Amphony 2.4 GHz Digital Audio Receiver/ Amplifier 1040 Specification Sheet

2.4 GHz Digital Audio Receiver/ Amplifier Model 1040
Product Specification
Features
· 40 W Output Power
· 94 dB Dynamic Range
· Avoids quality losses due to audio
compression
· 128 times digital interpolation filter stage and
analog filter stage
· Range of up to 300 ft (line of sight)
· Avoids reception errors by employing
½ rate forward error correction
· Mute Function
· No switch-on/ switch-off plops
· Short-circuit Safe Output
· Built-In Voltage Step-Up Converter
· Only one supply voltage required
· Power-Down Feature
Applications
· Wireless home theater systems
· Wireless hi-fi stereo speaker systems
ã 2000 Amphony
General Description
The Model 1040 receiver/ amplifier will receive
a digital audio signal that is being transmitted in
the 2.4 GHz range by either the Model 1000 or
Model 2000 transmitter. The recovered audio
signal will pass a digital as well as an analog
filter stage to eliminate out-of-band components
and is amplified to the maximum output power
of 40 W to drive a speaker unit.
By receiving the signal in a digital format, noise
and quality losses that are inherent with
conventional analog systems are avoided.
The Model 1040 receiver/ amplifier will apply
forward error correction to the received signal in
order to maximize reception robustness.
A built-in voltage step-up converter will lift the
internal voltage to approximately twice the
supply voltage when a larger output swing is
required.
The Model 1040 receiver/ amplifier will enter a
Power-Down Mode if no valid signal is received.
It will return to active mode when a valid signal
is detected.
January 2000
