Summary of Contents for MCM Electronics USB-80
-
Page 1: Owners Manual
40 Watt Mixer Amplifier Owners Manual with Media Player Model #USB-80 ©2009 MCM Electronics MCM Custom Audio MCM Electronics Centerville, Ohio www.mcmelectronics.com... -
Page 2: Safety Instructions
Owners Manual USB-80 Mixer Amplifier SAFETY INSTRUCTIONS • Please be sure to read all the instructions carefully before using this product. • As several safety messages are printed in this instruction sheet, please be sure to observe these as they are important. -
Page 3: Front Panel Description
Owners Manual USB-80 Mixer Amplifier Front Panel Description 1. Output Power Meter Displays relative output level of the amplifier. Left most yellow indicator acts as power indicator for the amplifier and will remain continuously lit when power is turned on. -
Page 4: Rear Panel Description
Pause and Play action. 14. SD/MMC Card Slot This slot accepts standard SD or MMC flash memory, readily available from MCM Electronics or any computer retailer. The player will read MP and WMA files directly from the flash memory, regardless of whether the file is in the root directory or sub folders. -
Page 5: Speaker Connection
Owners Manual USB-80 Mixer Amplifier Speaker Connection It is possible to connect any number of speakers to this amplifier, from a single unit to 20 or more. However, it is critical that proper wiring configurations are used, otherwise potentially poor performance, and likely permanent amplifier damage will result. - Page 6 Owners Manual USB-80 Mixer Amplifier Low Impedance Speakers (cont) In certain cases, it may be necessary to use a combination of series and parallel wiring to achieve the desired impedance. The adjacent illustration demonstrates a common method of connecting four 8Ω speakers, and maintaining a combined 8Ω...
- Page 7 "daisy chain" configuration. It is not necessary to "home run" wire from each speaker back to the amplifier. Shown below is a very typical arrangement of (14) 70V speakers connected to the USB-80 amplifier. Typically, speakers having attached 70V transformers will have multiple wattage taps available for connection.
-
Page 8: Operating The Amplifier
Owners Manual USB-80 Mixer Amplifier Installation of the Amplifier • Be certain that the power is removed from the amplifier • Locate the amplifier in a suitable shelf or tabletop. If positioned with other components, it is not recommended that other devices be located on top of the amplifier. -
Page 9: Amplifier Specifications
Owners Manual USB-80 Mixer Amplifier Using the IR Remote Control The included IR remote control will allows remote operation of all front panel controls, plus additional functions. Shaded area buttons labeled 0~9 –Allow individual track selection by number. Simply key in the desired track.
