Summary of Contents for Crem International CQUBE M Espresso
- Page 1 User Guide CQUBE M Espresso Your dealer U_EN Rev. 111124 Art. nr/Art. no. 1730136-02 CREM International AB Box 10, Viksgränd 2, SE-670 40 Åmotfors, Sweden Tel: +46 (0)570-477 00, Fax: +46 (0)570-47719 E-mail: info.se@creminternational.com www.creminternational.com...
-
Page 2: Table Of Contents
Contents CQube Espresso Contents page 2 General, Safety regulations, Fact, Overview, front Overview, mixer system Overview components, ingredients canister Overview membrane switch, button function front Overview user card Installation and start-up, Position machine, Fit machine Connection of the hoses for cooling unit with carbonic acid, (base cab.) Connection of carbonic acid tube, (base cabinet) Connections: electricity Connections: water, Start-up of coffee maker... -
Page 3: General, Safety Regulations, Fact
2. General . CQube Espresso Thank you for choosing a CQube espresso machine. We hope you enjoy it ! - The machine must be connected correctly for your own safety. Read the user guide before using the machine. - The guide contains important instructions for proper and safe use. - Always keep the guide close at hand. -
Page 4: Overview, Front
3. Overview, front. CQube Espresso Bean container Display Pre-selection buttons Energy-saving mode Stop Menu Drinks Card reader Door Lock Dispenser hot drinks Tap for water drinks Cup shelf Drip cover Drip tray Accessories; Base cabinet with carbonic acid tube and cooler... -
Page 5: Overview, Mixer System
3. Overview inside. CQube Espresso Bean- container Ingredients canister Bean valve Chute Grinder Grinder ON/OFF dispenser switch Cleaning buttons Brewing- mechanism Mixing bowl Grounds tray... -
Page 6: Overview Components, Ingredients Canister
3. Overview of components, ingredients container. CQube Espresso Ingredients canister. Detail; Ingredients; Width Height Cups in gram Amount of cups Canister Beans Canister Chocolate Canister Topping Espresso maskin Behållare Topping 0,01 Behållare Chocolate 0,02... -
Page 7: Overview Membrane Switch, Button Function Front
3. Overview: Membrane switch function, front CQube Espresso 5. Overview of components, function buttons AC12 Buttons function front. USER CARD Press the Back button if you want to leave the submenu and go back to the main menu. Press the Enter button if you want to enter the menu, change a value or a setting. Confi... -
Page 8: Overview User Card
3. Overview: USER CARD CQube Espresso 5. Overview of components, function buttons AC12 USER CARD USER CARD Item number: 1602692. Is used for cleaning and setting jug beverages. The user card is supplied by your dealer. For full menus. See Programming Manual. Insert the card: Display will show the Service Menu, Jug Beverage and you can now browse forwards through the menu. -
Page 9: Installation And Start-Up, Position Machine, Fit Machine
4. Installation and start-up. CQube Espresso 1. Place the machine on a fl at surface that is impermeable to water. 2. With assembly with a base cabinet; Mount the machine's top cabinet with the M6 x 35 screws supplied. M6 x 35 90°... -
Page 10: Connection Of Carbonic Acid Tube, (Base Cabinet)
4. Installation and start-up. CQube Espresso CARBONATED WATER WATER OUT Note: Do not connect the electrical cable from the cold water unit, before the machine has heated up for c.10 minutes. Connect the carbon dioxide tube to the gas canister and open the tap, check that the factory set pressure is c. -
Page 11: Connections: Water, Start-Up Of Coffee Maker
Installation and start-up. CQube Espresso Connect the water to the top cabinet on the machine. 6. Connect the factory-supplied tube to the cold water feed using a ½” R- connection piece Make sure no folding or sharp bending occurs when you push the machine back in place. -
Page 12: Connect: Electric Cable For Cold Water
Installation and start-up. CQube Espresso Start-up of coffee machine with built-in refrigeration unit for water 13. Now connect the electricity cable which comes from the bottom Figure.3. cabinet into the electric socket for the machine (B) in the top cabinet see fi gure 3). Switch on the machine again: and wait until the text in the display starts to rotate. -
Page 13: Fill Ingredients Canister
4. Installation and start-up. CQube Espresso 18. Fill the container. Fill ingredients into the containers. Remove the ingredients containers to avoid spilling in the machine) and fi ll with ingredients. 19. Fill the bean container with coffee beans. Lift the lid and fi ll the bean container with freshly roasted coffee beans without additives. -
Page 14: Brewing Of Espresso In Cup, Cold Water Dispenser
5. Operations. Brewing a cup of espresso, CQube Espresso Brewing a cup of espresso. Put a cup under the espresso dispenser. The strength of the drink is set to default. If you would like to increase or decrease the strength then follow the steps in the section below, otherwise proceed to Point 3. -
Page 15: Brewing Of Chocolate In Jug
5. Operation. Brewing chocolate in a jug. CQube Espresso Put a jug under the espresso dispenser and fold up the cup shelf. Insert the user card in the card reader(A) The display shows Service Menu, Jug Beverage. Press the E button. Change the number of cups you want to brew in your jug. -
Page 16: Cleaning Program
6. Cleaning programme; Clean brewing mechanism CQube Espresso Automatic cleaning with brewing mechanism: Cleaning the brewer mechanism should be done once a week. 1. Insert the user card in the card reader (A) 2. Move through the menu until the display shows Service Menu, Clean Machine. - Page 17 6. Cleaning programme; Clean the brewing mechanism. CQube Espresso Continuation: 10. Press E-button to start cleaning. 11. Display indicates: Preparing unit, Please wait. 12. Cleaning Unit, Time Left 60 seconds. The machine counts down from 60 seconds. 13. Display indicates: Cleaning unit, Brewcycles left 3. Machine is now cleaning the system. 14.
- Page 18 6. Cleaning programme; Rinsing the blender bowls CQube Espresso Automatic rinsing of the blender bowls, at least once a day. Lift up the cup shelf. Put a container that takes c. 0.5 litres under the dispenser for espresso Insert the user card in the card reader (A) Move through the menu until the display shows Service Menu, Clean Machine.
-
Page 19: Cleaning Dispenser Valves
6. Cleaning programme; Dispenser valves CQube Espresso Automatic cleaning of dispenser valves: Cleaning of dispenser valves Lift up the cup shelf. Put a container under both the Espresso and Water dispensers. Insert the user card in the card reader (A) Move through the menu until the display shows Service Menu, Clean Machine. -
Page 20: Flush Brew Mechanism
6. Cleaning programme; Flush brew mechanism ESP CQube Espresso Flush brew mechanism with water if necessary. Flush brew mechanism. Lift up the cup shelf. Put a container under the Espresso dispenser. Insert the user card in the card reader (A). Move through the menu until the display shows Service Menu, Clean Machine. -
Page 21: Cleaning Every Week
7. CLEANING: CLEANING EVERY WEEK Disassemble: the blendersystem 1. Loosen canister and output hose. see fi g. 1. 2. Turn the lever anticlockwise. see fi g. 2. 3. Loosen the blender bowl by pull straight out. see fi g. 3. Fig. -
Page 22: Re-Install Blender System
7. CLEANING: CLEANING EVERY WEEK Wash these parts. Clean with a moist cloth and wipe dry. Blender bowl Condensation trap Fitting plate Whisk All parts must be dry before reassembly. Reassembly blendersystem reversed. CHECK all seals before reassembly of parts. See fi g. 6. The plane side of the whisk motor shaft must correspond with the marking on the whisk. -
Page 23: Cleaning And Care
8. Cleaning and care. CLEANING CQube Espresso Cleaning when necessary. When cleaning the bean container. 1. Close the dispenser valve 2. Lift the bean container up and remove it. Use a soft rag and liquid cleaning agent that is non abrasive. Note: Ensure that the bean container is completely dry before refi... -
Page 24: Message Shown On Display
9. Message shown on display CQube Espresso Message on display: The display indicates: Energy saving mode The machine is in energy saving mode. Not available Drink cannot be selected as jug. Heating Water Low temperature in the water tank, the machine Please Wait... -
Page 25: Programming
10. PROGRAMMING CQube Espresso Activate programming with the user card Insert the user card in the card reader The display indicates: Service Menu, Jug Beverage, Clean Machine, Counters Function buttons programming Press this button if you wish to leave the submenu and return to the main menu. -
Page 26: Programming Main Menu
11. PROGRAMMING MAIN MENU CQube Espresso PROGRAMMING AND SETTINGS. Service Menu The display shows Jug Beverage Press the button Service Menu The display shows Clean Machine Press the button Service Menu The display shows Counters... -
Page 27: Jug Beverage
11. PROGRAMMING Jug Beverage CQube Espresso Alter Jug Beverage, Jug Setup Service Menu Jug Beverage Place card in the card reader. Display shows Jug Beverage Press the button Select the number of cups to be brewed in jug Press Jug Beverage Cups Select Drink 1 - 12... -
Page 28: Clean Machine
11. PROGRAMMING Clean Machine CQube Espresso Cleaning Programm: Access Cleaning menus for the user card. Place card in card reader. Display shows Service meny Jug Beverage, Clean Machine, Counters Step forward in menu Service Menu Clean Machine Cleaning of brewmechanism with cleaning Select Cleaning tablet Clean Brewer... -
Page 29: Counters
11. PROGRAMMING Counters CQube Espresso Se the number of performed cleanings or reset the counter: Place card in card reader. Step forward until Display shows Counters Press the button Press Press Beverage counter Drink 1 Counters Per beverage Served xxx Beverages to step forwards in the menu. - Page 30 11. PROGRAMMING Counters CQube Espresso Se the number of performed cleanings or reset the counter: Counters, Cleaning Counter Step forward until Display shows Counters Press button Press Counters Clean Counter Clean Counter Brewer 000 to step forwards in the menu. Press Press button...
-
Page 31: Dimension Sketch
12. Dimension sketch. CQube Espresso Electricity connection Water connection... - Page 32 FOR SERVICE Please contact your dealer ................................................
