ViewCast Osprey-300 User Manual

Capture card
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Osprey-300
User's Guide

Advertisement

Table of Contents
loading

Related Manuals for ViewCast Osprey-300

Summary of Contents for ViewCast Osprey-300

  • Page 1 Osprey-300 User’s Guide...
  • Page 2 Trademark Acknowledgment Osprey-300 is a trademark of Osprey Technologies, Inc. Microsoft, Windows XP, NetMeeting, NetShow, and Video for Windows are trademarks or registered trademarks of Microsoft Corporation. Any other product names, trademarks, trade names, service marks, or service names owned or registered by any other company and mentioned herein are the property of their respective companies.

  • Page 3: Table Of Contents

    Osprey-300 Input Breakout Box (optional) ....13 Connecting a Composite Source ....... 13 Guidelines for Connecting FireWire Devices ....14 About 1394 connectors .......... 15 Connecting Analog Audio with the Osprey-300 ....16 3: I XP ..17 HAPTER NSTALLING THE...
  • Page 4 Osprey-300 User’s Guide The Input Tab ............ 40 The Device Tab ........... 41 The RefSize Tab ..........46 The Size and Crop Tab .......... 48 The Logo Tab ............. 55 Capture and Preview Pin Properties ......58 6: V ........ 61...

  • Page 5: Chapter 1: Getting To Know Your Osprey -300

    HAPTER Osprey-300 Capture Card Getting to know your Osprey-300 The Osprey-300 Capture Card User’s Guide provides practical information for installing and configuring the hardware and software for the Osprey-300 Capture Card. This guide has been designed with the needs of the end user in mind, particularly first- timers and those working with existing applications.

  • Page 6: Symbols

    Osprey cards and their capabilities, you may want to skip ahead to Chapter 2, Hardware and proceed with installation. The Osprey-300 Capture Card is a single-slot PCI card combining analog and digital video capture and delivering uncompressed video and audio real time to media applications.

  • Page 7: Firewire 800 Features

    Chapter 1: Getting to know your Osprey-300 Card The Osprey-300 also offers the following features: • OHCI compliant • Cascadable architecture allows for multiple Osprey-300’s per chassis • Advanced DMA for ultra-high performance (30 fps) • Hardware audio gain control for analog audio inputs •...

  • Page 8: Getting Help

    Software Included Osprey Capture Cards FAQs ¨ Unbalanced stereo (2 x RCA The products for Windows XP by selecting Osprey-300, then connectors) include: clicking on the FAQ button. ¨ DV audio (via same 1394 • A DirectShow compatible video...

  • Page 9: Chapter 2: Hardware Overview

    HAPTER Osprey-300 Capture Card Hardware Overview The Osprey-300 Capture Card is a universal 3.3V/5V PCI card that will operate in either 32-bit or 64-bit slots, and is compliant with version 2.3 of the PCI hardware specification. • System Requirements • Configuring the Video Capture Driver •...

  • Page 10: System Requirements

    • 256MB or more of system RAM video capture portion of the Osprey 300 • Microsoft DirectX 8.0 or newer uses drivers supplied by ViewCast. Use of • Sound card capable of 16-bit stereo or this card in operating systems older than...

  • Page 11: Installing The Card

    Chapter 2: Hardware Overview NSTALLING THE All computer cards are sensitive to electrostatic discharge. Slight discharges from clothing or even from the normal work environment can adversely affect these cards. By following these simple guidelines, however, you can minimize the chance of damaging your Osprey card.

  • Page 12: Osprey-300 Back Plate

    Osprey-300 User’s Guide -300 B SPREY LATE The Osprey-300 is assembled with a back plate for standard systems (figure 1). If you are not familiar with how to The Osprey-300 Back Plate install a PCI bus card, refer to your system’s documentation for more...

  • Page 13: Osprey-300 Input Breakout Box (Optional)

    6 - Osprey-300 Video Control Dialog for instructions on configuring the driver for S-Video. Connecting an IEEE 1394/DV Source The Osprey-300 has two DV inputs, 1394a and 1394b. DV carries digital audio and video and both can be independently used by the Osprey- 300.

  • Page 14: Guidelines For Connecting Firewire Devices

    Osprey-300 User’s Guide UIDELINES FOR ONNECTING EVICES FireWire devices can be connected in any combination of branching and chaining. There are no SCSI-style ID numbers to set and no termination requirements. The Osprey 300’s 6-pin FireWire port can support up to 16 consecutive cable hops of 4.5 meters (14.76 feet)

  • Page 15: About 1394 Connectors

    Chapter 2: Hardware Overview • If the total DC power requirement for the connected devices is 9 watts or less (at 12 VDC) the on-board DC power connector does not need to be connected to a power source. • If the total load exceeds 9 watts, connect a compatible power source to the DC power connector at the rear of the Osprey 300 card, as shown below.

  • Page 16: Connecting Analog Audio With The Osprey-300

    NALOG UDIO WITH THE -300 SPREY The Osprey-300 audio connectors are made for line level audio stereo equipment, such as VCR or DVD outputs and can also take headphone level outputs when the volume is adjusted midway between high and low settings. It should be...

  • Page 17: Chapter 3: Installing The Software For Windows Xp

    Osprey-300 Capture Card Installing the Software for Windows XP The CD which comes packaged with the Osprey-300 Capture Card contains software compatible with Windows XP. After you’ve installed the software, you can test the card and software by running the included application program, SwiftCap.

  • Page 18: Installing From The Cd

    Osprey-300 User’s Guide NSTALLING ROM THE Insert the Osprey CD into your CDROM drive. The installation instructions assume this is the “D:” drive. Substitute the proper drive name as it appears on your system where appropriate. To run the installation program: 1.

  • Page 19: Two Installation Scenarios

    Chapter 3: Installing the Software for Windows XP NSTALLATION CENARIOS There are two main situations that might apply to you: • Scenario 1: Osprey Card(s) not Physically Installed in the PC • Scenario 2: Osprey Card(s) Physically Installed, but Osprey Software not Installed In all cases, the most efficient and complete installation method is to run the setup.exe...
  • Page 20 Software Agreement. If you do not wish to accept the agreement, click No to terminate the installation routine. The Information window displays. 6. Click Next. The Osprey-300 Driver window appears. 7. Click the radio button to select the default signal format (fi gure 1).
  • Page 21 In this case you have two options: available on the Programs menu or on the Osprey Video web site • Option A: Run the Installation Program (http://www.viewcast.com/). (Recommended) • Option B: Use the New Hardware Found Wizard (Not Recommended) Option A: Run the Installation Program...
  • Page 22 17. Once you have made your choice, click OK. The Product Registration window displays. 18. If you would like to register your Osprey-300 Capture card, click Yes and a browser window will open with a registration page. If not, click No.
  • Page 23 Chapter 3: Installing the Software for Windows XP Option B: Use the New Hardware Found Wizard (Not Recommended) This method is more complicated than Option A. It is particularly inconvenient if you are installing multiple cards at once, since each card has to be set up separately.

  • Page 24: Testing The Installation

    Since the driver defaults to NTSC-M signal format, users of PAL and SECAM equipment always need to change the driver’s signal format the fi rst time they run the driver. Please see Video Standard in Chapter 6 – Osprey-300 Video Control Dialog.

  • Page 25: Uninstalling The Software

    Chapter 3: Installing the Software for Windows XP NINSTALLING THE OFTWARE If you ever need to remove the Osprey driver from your system, proceed as follows: 1. Open the Control Panel. 2. Double-click Add/Remove Programs. 3. Click to select Change or Remove Programs.

  • Page 26: Chapter 4: Digital Video On The Osprey -300

    5XX cards, the DV connector and capture hardware sit behind the Osprey audio and video capture devices and are controlled by the Osprey driver. On the Osprey-300, the DV is an entirely independent device. If you look at the Windows XP Device...

  • Page 27: Specifics Of Dv Capture

    DV devices and work with them fully. For example, we have verified that Windows Media Encoder 9 supports a DVCam attached to an Osprey-300. With major applications the DV connection should “just work” and the information here is for background and reference only.
  • Page 28 Chapter 4: Digital Video on the Osprey-300 The dvsd format comes in two flavors - video- only, and audio + video interleaved. The audio + video data rate is slightly higher than the 120,000 or 144,000 bytes per frame quoted above - for NTSC it is about 129,000 bytes per frame, or about 3,866,130 bytes per second.

  • Page 29: Swiftcap

    2. If a device such as a DV camcorder is connected to the Osprey-300, it will appear in the video device list as a “Microsoft DV Camera and VCR”. The Capture Settings dialog will appear as shown only when a DV device is selected;...

  • Page 30: Graphs

    Chapter 4: Digital Video on the Osprey-300 RAPHS This section contains more technical information that may give some users helpful insight into DV capture and rendering operations. The illustrations are DirectShow graphs as displayed by GraphEdit. For still more advanced information, refer to the DirectX 9 SDK documentation available from Microsoft.
  • Page 31 Osprey-300 User’s Guide This graph shows basic video-only rendering. The DV Video Decoder converts the “dvsd” DV video stream to the YUY2 format required by the video renderer. The Smart Tee allows a capture stream to be connected as well as the preview stream. It is optional in this particular graph; however, the normal graph-building process usually inserts a SmartTee automatically.
  • Page 32 Chapter 4: Digital Video on the Osprey-300 Audio and video, capture with preview. This is the most complex graph that SwiftCap currently supports. It is a combination of elements described in the previous graphs. This graph (which SwiftCap currently does not support) shows an A/V capture-only configuration to which a DV Video Decoder Filter has been added.
  • Page 33 Osprey-300 User’s Guide This graph shows audio + video capture with the Microsoft Video 1 compressor. The compressor requires YUY2 as its input fomat and so the DV Video Decoder precedes it. A compressed graph of this kind substantially compresses the AVI data, at the expense of cpu time and video quality.

  • Page 34: Chapter 5: Analog Video Driver Properties

    HAPTER Osprey-300 Capture Card Analog Video Driver Properties ILTERS ILTER RAPHS ROPERTIES In DirectShow the words “Filter” and “Pin” are frequently used. A “Filter” is a component that performs a processing step on an audio or video (or closed caption, or VBI…) stream. A...

  • Page 35: Osprey Video Capture Device Properties

    “Tabs” that are part of a tabbed dialog. If you are a programmer, you might set properties directly from the code of your application. The block labeled “Osprey-300 Device 1” in the center of the filtergraph is the Osprey capture filter, and the “Filter Properties” about to be described are the properties and controls for that component.

  • Page 36: Accessing The Property

    Chapter 5: Analog Video Driver Properties SwiftCap: • Pull down the Capture menu, select Settings… • Select the device from the drop list in the upper left corner of the Capture Settings dialog box. • Real Producer 8, VidCap32, and other Video for Windows applications: •...

  • Page 37: Common Dialog Features

    Osprey-300 User’s Guide OMMON IALOG EATURES The Properties are organized as tabs or pages in a dialog box entitled o300avs cap Properties. The tabs are as follows: Note that these property tabs are not where you Tabs located along the top of the video set frame size and frame rate.

  • Page 38: The Video Proc Amp Tab

    Chapter 5: Analog Video Driver Properties Note that the OK and Apply buttons commit only the changes on the currently displayed page. To set changes on three different pages you would have to click Apply twice and OK once. IDEO Use the four slider controls to set Brightness, Contrast, Hue, and Saturation (figure 5).

  • Page 39: The Input Tab

    Osprey-300 User’s Guide Changes made with this control take effect immediately – the Apply button really has no function on this tab. If video is running and a standard is selected that does not match the incoming signal, the video is likely to freeze or glitch until the signal matches again.

  • Page 40: The Device Tab

    Chapter 5: Analog Video Driver Properties Changes take effect only when you click the Apply button. If video is running, there may be a brief glitch while the settings take effect. EVICE These controls (figure 8) set important low-level operating parameters for the driver. Changes made on this page apply to all video preview and capture pins on the currently selected device.
  • Page 41 Osprey-300 User’s Guide For Preview, the driver exploits the hardware- based deinterlacing capability that resides in most display adapters. No CPU bandwidth is used; however, our experience so far is that the quality of the deinterlacing is not quite as high as that offered by the software-based capture pin method.
  • Page 42 Chapter 5: Analog Video Driver Properties You can use this control to reposition the video. If you start video preview running before you use this control, repositioning will be interactive. Use the arrow buttons to move the video, and the “0” button to reset it to the normal position. With uncropped video, the video will shift only on every second increment 0, 2, 4…...
  • Page 43 Osprey-300 User’s Guide 3. Note also that gamma correction will only show up in preview video if “Adjust preview video” is checked. 4. The “Adjust preview video” checkbox is provided because gamma correction of preview video may be quite slow.
  • Page 44 “VBI” is short for Vertical Blanking Interval, and refers to nonvideo data that may be present in the vertical retrace region of a video signal. The Osprey-300 does not capture full VBI data, although it does deliver decoded Closed Captions (CC) and Vertical Interval Timecode (VITC).

  • Page 45: The Refsize Tab

    Osprey-300 User’s Guide If you change this control, the change will not take effect until you restart the video capture device, either by rebooting the system (recommended) or restarting it with the Device Manager (advanced but quicker). The other two control groups are quite specialized. For...
  • Page 46 Chapter 5: Analog Video Driver Properties • Select 480-line video for all normal applications. • Select 485-line video for specialized applications. When 480-line video is selected, you have the option of treating the Closed Caption line, Line 21, as video or as Closed Caption data. If you want to capture or display decoded Closed Captions, you must uncheck the box titled Include Line 21 in Video.

  • Page 47: The Size And Crop Tab

    Osprey-300 User’s Guide IZE AND The Size and Crop Tab (figure 13) has two functions: • It sets the default output size, whether or not cropping is enabled. • It enables and disables cropping, and sets the cropping rectangle. The default output size is the video size that appears in the DirectShow pin properties dialog as the “default”...
  • Page 48 Chapter 5: Analog Video Driver Properties Reference Size The reference size information is always read- only on this dialog tab. It is determined by settings made on other tabs – specifically, the Input tab, where a 525-line or 625-line standard is selected, and the RefSize tab, where NTSC vertical sizing is selected.
  • Page 49 Osprey-300 User’s Guide If Pin Select is set to Both, both the capture and preview drop boxes are enabled for editing. The two small read-only edit boxes to the right of the group show the worst-case horizontal and vertical granularities required by both formats.
  • Page 50 Chapter 5: Analog Video Driver Properties If you select “Both”, the horizontal granularity is at least 2, because the Preview YUY2 format has horizontal granularity 2. You would notice this only if you select RGB32. Enable Cropping If you uncheck the Enable Cropping checkbox, your video will not be cropped regardless of any crop settings you might previously have made.
  • Page 51 Osprey-300 User’s Guide If you enable cropping, key in some custom settings, and then disable cropping, an uncropped specification will be displayed and your settings will disappear from view. However, the driver does remember your custom settings, and if you enable cropping again, they will reappear.
  • Page 52 Chapter 5: Analog Video Driver Properties Default Size The standard DirectShow Pin Properties dialog allows you to select the height and width of captured video from a dropdown list. The dropdown list has a particular range of choices that may or may not fit your needs. The dropdown list includes one default size that is provided by the capture driver.
  • Page 53 352 as soon as you click on another control. • The driver will not accept sizes below a set minimum. For the Osprey-300 release, the minimum size for captured video is 48 wide by 36 high. The Size and Crop page will not accept output size selections that would make the video smaller than the set minimum size.

  • Page 54: The Logo Tab

    Chapter 5: Analog Video Driver Properties The logo property superimposes a graphic over captured video using the logo property controls (figure 15). Logos have the following characteristics: • Any RGB-24 bitmap in .bmp file format can be used. • A selectable key color can be specified; all parts of the logo graphic with that color are not drawn on the video.
  • Page 55 Osprey-300 User’s Guide If you like, however, you can have different setups for the two pins. For example, you could enable the logo on the capture pin but not on the preview pin, and thereby save some cpu time. When you select the “Capture” radio button,...
  • Page 56 Chapter 5: Analog Video Driver Properties If the checkbox is checked, key coloring is activated. The five radio buttons are activated. You can select one of four standard colors – dark grey, medium grey, cyan, or magenta – or a custom color.

  • Page 57: Capture And Preview Pin Properties

    Osprey-300 User’s Guide image. We recommend that wherever possible for production work you prepare artwork of the exact size at which it will be used. Notes on Logos: • Because the logo properties tab is used to set up a logo interactively on live video, its behavior is different from the behavior of the other tabs.
  • Page 58 Chapter 5: Analog Video Driver Properties The three active fields of the dialog set the Color Space or pixel format of captured video; Output Size of the video, and Frame Rate. The recommended order for setting these parameters is: First, Color Space; second, Output Size;...

  • Page 59: Chapter 6: Video Driver Topics

    For details about purchasing and installing SimulStream, refer to www.viewcast.com. When you first install this driver, a 10-day evaluation is installed as part of it. This section describes the capabilities of SimulStream, and explains additions and changes to the filter properties interface.
  • Page 60 Osprey-300 User’s Guide When SimulStream is installed it will indicate the status of the license. With both the full and evaluation versions you have the option to enable or disable SimulStream. When it is disabled, the only control on the property page is the...
  • Page 61 Chapter 6: Video Driver Topics When “Optimize for Single Streams” is selected, the Osprey driver is configured for minimum cpu usage and bus bandwidth utilization when possible. It switches to more cpu-intensive SimulStream processing only when additional pins start running. When it does make this switch, there could be a slight transition in the appearance of the video.
  • Page 62 Osprey-300 User’s Guide Per-Device Controls and Per-Pin Controls Some controls operate on the device as a whole, while other controls operate on individual pins. Specifically, controls on the following tabs are per-device: • Video Proc Amp • Video Decoder • Input •...
  • Page 63 Chapter 6: Video Driver Topics • When you define a pin, you give it a number, so it is “Capture Pin 0”, “Capture Pin 1”, etc. These numbered pin specifications do not map absolutely to particular pins belonging to a particular application.
  • Page 64 Osprey-300 User’s Guide Although you can enter any pin number, you will probably want to provide the next unused instance number in sequence – for example, if you already have Capture Pins 0 and 1 defined, the next capture pin should be 2.
  • Page 65 Chapter 6: Video Driver Topics Get Data Select a pin specification using the drop box, then click Get Data to read that pin spec’s data from the registry. If the “Apply to Both Capture and Preview” box is checked, the data for the capture pin will be read and applied to both pins.

  • Page 66: Osprey Avstream Driver And Video For Windows

    Osprey-300 User’s Guide SPREY TREAM RIVER AND IDEO INDOWS Video for Windows applications control the driver’s most important functions via compatibility mode dialog boxes. You cannot access the complete Osprey AVStream Filter Properties directly from these older applications. The compatibility mode dialogs do not have all the controls that are accessible from DirectShow applications.
  • Page 67 Chapter 6: Video Driver Topics Brightness, Contrast, Hue, Saturation In the Video Source dialog, select Device Settings (figure 8). If you have preview or overlay video already running, you can see the effects of the four sliders interactively. For PAL video, keep Hue at its default value.

  • Page 68: De-Interlacing

    Osprey-300 User’s Guide On the other hand, if overlay video is sized to 160x120 because that is the DirectShow default setting, and the capture video is sized by VidCap32 to 640x480, then overlay will be captured at 160x120 and scaled up 1:4 in software to the 640x480 size of the VidCap32 overlay window –...
  • Page 69 Chapter 6: Video Driver Topics Figure 10 is a simplistic view of interlaced video and fields. The two fields are taken 1/60th of a second apart, and the lines of each field are not aligned, but staggered. Most televisions are interlace display devices, where the 60 fields are displayed individually and the viewer sees only one field at a time.

  • Page 70: Efficient Video Rendering

    Osprey-300 User’s Guide The Osprey-300’s software de-interlacing can be applied to any video capture stream to eliminate streaking or feathering and maintain motion content. In the screen in figure 13, where the Osprey-300’s de-interlace motion filter has been turned on, note that the strong horizontal streaking or feathering around the subject’s head...
  • Page 71 Chapter 6: Video Driver Topics Preview Pin to Video Renderer This is the oldest, simplest, and usually least efficient way of rendering video. It does not use DirectDraw in the rendering process. It is the default rendering pathway that will be chosen when an application says “Render”...
  • Page 72 Osprey-300 User’s Guide Preview Pin to VMR7 VMR7 is short for “Video Mixing Renderer 7”. VMR7 is a newer renderer that is generally much faster than the old Video Renderer. It uses an efficient DirectDraw configuration to render with almost no cpu overhead, so long as the correct video format is used.

  • Page 73: Video Standards And Sizes

    Chapter 6: Video Driver Topics Some Data Points: The following measurements are cpu percent utilization on a fairly old, 600 MHz machine – the relative performances of the pathways are more important than the absolute percents. The video size is 640x480. The screen depth is 32 bits, so that RGB32 renders more than RGB555 in this case. The following abbreviations are used: = Video Renderer VMR7...

  • Page 74: Color Formats

    360x240 for NTSC, and 360x288 for PAL. The driver automatically adjusts the reference size and default size for the video standard you are using. Note that the Osprey-300 always uses CCIR-601 horizontal proportioning, which is based on a 720-pixel full line width. OLOR...
  • Page 75 Chapter 6: Video Driver Topics * YVU9 planar - Similar to YUV12 planar, except that there are in the aggregate 9 bits of data per pixel, and each byte pair of chrominance data is shared by 16 adjacent pixels arranged in a 4x4 square.

  • Page 76: Closed Captioning (Cc)

    Osprey-300 User’s Guide YUY2 mode, sometimes referred to as 4:2:2 packed mode, consists of a single array of mixed Byte 1= y1 Byte 1 Intensity Y, U, and V data. Each pixel has one Y (intensity) byte. Each pixel shares its U and V bytes with...
  • Page 77 NTSC captioning only. The GraphEdit filtergraph shown in figure 15 displays CC on preview video. The Line 21 Decoder downstream of the Osprey-300 capture filter interprets the CC pairs and renders an overlay of the characters. The Overlay Mixer combines the CC overlay with the preview video, which is then rendered onscreen.
  • Page 78 Osprey-300 User’s Guide When SimulStream is not installed, the driver supports two CC pin instances. One could be associated with the video capture stream, the other with the preview stream. In practice, a DirectShow Smart Tee Filter can be inserted into the graph to make any number of VBI pins.
  • Page 79 Chapter 6: Video Driver Topics Application notes Windows Media Player will not play back an AVI file with an embedded CC stream. The above GraphEdit filtergraph will play back an AVI file containing a video stream plus a CC stream, with the CC rendered on the video.

  • Page 80: Vertical Interval Timecode (Vitc)

    Osprey-300 User’s Guide (VITC) ERTICAL NTERVAL IMECODE Vertical interval timecode (VITC) data is embedded in the Vertical Blanking Intervals (VBIs) of some video content. Timecodes mark each frame with an hour / minute / second / framenumber marking that can be use for frame-precise editing.
  • Page 81 (VBI) ERTICAL LANKING NTERVAL APTURE The Osprey-300 does not support VBI raw capture. It only supports decoded capture of the two special streams, Closed Caption (CC) and vertical interval timecode (VITC). If your application requires VBI capture for WST teletext...

  • Page 82: Chapter 7: The Analog Audio Driver

    HAPTER Osprey-300 Capture Card The Analog Audio Driver Setup and control for audio are much simpler than for video. The basic steps are covered in the following topics: • Select the Audio Source and Input Volume • Audio Formats • Audio Playback •...
  • Page 83 OK, and you will be returned to the Recording Mixer Interface) Control display. The Osprey-300 device is not a mixer in that it does not allow for mixing the various audio sources. Therefore, when one audio input is selected, any other input previously selected becomes unselected.

  • Page 84: Audio Formats

    • 32 kHz • 44.1 kHz • 48 kHz UDIO LAYBACK The Osprey-300 provides audio capture only, not audio playback. Continue to play back captured audio using your system soundcard. UDIO ONFIGURATION The AudioConfig applet is included as part of the Osprey AVStream driver package.
  • Page 85 Osprey-300 User’s Guide Preferred Audio Sample Rate The audio sample rate is the rate at which the hardware samples the incoming audio, which may differ from the sample rate delivered to the client application. The choice are to allow “Any Supported Rate”, or to force the sampling rate to be 32 kHz, 44.1 kHz, or 48 kHz.
  • Page 86 Chapter 7: The Osprey-300 Audio Driver Note that in order to get mono audio you have to select mono mode in your application. For example, in SwiftCap you have to select mono 8-bit or mono 16-bit in the Capture Settings ->...

  • Page 87: Chapter 8: Applications

    HAPTER Osprey-300 Capture Card Applications WIFT SwiftCap is a video capture application that is included with the Osprey AVStream package. It is included in source form in the Osprey AVStream SDK. SwiftCap is useful for general purpose capture and viewing of video, as well as for testing the installation.
  • Page 88 Osprey-300 User’s Guide Setup Sequence SwiftCap has many possible scenarios and pathways. The following steps illustrate a few of the most useful possibilities. 1. Click the “Tools” button to open the capture settings dialog (fi gure 2). 2. First decide whether you want to capture video only, audio only, or both;...
  • Page 89 Chapter 8: Applications A Capture-to-File Scenario No changes are mandatory from the previous setup the Capture Settings dialog. However, you may want to select a video and/or audio compressor to obtain a much more compact capture file. In the Capture Destination dialog (figure 4), make the following changes: 1.
  • Page 90 Osprey-300 User’s Guide 4. The output size, which is the fi nal size of the captured video, can be 1X, 1/2X, or 1/4X the crop size (6d). There is also an entry in this drop box by which you can set a custom size.

  • Page 91: Ccapp

    Chapter 8: Applications • If you select RGB8 greyscale as your color format, SwiftCap captures in greyscale, but continues to preview in color. Also, if you capture to the VMR7 Renderer or VMR9 Renderer, you will get color video; you will only see greyscale video with the “Video Renderer”...

  • Page 92: Cropapp

    Osprey-300 User’s Guide CropApp (figure 8) sets up crops visually and interactively. Its functionality is similar to the driver’s Size and Crop property page, but it has the added dimension of graphical placement of the cropping rectangle on live video. It has about the same functionality as SwiftCap’s crop setup...
  • Page 93 CropApp will not let you set crops that are smaller than a minimum width and/or height. The minimum size in the Osprey-300 driver is 48 wide by 36 high. The Default Output Size group sets a default size that applications may choose.

  • Page 94: Logoapp

    Osprey-300 User’s Guide Selecting a format here causes CropApp to use that format for its own rendering, but it does not cause that same color format to be selected in your application. In only ensures that your crop size will work with that color format when it is used.

  • Page 95: Vidcontrol

    Chapter 8: Applications LogoApp sets the same logo spec for both the Capture and Preview pin. If SimulStream is enabled, LogoApp will set only Pin Pair 0. To set up other pin instances, or to set the capture and preview pins differently, use the driver’s Logo property page.

  • Page 96: Roubleshooting

    HAPTER Osprey-300 Capture Card Troubleshooting LACK RANGE IDEO CREEN The currently selected video input is not receiving an active video signal. Different inputs may provide a different symptom when a video source is not supplied. * Check that the camera, VCR, or...

  • Page 97: Multiple Horizontal Lines Across Video

    * Verify that the selected playback device is full frame sizes. your sound card, and not the Osprey-300 Systems vary in their data transfer limits. The Placeholder device. The Placeholder device exists characteristics of the PCI bridge are often more in order to handle the situation where there is an important than processor speed.

  • Page 98: Interrupt Conflicts

    Chapter 9: Troubleshooting Unfortunately the Recording Control does not Multiple PCI cards are supposed to be able to work smoothly in this situation. The Video for share the same IRQ line. In practice, occasionally Windows device will always try to act like it is you may encounter a device driver that is not the selected device even if it is not.
  • Page 99 Osprey-300 Capture Card PPENDIX Hardware Specifi cations Table A-1 Physical Dimensions Table A-2 Environmental Specifications Length 167 mm Operating Temperature 0º to 40º C Range Width 18 mm Non-Operating -40º to +75º C (RH) Height 106 mm Temperature Range Weight...
  • Page 100 Osprey-300 Capture Card PPENDIX Special Registry Settings All of the registry variables described here affect all The first character in each four-character descriptor devices and all capture or preview pins controlled is a hexadecimal number for the color format. The by the driver.

  • Page 101: Dx9

    Osprey-300 User’s Guide Currently, the driver’s internal defaults are as follows: CaptureMap This variable is meaningful only on Windows 2000 systems, not on XP. On Windows 2000 the audio 71+ 81+ B1+ C1+ 41+ 21+ 11+ 61+ 41- 21- 11- 61-...
  • Page 102 Osprey AVStream driver’s custom sequence is initiated. This can happen because an properties. Inquire at http://www.viewcast.com for Osprey board has been moved to a different PCI slot further information. This kit is different from the or when a board is being added to the machine.
