Summary of Contents for scope RX8Z
-
Page 1: User Manual
SCOPE COMMUNICATIONS UK LTD 8 Zone Receiver System User Manual Scope Communications UK Ltd Quantum House, Totnes, Devon TQ9 5AL England. Tel: 01803 860700 Email: sales@scope-uk.com RX8ZONE Issue 2... - Page 2 For UK equipment, Scope has no control of the use and application of the frequencies issued by OFCOM. Some equipment that is licensed may have greater protection than other equipment which is operated on a WT Act License Exempt basis.
- Page 3 Liability Scope does not accept liability for any damage or injury, howsoever caused as the result of misuse of this equipment. It is the responsibility of the user to ensure that the equipment is operated in the manner for which it was intended and that it is the correct item of equipment for the required task.
- Page 4 SCOPE 8 ZONE RECEIVER DECODER MK1 Overview The 8 Zone Receiver Decoder is equipped with 8 zone relays, a Battery Low relay, a Tamper relay and a Common relay, and is designed to run from a mains supply with a battery back-up, although battery operation can be acceptable under certain circumstances providing sufficient standby facilities are available.
- Page 5 SCOPE 8 ZONE RECEIVER DECODER MK1 MODE 4 125 SECS MOMENTARY All mode switch functions become current during power-up. ie if you alter the settings of the mode switches, then you must power down the unit for ten seconds then power-up again.
-
Page 6: Expansion Connections
SCOPE 8 ZONE RECEIVER DECODER MK1 Range Tests 1) Using the Analogue Meter Connect the signal strength meter to the port indicated on the component layout after removing the LED driver connection (remember to reconnect this lead after tests are completed). When the receiver is powered, the signal meter will register a reading of around 1.6 / 2.2 on the upper scale. - Page 7 SCOPE 8 ZONE RECEIVER DECODER MK1 Diagram 1 Page 7 of 9 RX8Z Issue 2...
- Page 8 SCOPE 8 ZONE RECEIVER DECODER MK1 Diagram 2 Page 8 of 9 RX8Z Issue 2...
- Page 9 SCOPE 8 ZONE RECEIVER DECODER MK1 Example Binary Code Table (SW = switch, 1=ON, 0=OFF) Decimal Value Transmitter no: 037' Page 9 of 9 RX8Z Issue 2...
