Operating Instructions
LED TV
Contents
Be Sure to Read
Important Notice ·················································2
Safety Precautions ·············································3
Quick Start Guide
Accessories ························································5
Connections························································7
Identifying Controls ···········································12
First time Auto Tuning ·······································15
Using your VIERA
Operations ························································16
How to Use eHELP ···········································17
Viewing 3D images ···········································18
Others
FAQs·································································19
Maintenance ·····················································20
Specifications ···················································20
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
The images shown in this manual are for illustrative purposes only.
Australia
TH-L65WT600A TH-L65WT600Z
For more detailed instructions, refer to [eHELP]
(Built-in Operating Instructions).
●
How to use [eHELP]
Model No.
New Zealand
(p. 17)
TQBC2747
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic Viera TH-L65WT600A
Summary of Contents for Panasonic Viera TH-L65WT600A
-
Page 1: Table Of Contents
Specifications ···················································20 How to use [eHELP] (p. 17) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. The images shown in this manual are for illustrative purposes only. -
Page 2: Important Notice
Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. -
Page 3: Safety Precautions
● Do not use an unapproved pedestal / mounting Caution equipment. Be sure to ask your local Panasonic dealer ● Do not use any pedestal other than the one provided to perform the setup or installation of approved wall- with this TV. - Page 4 Additional information for the wireless LAN and access ● Do not mix old and new batteries. point may be on the following website. ● Do not mix different battery types (such as alkaline and http://panasonic.net/viera/support manganese batteries). ■ ● Do not use rechargeable batteries (Ni-Cd, etc.). Bluetooth wireless technology ®...
-
Page 5: Accessories
■ ■ 3D Eyewear Use Viewing 3D Images Caution Caution ● Use the 3D Eyewear only for the intended purpose and ● Pay special attention when children are viewing 3D nothing else. images. 3D images should not be viewed by children ●... - Page 6 Assembling / Removing the pedestal Assembly screw (4) Bracket Cover M5 × 14 Assembly screw (8) Base Spiral tube (p. 11) M4 × 10 Parts for preventing the TV from falling over Band (2) Screw (2) Wood screw (2) ■ Assembling the pedestal Preventing the TV from falling over It is recommended to secure the pedestal to a furniture as shown...
-
Page 7: Connections
Connections ● External equipment and cables shown are not supplied with this TV. ● Ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads. ● Check the type of terminals and cable plugs are correct when connecting. ●... -
Page 8: Wireless Connection
● Keep RF (aerial) cable away from the mains lead to avoid and minimise mains interference pickup. ● Do not place the RF cable under the TV. An aerial, correct cable (75 Ω coaxial) and correct terminating plug are required to obtain optimum quality picture and ●... - Page 9 Connections for 4K contents ■ 4K compatible equipment HDMI cable 4K compatible equipment DisplayPort cable ● To watch contents of 4K format, connect the 4K compatible equipment to HDMI4 or DisplayPort by using a 4K compatible cable. When connecting to DisplayPort, use the DisplayPort 1.2 compliant cable. Other connections ■...
- Page 10 ■ Amplifier (to listen with speakers) HDMI cable Amplifier with External equipment speaker system (DVD Player, etc.) ● Use HDMI2 or HDMI4 for connecting an amplifier and match the output setting in [ARC Output] (Sound Menu). This connection is applicable when using an amplifier that has ARC (Audio Return Channel) function. As for an amplifier without ARC function, use DIGITAL AUDIO OUT.
- Page 11 Using the cable tie and spiral tube (supplied) ● Do not bundle the RF cable and mains lead together (could cause distorted image). ● Fix cables with the cable tie and spiral tube as necessary. ● When using the optional accessory, follow the option’s assembly manual to fix cables. Attach the cable tie Bundle the cables hole...
-
Page 12: Identifying Controls
Identifying Controls Remote Control ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. ● Displays the Channel List. [Option Menu] ● Easy optional setting for viewing, sound, etc. Coloured buttons (red-green-yellow-blue) ● Used for the selection, navigation and operation of various functions. - Page 13 VIERA Touch Pad Controller This touch pad controller is designed for the convenient operations, especially, on Home Screen or internet contents. You can operate the TV intuitively with this controller. ● The touch pad controller can be used by registering to this TV with Bluetooth wireless technology. Setup screen to register will appear in “First time Auto Tuning”...
- Page 14 Indicator / Control panel ● When pressing 1, 2, 3 buttons, the control panel guide appears on the right side of the screen for 3 seconds to highlight the pressed button. 25 mm 9 10 Rear side of the TV Input mode selection Power LED ●...
-
Page 15: First Time Auto Tuning
First time Auto Tuning Automatically sets up the TV and searches for available TV channels when the TV is turned on for the first time. ● These steps are not necessary if the setup has been completed by your local dealer. ●... -
Page 16: Operations
Operations Turn power on ● Mains power On / Off switch should be on. (p. 14) (TV) (Remote Control) The last viewed [Home Screen] is displayed. Example: [TV Home Screen] Example: Selected content screen ● To return to [Home Screen] at any time ●... -
Page 17: How To Use Ehelp
How to Use eHELP [eHELP] is the detailed operating instructions built into the TV, and helps you to get more understanding of the operations for each feature. Display [eHELP] [Help] [eHELP] ● [Read first] will be displayed on the top page. Please read these instructions fully to get more understanding of the operation in [eHELP]. -
Page 18: Viewing 3D Images
*: The 3D format that the images for the left and right eyes are recorded with the high definition quality and alternately played back. 3D Eyewear Use the supplied 3D Eyewear or Panasonic 3D Eyewear that has this logo and supports Bluetooth wireless ®... -
Page 19: Faqs
Turn the 3D Eyewear on and put it on Connection status and battery status are displayed on the bottom right of the screen. View the 3D images Safety precautions will be displayed when you first watch the 3D image. Select [Yes] or [No] to continue to view 3D images. -
Page 20: Maintenance
Wipe the mains plug with a dry cloth at regular intervals. Moisture and dust may cause fire or electrical shock. Specifications ■ Australia New Zealand Model No. TH-L65WT600A TH-L65WT600Z 7 MHz VHF / UHF (Australia) 8 MHz UHF (New Zealand) Digital TV free-to-air TV broadcast reception... - Page 21 Liquid Crystal Shutter Usage temperature range 0 °C - 40 °C Coin-shaped lithium battery CR2025 Battery Operation time: Approx. 75 hours in continuous use of the battery made by Panasonic Main body: Resin Materials Lens section: Liquid crystal glass Note ●...
- Page 22 If there is a major failure in regard to the product which cannot be remedied then you must notify us within a reasonable period by contacting the Panasonic Customer Care Centre. If the failure in the product is not a major failure then Panasonic may choose to repair or replace the product and will do so in a reasonable period of time from receiving notice from you.
- Page 23 New Zealand WARRANTY - New Zealand only NEW ZEALAND Distributed in New Zealand by Panasonic New Zealand Limited 350 Te Irirangi Drive East Tamaki, Private Bag 14911, Panmure Auckland Tel. 09 272 0100 Customer Care Center Email: Customerservice@nz.panasonic.com www.panasonic.co.nz Warranty...
- Page 24 Warranty Service purposes. Model Number Serial Number M0713-0 Web Site: http://panasonic.net © Panasonic Corporation 2013 Printed in Japan...
