Summary of Contents for Allnet ALL9600T
- Page 1 ALL9600T ALL9600R User's Manual AV Extender One-Port AV Transmitter : ALL9600T One-Port AV Receiver : ALL9600R (C) 2006 ALLNET, All Rights Reserved...
- Page 2 User’s Manual One-Port AV Transmitter : ALL9600T One-Port AV Receiver : ALL9600R...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Key Features Panel Description Installation and Operation Specification Order Information Remarks... -
Page 4: Introduction
User’s Manual Introduction ALL9600 is a broadcast system to transmit AV signal (Audio + VGA) over Cat5/5e/6 cable, it can reach the distance up to 00 meters and by stacking more system Transceivers, the whole system can extend AV signal up to 900 meters. -
Page 5: Key Features
9. Provides magnetic pad and attachable metal plate for single-port unit to ease the installation 10. One-Port Transmitter ALL9600T: (1) Built in one set of AV inputs (VGA + Audio) (2) Built in one set of AV outputs (VGA + Audio) to monitor the AV signal... - Page 6 User’s Manual 11. Receiver ALL9600R:: (1) Receive AV signal through RJ45 port, and with video GAIN and FOCUS control, you can adjust the video quality, the maximum supported extended VGA resolution and distance up to 2048x156@00m (2) Built in one set of AV output (VGA + Audio) to monitor the AV signal...
-
Page 7: Panel Description
Panel Description 1. ALL9600T Single-Port AV Transmitter ❻ ❼ ❶ ❽ ❷ ❸ ❹ ❺ ❶ ❺ Power Indicator RJ-45 AV Output ❷ ❻ Power Jack H. Sync Activity ❸ ❼ VGA+Audio Output V. Sync Activity ❹ ❽ VGA+Audio+USB Power Input Magnetic Pad 2. - Page 8 User’s Manual . Cable and Accessories CBK1510AU -in-1 cable for ALL9600T...
-
Page 9: Installation And Operation
USB port or if you are using DVD Player or other device without USB port, you can plug optional power adaptor (AC7.5V, 1A ). VGA Audio USB -in-1 Cable One-Port Transmitter Installation Diagram of System Transmitter ALL9600T... - Page 10 User’s Manual () Function Test: Turn on your AV device, the POWER LED should turn on green to indicate the POWER ON status and the LEDs above RJ-45 will blink before VGA signal is turned ON and remain ON after VGA signal is turned ON.
- Page 11 (4) Connect UTP Cable: Plug two ends of UTP cable to Transmitter and Receiver’s RJ45 UTP link ports, the Receiver’s connected monitor and speaker should work now. You can adjust the FOCUS and GAIN control of Receiver to have the best VGA display. Projector VGA output Devices VGA Audio USB...
-
Page 12: Specification
User’s Manual Specification Spec AV Transceiver AV Receiver Model ALL9600T ALL9600R Description 1 Port Transmitter 1 Port Receiver AV INPUT AV x 1 RJ45 x 1 AV OUTPUT AV x 1, RJ45 x1 AV x 1 Video CTRL Video Gain and Focus... -
Page 13: Order Information
Order Information Order Details Part Number Remark AVU Cable x 1, One-Port ALL9600 AV Transmitter ALL9600T Rack-mount Kit x 1 With AC7.5V Power Adaptor x 1, One-Port ALL9600 AV Receiver ALL9600R Rack-mount Kit x 1... -
Page 14: Remarks
User’s Manual Remarks (1) Before operating this system, please read operation manual carefully. (2) Please use correct power adapter and use high quality cable for optimum broadcasting. () To prevent potential power damage, please don’t use 2 -wire extension cord and ensure AC outlets at relative devices on the same electronic phase and have correct grounding. - Page 16 (C) 2006 ALLNET, All Rights Reserved...
