Summary of Contents for Jangus Wi Sure-Fit
- Page 1 Wi Sure-Fit EL Series Earset/Lavalier Microphone USER GUIDE...
- Page 2 EL Series Earset/Lavalier Microphone. ™ Congratulations on your purchase of the Wi Sure-Fit™ EL Series Earset/Lavalier Microphone. We’re confident you’ll find it the finest, most natural sounding and most innovative earset and lavalier microphone available. Please thoroughly read this User’s Manual for all the features and information necessary to install and operate your new Wi Sure-Fit™...
-
Page 3: Packing List
Wi Sure-Fit EL Series PACKING LIST What is included in the package? Verify that you have received all of the items listed below. Wi Sure-Fit™ ELM Earset Wi Sure-Fit™ EL Earset Wi Simple-Twist™ Detachable Wi Simple-Twist™ Detachable Lavalier (If specified by part number) - Page 4 Cable Port: Simple-Twist detachable cable port In-Ear Receiver: Integrated in-ear receiver (Wi Sure-Fit ELM model) EL Ear Mount: Sure-Fit advanced ergonomic silicon ear mount (Wi Sure-Fit EL model) Lavalier MIC Port: Simple-Twist detachable Lavalier cable with removable microphone capsule port...
- Page 5 Wi Sure-Fit EL Series FEATURES...
- Page 6 Wi Sure-Fit EL Series HANDLING Handling The Wi Sure-Fit EL Series The Wi Sure-Fit EL Series is a high-precision instrument and it is designed for durability and flexibility. The following are some of the basic precautions to prevent damage to the Wi Sure-Fit EL.
- Page 7 Wi Sure-Fit EL Series HANDLING Do not bend and wrap the cables in any way that creates severe coiling or strain on the cables. Always detach the earset cable and the removable adapter when storing the Wi Sure-Fit microphone...
-
Page 8: Getting Started
GETTING STARTED The Wi Sure-Fit Earset & Lavalier Delivering unmatched value, comfort, sound quality and secure fit, the Wi Sure-Fit™ EL Series earset and lavalier microphone delivers three (3) applications in one versatile microphone including ear-worn, lavalier and video camera/instruments miking applications. - Page 9 The Wi Sure-Fit™ EL Series ultra-low-profile detachable cable delivers minimum visibility with maximum durability. Optional adapters give the Wi Sure-Fit™ EL series earset great flexibility for use with different pocket wireless systems including Wi AudioStream™, AKG™, Shure™, Sony™, Audio-Technica™ and Sennheiser™.
- Page 10 Wi Sure-Fit EL Series EARSET CUSTOM FITTING Left or Right Ear Placement The Wi Sure-Fit EL Series can easily be converted from right to left ear wearing preferences with a Simple-Twist™. This un- matched time saving feature delivers exceptional flexibility for venues needing to accommodate multiple users and their wearing preferences.
- Page 11 Don’t jam the in-ear receiver too far inside the ear because that will cause your ear to pop when your ear muscles flex. You should feel the Wi Sure-Fit earset gripping your ear and pressing out against your earlobe for a comfortable, secure fit.
- Page 12 Wi Sure-Fit EL Series EARSET CUSTOM FITTING Adjusting the Boom Length The Wi Sure-Fit EL Series boom can easily be adjusted to the appropriate length and placement with a simple push of a button to capture the closest near-the-mouth vocals clearly and consistently.
- Page 13 EARSET CUSTOM FITTING Adjusting the Boom Curve The Wi Sure-Fit EL Series bendable boom can easily be adjusted to position the microphone tip as close as possible to the mouth for best vocal gain and clarity. Adjust the curvature of the boom only when necessary.
- Page 14 EARSET CUSTOM FITTING Positioning The Microphone Capsule The Wi Sure-Fit EL Series removable microphone capsule is located at the tip of the boom. The key to maximizing the sound quality is to locate the capsule as close as possible to the mouth without touching the face.
- Page 15 Wi Sure-Fit EL Series EARSET CUSTOM FITTING Using The Earset/Lavalier Cable Clip The Wi Sure-Fit EL Series comes with an Earset/ Lavalier cable clip to prevent movement of the cable from dislodging the earset. The clip is specifically designed to match the diameter of your cable, either 1.4mm or 2mm.
- Page 16 Wi Sure-Fit EL Series LAVALIER CUSTOM FITTING Using The Lavalier Option The Wi Sure-Fit EL Series detachable lavalier cable for use with the removable MIC capsule is ultra-thin and easily accommodates alternative mounting applications such as: • Ties, Shirts, Jackets and Behind-the-Button Positioning •...
- Page 17 Wi Sure-Fit EL Series LAVALIER CUSTOM FITTING Connecting The Lavalier Cable The Wi Sure-Fit EL Series ultra-low-profile lavalier cable is designed for minimum visibility with maximum durability. The detachable adapter provides the flexibility to use the lavalier with a variety of optional adapters that can connect to different pocket wireless systems including Wi AudioStream™, AKG™,...
-
Page 18: Product Technical Specifications
Wi Sure-Fit EL Series PRODUCT SPECIFICATIONS Product Technical Specifications Mechanical Specifications Ear Mount: Sure-Fit™ Ergonomic Silicon Ear Mount Ear Placement: Simple-Twist™ Left/Right Ear Placement Boom Type: Simple-Twist™ Bendable, Adjustable Length Boom with Locking Mechanism Cable Type: Simple-Twist™ Detachable Cables Omnidirectional Capsule MIC Specifications (If specified by part number) - Page 19 Wi Sure-Fit EL Series PRODUCT SPECIFICATIONS Product Technical Specifications Unidirectional Capsule MIC Specifications (If specified by part number) Frequency Response: 50Hz to 15kHz Operating Current: Less than 500uA Operating Voltage: 1.5V - 10V DC Sensitivity: -51dB+/-4dB/Pascal Maximum SPL: 130 dB SPL max Output Impedance: 1.5KΩ±30%...
-
Page 20: Regulatory Compliance Information
Regulatory Compliance Information Compliance Statement We, Jangus Music Inc., declare under our sole responsibility that the Earset Microphone model EL Series to which this dec- laration relates is in compliance with the essential requirements of 2004/108/EC EMC, EN 55103-1, EN 55103-2, 2002/96/... -
Page 21: Disposal And Recycling Information
Wi Sure-Fit EL Series RECYCLING INFORMATION Disposal and Recycling Information Correct Disposal This symbol indicates that your product must be disposed of properly according to your local laws and regulations. When your product reaches its end of life, contact the retailer where the product was purchased or your local authorities to learn about recycling options. -
Page 22: Product Warranty Terms
Product Warranty Terms Jangus Music, Inc. warrants that the Wi Sure-Fit EL Series is free from material defects and faulty workmanship for a period of twelve (12) months from the date of purchase. Jangus Music will repair or replace, at its option, any Product that breaches this warranty during said period. -
Page 23: Out Of Warranty
Wi Sure-Fit EL product. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL JANGUS MUSIC OR ITS SUPPLIERS BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT,... - Page 24 . j a n g u s m u s i c . c o m © 2010 Jangus Music, Inc. All rights reserved. Wi and Jangus Music logos are registered trademarks of Jangus Music, Inc. in the United States and may be registered trademark or trademarks in other countries.
