LUNA 6
INSTRUCTION MANUAL
The Radio Controlled Clock
With the Radio-Controlled Clock, you can have the most accurate time within the continent. It can
receive the time signal transmitted by Physikalisch-Technische Bundesanstalt (PTB) of Germany,
which is regulated by 4 atomic clocks. PTB transmits the time signal (DCF77, 77.5kHz)
continuously from Mainflingen, 25 km southeast of Frankfurt am Main. It is expected that the
signal can cover a distance of approx. 1,500km from the transmitter. However, some
environmental effects affect the transmitting distance.
For more information, please visit:
http://www.ptb.de
Environmental Reception Effects
The Radio-Controlled Clock obtains the accurate time with wireless technology. Same as all
wireless devices, the receiving ability may be affected by, but not limited to, the following
conditions (see also the "Local Precautions")
• Long transmitting distance.
• Nearby mountains and valleys.
• Among tall buildings.
• Near railway, high voltage cable, etc.
• Near freeway, airport, etc.
• Near construction site.
• Bad weather.
• Nearby metallic structures.
Advertisement
Table of Contents
Related Manuals for IROX LUNA 6
Summary of Contents for IROX LUNA 6
-
Page 1: Instruction Manual
LUNA 6 INSTRUCTION MANUAL The Radio Controlled Clock With the Radio-Controlled Clock, you can have the most accurate time within the continent. It can receive the time signal transmitted by Physikalisch-Technische Bundesanstalt (PTB) of Germany, which is regulated by 4 atomic clocks. PTB transmits the time signal (DCF77, 77.5kHz) continuously from Mainflingen, 25 km southeast of Frankfurt am Main. - Page 2 Specifications • Receive 77.5kHz DCF77 signal transmitted by PTB. • Automatic time adjustment after signal reception. • Calendar with day-of-the-week display. • Hour, Minute and Second display. • 12 or 24 hour format. • Quartz crystal oscillator frequency : 32.768kHz. •...
-
Page 3: Battery Installation
Too close to household appliances (Computer, TV, video/audios, fax machines, speakers). Near construction sites, traffic lights, roadside, neon lights etc. Close to or on top of metal surfaces / plates. Battery Installation Lift the tab on the battery door located at the back of the clock. Put in batteries with proper polarity (+) and (-). - Page 4 Triggering a Receive Operation Manually You can trigger a signal receive operation at any time by pressing the SET/WAVE button, which cause the unit to perform an immediate signal receive operation. Unsuccessful Signal Reception If the automatic update is unsuccessful, the wave on top of the antenna tower and the WAVE OK icon will be disappeared, and the unit will re-try to receive the signal again every hour thereafter for maximum of 4 hours.
- Page 5 Room Thermometer The temperature is displayed on the temperature field, Hi and Lo will be shown if the temperature is out of the measurement range. Reset the Unit If the unit does not work properly, reset it by pressing the RESET button. Care of the device - Do not expose the device to extreme temperatures or direct sunlight over longer periods.
- Page 6 Support This device is a new development of Irox Development Technology. All information was made and checked by means of a functioning device. It may occur that adjustments and improvements of the device will take place that due to typographical procedures were not able to be listed in this manual.
