD Super Slow Motion NXCAM Camcorder
A new multi-purpose camcorder offering exceptional image
quality ready to maximize your creative potential as a producer.
Sony's NEX-FS700R is an interchangeable lens camcorder capable of capturing super slow motion images in
Full HD at 240fps. It features an 11.6M Exmor Super35mm CMOS sensor, the latest large format sensor, boasting
high-speed readout and outstanding sensitivity. And thanks to the E-mount system, as well as Sony lenses, using a
mount adapter lets you attach various other interchangeable lenses for extra shooting flexibility. A motorized zoom
lens that covers a focal range from 18mm to 200mm (35mm equivalent, 30.6-340mm) is also provided as standard.
This lets you enjoy smooth zooming for expressive results that are difficult to achieve with manual operation.
Other valuable features supporting professional video production include a built-in ND filter, a 3G HD-SDI out, an
XLR audio input and simultaneous recording with a memory recording unit. Taking full advantage of the Exmor
Super35mm CMOS sensor's capabilities, 4K recording is also possible with an optional interface and recorder
(HXR-IFR5/AXS-R5). In addition to high-definition 4K recording, continuous shooting with 2K resolution at 240fps is
possible with no time limit.
The NEX-FS700R is a camcorder designed to provide everything professionals need for more creative freedom
when shooting in the field.
* The HXR-IFR5 interface unit, the AXS-R5 RAW recorder
and the battery are shown on the right of the photo.
These are option for 4K recording.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEX-FS700R and is the answer not in the manual?

Questions and answers

Related Manuals for Sony NEX-FS700R

Summary of Contents for Sony NEX-FS700R

  • Page 1 Full HD at 240fps. It features an 11.6M Exmor Super35mm CMOS sensor, the latest large format sensor, boasting high-speed readout and outstanding sensitivity. And thanks to the E-mount system, as well as Sony lenses, using a mount adapter lets you attach various other interchangeable lenses for extra shooting flexibility. A motorized zoom lens that covers a focal range from 18mm to 200mm (35mm equivalent, 30.6-340mm) is also provided as standard.
  • Page 2 240 fps in 1920 x 1080 High Speed Shooting Thanks to the high-speed image data reading characteristics of the new Exmor Super35 CMOS sensor, the NEX-FS700R can capture full-HD images (1920 x 1080) at 120 or 240 fps of burst recording in 60Hz shooting mode. Using playback at 24 fps, the camcorder can simply and beautifully realize a maximum quality of full-HD 10x super slow motion pictures.
  • Page 3 High Speed Shooting, High Resolution and High Sensitivity The NEX-FS700R is equipped with a newly developed 11.6M pixel Exmor Super35 CMOS sensor. This has a total of 4352 x 2662 pixels, and provides a future capability of 4K-size (4096 x 2160) motion picture shooting. Based on Exmor technology, this sensor has very high-speed image readout characteristics, such as a 240 fps reading in full-HD quality (1920 x 1080).

  • Page 4: Interchangeable Lenses

    For example, with the optional A-mount adaptor, you can take advantage of the many available A-mount lenses. Sony’s LA-EA2 A-mount lens adaptor allows you to use the wide range of high-quality alpha lenses and take advantage of the auto focus function for quicker and more convenient operation.
  • Page 5 NEX-FS700R Third party adaptor Mount Adaptor LA-EA2 Compatible The NEX-FS700R can attach A-mount lens via A-mount to E-mount adaptor LA-EA2. Thanks to Translucent Mirror Technology on LA-EA2, auto focus and one push auto iris functions are available during motion picture...

  • Page 6: Still Picture Recording

    Built-in ND Filters With its built-in, ultra-thin ND filters, the NEX-FS700R offers exceptional shallow depth-of-field on highlights. This means you can expand your shooting styles in every different shooting situation, without requiring external ND filter equipment.

  • Page 7: Recording Time

    Safe, Long-duration Recording in a One-piece Body Hybrid Recording Recording to the directly mountable HXR-FMU128 Flash Memory unit allows continuous recording for over 10 hours without changing the recording media. Simultaneous recording using a memory card and the HXR-FMU128 is also possible for secure backup when shooting footage that cannot be re-taken.

  • Page 8: Editing Workflow

    Picture Profile lets you make adjustments to the gamma curve, black level, color and other parameters that determine image characteristics. In the NEX-FS700R, S-Log2 has been added to the selection of gamma curves provided. S-Log2 is a gamma curve specifically designed to make the most of the sensitivity characteristics of the Exmor super 35 CMOS sensor.
  • Page 9 Moreover, you can select the units of measure: meter or feet, dB or ISO, and – for shutter speed – degree or second. Switchable 50-Hz and 60-Hz Shooting The NEX-FS700R is switchable between 50 Hz and 60 Hz to allow 24 p shooting in PAL areas, and to ensure no PAL/NTSC limitations. Below table shows available recording frame rate.
  • Page 10 The genius of 4K and 2K RAW Sony empowered the NEX-FS700R with a brilliant 4K image sensor featuring 4096 x 2160 resolution. Now you can unlock all that picture quality with the interface unit HXR-IFR5 and the RAW recorder AXS-R5 combination.

  • Page 11: Available Accessories

    * Recording duration is slightly different between RAW and AVCHD recording. HD output for monitoring HDMI/Component/Composite video outputs on the NEX-FS700R and the AUX OUT of the AXS-R5 can be used for monitoring purposes. In order to achieve accurate monitoring of the wide dynamic range of RAW recording, S-Log2 settings onto the picture profile of the NEX-FS700R.

  • Page 12: Specifications

    Sony and Sony logo are trademarks of Sony Corporation. NXCAM and NXCAM logo are trademarks of Sony Corporation. Memory Stick and their respective logos are trademarks of Sony Corporation. AXSM and Picture Profile are trademarks of Sony Corporation. AVCHD and AVCHD logo are trademarks of Panasonic Corporation and Sony Corporation.
