Summary of Contents for Trane ELECTRONIC MORTISE LOCK
- Page 1 INTERACTIVE OWNER’S GUIDE ELECTRONIC LOCK TRANE ELECTRONIC MORTISE LOCK...
-
Page 2: Figure
Key fob Reading Area Outside Activation Button Outside Lever Emergency Battery Terminal (9V battery) Mechanical Key Hole Emergency Cover Figure - 1 Away Button Away Home Button Home Passage Button Passage Night Latch Button Night Latch Inside Activation Button Inside Lever Battery Cover Figure - 2 4000994... -
Page 3: Programming Legend
• Night latch mode disabled. One Beep Red - Blinks one time Function Enable/Check - PASSAgE • Passage mode enabled. Three Beeps Green - Blinks three times Function Disable - PASSAgE • Passage mode disabled. One Beep Green - Blinks one time Function Enable - hOME • TRANE Air Conditioner(s) switched ON. Three Beeps Green - Blinks three times Function Enable - AWAY • Three Beeps TRANE Air Conditioner(s) switched OFF. Red - Blinks three times 4000994 Contents... -
Page 4: Manual Programming Functions
Manual Programming Functions Press Show Press Success! OUT OUT within 0 secs Show within 0 secs beeps + blinks beeps + blinks beeps + blinks † † † beeps + Blinks † Success! Press Unlock OUT Show Door within 10 secs beeps + blinks †... -
Page 5: Table Of Contents
Contents Programming Legend........................3 Lights/Beeps Legend........................3 Manual Programming Functions..................... 4 1. User Operations ..........................7 1.1. Other Lock Parts......................... 7 1.2. Basic Functions........................... 8 1.2.1. Unlocking the Door ........................ 8 1.2.2. Check Mode of Lock ........................ - Page 6 Dear Customer, Welcome to the tRANE family. We are tRANE , a part of $ 14 billion Ingersoll Rand group. Driven by the passion for technological innovations, we are always pushing the boundaries to offer the customers what is essential to human living in order to progress. Our 100 patents are a testimony to our sprit of innovation. Today we bring innovation to your home. Enter a whole new level of comfort, convenience and security Thank you for choosing tRANE Electronic Mortise Lock. It is designed and developed by Schlage , the most trusted and preferred brand for home security in US. tRANE electronic mortise lock makes your everyday living simple and intuitive. The innovative technology used in our security systems will take you to a new level of safety and convenience. Before Use Read all documentation supplied with this product. Do not discard manuals. Keep manuals readily available for all personnel. Product Functions Door is assumed to be in closed condition. The tRANE lock offers below features : S.No.
-
Page 7: User Operations
1. User Operations 1.1. Other Lock Parts Mechanical Keys Door Position Sensor (DPS) and User Keyfobs Programming Keyfob AA Batteries DPS Magnet Face Plate Latch Bolt Guard Latch Dead Bolt Strike Plate & Dust Box Mortise Lock Unit Figure - 3 4000994 Contents... -
Page 8: Basic Functions
1.2. Basic Functions 1.2.1. Unlocking the Door Press Once Press outside activation button. See these indications: O utside activation button blinks three times Three Beeps † in orange colour Show user key fob (black) on area in less than ten seconds. See these indications: O utside activation button blinks three times Three Beeps † in green colour Turn outside lever in less than five seconds to unlock. 1.2.2. Check Mode of Lock Press inside activation button. See these indications: I nside activation button blinks one time in One Beep † orange colour On successful operation following lock status indications are observed: N ight latch button blinks Night latch ON Three Beeps †... -
Page 9: Disabling Night Latch Mode
1.3.2. Disabling Night Latch Mode Press Twice Press Once Away Away Home Home Passage Passage Night Latch Night Latch Press inside activation button two times to activate lock*. See these indications: I nside activation button blinks three times Three Beeps † in orange colour Press night latch button in less than ten seconds to disable night latch mode. On successful operation, lock will be in normal mode. See these indications: N ight latch button blinks one time in red colour One Beep † 1.3.3. Enabling / Disabling Night latch Mode (from AC Remote) AC Remote Display Press on remote to activate or deactivate night latch mode on lock. Night latch will show on... -
Page 10: Disabling Passage Mode
I nside activation button blinks three times Three Beeps † in orange colour Press passage button in less than ten seconds to disable passage mode. On successful operation lock will be in normal mode and see these indications: Passage button blinks one time in green colour One Beep † 1.4. home Connect Operations User operations 1.4.1 and 1.4.2 are part of home connect solution (tRANE Lock and tRANE Residential air conditioners). Make sure that lock and air conditioner(s) are connected to tRANE network to ensure that the user operations work as mentioned in 1.4.1 and 1.4.2. Refer AC user guide for procedure to connect lock and air conditioner(s). Refer AC user guide for AC Audio - Visual indications. 1.4.1. Away Mode In this mode lock will switch off all the TRANE air conditioner(s) which are ON. Press Twice Press Once Away Away Home Home Passage Passage... -
Page 11: Home Mode
1.4.2. home Mode In this mode lock will switch ON all the TRANE air conditioner(s) which were switched OFF using the lock away command. This will not switch ON those air conditioner(s) which are switched OFF using remote controller. Press Twice Press Once Away Away Home Home Passage Passage Night Latch Night Latch Press inside activation button two times to activate lock*. See these indications: I nside activation button blinks three times Three Beeps † in orange colour Press home button in less than ten seconds. See these indications: Home button blinks one time in green colour One Beep † On successful operation air conditioner(s) will be turned on and see these indications: I nside activation button blinks three times Three Beeps † in green colour Home button blinks three times in green colour Three Beeps †... -
Page 12: Programming Key Fob Registration
Show unregistered user key fob (black) on area in less than thirty seconds. On successful registration, see these indications: O utside activation button blinks three times Three Beeps † in green colour Repeat steps & 4 to add multiple user key fobs (black). To register next user key fob (black), show in less than thirty seconds Note: Maximum of 0 user key fobs can be registered. 1.5.2. Programming Key Fob Registration Remove batteries (Refer section 1.7.1) K eep home button pressed till beep sound while inserting batteries. One Beep † All buttons blinks one time O utside activation button blinks three times Three Beeps † in orange colour Show programming key fob (red) on area in less than thirty seconds. On successful registration, see these indications: O utside activation button blinks three times Three Beeps † in green colour 1.6. Emergency and Miscellaneous Operations 1.6.1. -
Page 13: Delete All User Key Fobs
Passage button blinks three times in green colour Three Beeps † Note: L ock will be in passage mode. Once new user key fob (black) is registered, lock will be in normal mode. 1.6.4. Factory Settings Remove batteries (Refer Section 1.7). Insert three batteries and keep inside activation button pressed till beep sound while inserting fourth battery. See these indications: One Beep † All buttons blinks one time I nside activation button blink one time in One Beep † red colour I nside activation button blinks three times Three Beeps † in green colour Passage button blinks three times in green colour Three Beeps † Lock will be in passage mode, deletes all user key fobs (black) and disconnects air conditioner(s) in TRANE network. All programming key fob functions are retained. * Press two times in less than two seconds. Beeps only when audio is enabled. † 4000994 Contents... -
Page 14: Disable Audio
1.6.5. Disable Audio Press Once Press Once Away Home Passage Night Latch Press outside activation button. See these indications: O utside activation button blinks three Three Beeps † times in orange colour Show programming key fob (red) on area in less than ten seconds. See these indications: O utside activation button blinks three Three Beeps † times in orange colour Press home button in less than thirty seconds. On successful operation, audio is disabled and see these indications: H ome button blinks three times in green colour No Audio Tamper alarm and Door open alert audio does not turn off. 1.6.6. Enable Audio Press Once Press Once Away Home Passage... -
Page 15: Lock Activation
1.6.7. Lock Activation Insert four AA batteries (Refer Section 1.7). See these indications: One Beep † All buttons blink one time On successful activation, lock will be in normal mode. 1.7. Battery Installation Remove battery cover screw holding the cover in place (Refer figure - 4). Slide battery cover down. Remove four batteries. Replace all with four new batteries of recommended specifications. (Duracell®# ‘AA’ batteries rated 1.V) Slide Battery cover to its original position. Secure battery cover with battery cover screw. Batteries Screw, Battery Cover Figure - 4 * Press two times in less than two seconds. Beeps only when audio is enabled. † 4000994 Contents... -
Page 16: Trouble Shooting Guide
2. trouble shooting guide Problem/ Indication Cause Remedy Symptom Key fob is not shown Show registered user One long beep and † area and/or is key fob (black) on out of range ( cms). outside activation area not more than Key fob shown button blinks one time cms away. after ten seconds in red colour (time out Show key fob in less of pressing outside indication). than ten seconds. activation button. Unable to unlock with † Five beeps and registered user key Replace with new fob (black) outside activation Battery low. batteries button blinks five times (Refer section 1.7) in red colour. -
Page 17: Maintenance Guide
† No door position sensor indication Lock is in passage mode. Disable passage mode. No beep † when door is open. 3. Maintenance guide Wipe with soft cloth. Avoid paint smears, thinners and strong cleaning agents as they destroy protective coatings. In case lock is damaged and not working, do not try to fix it, call customer care helpline. 4. After Sales Service On calling customer care helpline, provide following information: Complete address and contact number. Serial Number. Warranty number Nature of malfunction. Do not allow any unauthorized person to service or repair the lock. This may affect functioning and quality of the product. This may also make the product warranty null and void. Call our customer care helpline 1-800-102-9986 (toll free) or email us on care@trane.com for any product related queries. * Press two times in less than two seconds. Beeps only when audio is enabled. † 4000994 Contents... -
Page 18: Warranty
Warranty Warranty Clause Subject to the terms and conditions of this warranty, TRANE extends a one-year limited warranty on the mechanical and finish warranty and a one-year limited electronics warranty to the original consumer user (“Original User”) of our TRANE brand product (“Product”) from the proven date of purchase against defects in material and workmanship, as long as the Original User occupies the residential premises upon which the Product is originally installed. The customer should retain the warranty card (after filling the details required and stamping done from the relevant dealer/distributor where it was originally purchased), along with the cash memo/invoice indicating date and time. Original User: This warranty only applies to the Original User of Products. This warranty is not transferable. What tRANE will do: Upon return of the faulty Product to TRANE, TRANE’s sole obligation, at its option, is to either repair or replace the Product, In case of a repair or replacement of the product, the period of warranty would continue from the original date of purchase. Replaced parts/products will be the property of the company. What is not covered? Surface Finish discoloration/shade of the product is not applicable to the above warranty. Labour costs including, but not limited to, such costs as the removal and reinstallation of Product; iii) Shipping and freight expenses required to return Product to TRANE; Any other incidental, consequential, indirect, special and/or punitive damages, whether based on contract, warranty, tort (including, but not limited to, strict liability or negligence), patent infringement, or otherwise, even if advised of the possibility of such damages. Warranty on the product will not be applicable under the conditions including but not limited to: Misuse/mishandling/negligence/improper installations done by other personnel apart from TRANE or its authorized dealers/ improper application/improper repair/tampering. - Page 19 Corporate Office: Plot No.35, KIADB Industrial Area, Bidadi, Ramanagaram Taluk, Bangalore-562109, Karnataka, INDIA. www.traneindia.com For more information call on 1800 102 9986 or write to care@trane.com 24000994 | Edition 1 | June 2012...
