Summary of Contents for Rancent Tech RG59
- Page 1 IR HIGH SPEED DOME CAMERA USER’S MANUAL Rancent Technologies Ltd,. 10/F Hong Kong Trade Centre, 161 Des Voeux Road Centrl, Hong Kong Tel: +852 2816 7037 Fax: +852 2855 8158...
-
Page 2: Table Of Contents
Table Of Contents 1 Precautions ……………………………………………… 2 Features………………………………………………… 3 Technical Data…………………………………………… 4 Installation Guide………………………………………… 5 Dome Settings…………………………………………… 6 Preset Setting…………………………………………… 7 The OSD Menu Setting…………………………………... -
Page 3: Precautions
1 Precautions 1.Transportation Security No heavy stress, violent vibration or water splash are allowed during transportation,storage.The unit should be transported in separated packing.In shipments of distributor and delivery of maintenance,any damages caused by integral packing are not covered by warranty. 2.Installation Avoid heavy stress and violent vibration during installation. -
Page 4: Features
2 Features 2.1 Built-in Decoder Presets calling speed :350 /S... - Page 5 2.5 Function Instructions Focus / Pan / Tilt Speed Auto Match The pan/tilt rotation speed could be auto adjusted according to the focus in/out, which makes it great performance for manual target tracking. Auto Flip The lens can auto flip when it rotates 180° Preset Position Setting and Calling Preset function means the speed dome can memory current pan/tilt angel, focus, zoom, ect.
-
Page 6: Lens Control
Lens Control Zoom Control Users can control zoom by keyboard to get near or far images. Auto Iris Control Auto sense ambient light, and make quick adjustments. Auto Back Compensation In the bright background, auto compensate light for the target, and adjust the back light. -
Page 7: Technical Data
3 Technical Data PowerPower Supply DC12V & 5A Operating Temperature Indoor 0 50 Outdoor -35 60 Operating moisture < 95% Power Consumption Indoor 15W Outdoor 55W Communication RS-485 bus Communication transmission speed 2400/4800/9600BPS Protocols Pelco-D, Pelco-P,HS Pan speed 0.01°-180° /s Titlt Angle 0 -90°... -
Page 8: Installation Guide
4 Installation Guide 4.1 Installation Preparation Video Coaxial Cables Mode Max Distance RG59/U 750ft(229m) RG6/U 1,000ft(305m) RG11/U 1,500ft(457m) 4.2 Structure 4.3 Installation Size... -
Page 9: Installation Procedures
4.4 Installation Procedures *Notice: The wall must be thick enough to install the expansion screws and can bear 4 times the weight of the dome camera itself. (1) Bore 4 holes by using templates included on the wall. (2) Mount 4 M8 expansion screws into the holes... - Page 10 (3) Put the cables through the bracket. Fix the dome base and the bracket with M5 screws. (4) Use screw-caps and shims to fix the bracket on the wall.
-
Page 11: Dome Settings
5 Dome Setting Before the dome is installed,the communication protocol, baud rate and dome address, should be confirmed.Set the DIP switch, keeping the setting consistent with the control system. The relative DIP switch site and connecting wires are diagramed below for reference. SW1 is address setting switch,SW2 is protocol setting switch. -
Page 12: Dome Address Setting
Dome Address Setting PELCO-P & HS protocol Address SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8... - Page 13 PELCO-D protocol Address SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8...
- Page 14 Cable Definition...
-
Page 15: Preset Setting
6 Preset Setting Speed dome camera supports 220 preset positions. The code numbers 1- 64 and 100-255 represent the 220 preset positions. You can activate some special functions by calling upon code number 65-99. Command Command packet Comments Start Auto Scan Call 99 Default to start the first group of auto scan... -
Page 16: The Osd Menu Setting
7 The OSD Menu Setting Operation Method of the Menu: 1.Access main menu (call preset 95). 2.Use the joystick to position the cursor beside menu selec- tion. NOTE: If your controller does not have a joystick, use the up or down key. 3.Press Iris Open, the submenu/cursor moves to the right. -
Page 17: Osd Menu Tree
OSD Menu Tree SYSTEM INFORMATION DOME ID: 123456789 0 ADD RESS: 001 BAUD RATE: 9600,N,8,1 PROTOCOL: PELCO P : 31C ALARM: 000000 00 <OTHERS> BACK EXIT DISPLAY DOME TITLE : OFF PRESET : 5 SEC MOTION : 5 SEC ZONES : 5 SEC DATE/TIME : PAN/TILT :... - Page 18 LANGUAGE The language for the on-screen menus is MAIN MENU LANGUAG E: ENGLISH selectable. Available languages include <SYSTEM INFORMATION> English and Chinese. <DISPLAY SETUP > <DOME SETTINGS > <CAMERA> <MOTION> To change the display language: RESTART FACTORY DEFAULTS 1. Use the joystick to position the cursor HELP beside LANGUAGE.
-
Page 19: System Information
SYSTEM INFORMATION The System Information screen displays MAIN MENU LANGUAGE: ENGLISH dome drive model, software version, and <SYSTEM INFORMATION> <DISPLAY SETUP> other diagnostic information.System <DOME SETTINGS> <CAMERA> settings cannot be changed using this <MOTION> RESTART screen. This screen is for reference only. FACTORY DEFAULTS HELP EXIT... -
Page 20: Display Setup
DISPLAY SETUP Display setup allows you to program how MAIN MENU labels are displayed on the monitor. LANGUAG E: ENGLISH <SYSTEM INFORMATION> <DISPLAY SETUP > <DOM E SETTINGS> The following settings are available for <CAMERA> each label: <MOTION> RESTART FACTORY DEFAULTS Label is not displayed when HELP EXIT... - Page 21 ALARM The dome system has 4 alarm inputs and 2 MAIN MENU alarm outputs. When an alarm is received, an LANGUAG E: ENGLISH input signal to the dome triggers the user <SYSTEM INFORMATION> <DISPLAY SETUP > defined action (go to preset, run pattern, etc.) <DOM E SETTINGS >...
-
Page 22: Privacy Mask
PRIVACY MASK Privacy mask allows a user to program areas MAIN MENU LANGUAG E: ENGLISH that cannot be viewed by the operator of the <SYSTEM INFORMATION> dome system. A blanked area will move with <DISPLAY SETUP > <DOME SETTINGS > pan and tilt functions and automatically adjust <CAMERA>... - Page 23 CLOCK The clock is used to program the current MAIN MENU LANGUAG E: ENGLISH date and time. The date and time set in <SYSTEM INFORMATION> the Clock menu is used to program <DISPLAY SETUP > <DOM E SETTINGS > events. The date and time can also be <CAMERA>...
- Page 24 PASSWORD MAIN MENU The dome features password protection LANGUAG E: ENGLISH to prevent unauthorized changes to the <SYSTEM INFORMATION> <DISPLAY SETUP > dome settings. An operator cannot <DOME SETTINGS > access any of the dome settings menus <CAMERA> <MOTION> without a valid password. RESTART FACTORY DEFAULTS HELP...
- Page 25 DOME TITLE Dome title is the label used to identify the MAIN MENU LANGUAG E: ENGLISH camera viewed on the monitor. Up to 12 <SYSTEM INFORMATION> characters can be used for a title. <DISPLAY SETUP > <DOME SETTINGS > To edit the title text label, do the following: <CAMERA>...
- Page 26 SOFT ADDRESS Dome support soft address function,use this MAIN MENU LANGUAG E: ENGLISH function bit 7 of setting switch 2 must be set to <SYSTEM INFORMATION> <DISPLAY SETUP > <DOM E SETTINGS> "on".In this case,address setting switch 1 will <CAMERA> <MOTION>...
- Page 27 MAIN MENU An auxiliary output is a programmable signal LANGUAG E: ENGLISH from the dome back box that can trigger <SYSTEM INFORMATION> <DISPLAY SETUP > another device to operate. An auxiliary output <DOME SETTINGS > <CAMERA> <MOTION> is programmable to trigger from an alarm or RESTART FACTORY DEFAULTS from a controller.
- Page 28 SOFT LIMIT MAIN MENU Limit stops are programmable stops that limit LANGUAG E: ENGLISH the pan range of the dome. There must be two <SYSTEM INFORMATION> <DISPLAY SETUP > <DOM E SETTINGS> limits, a left and a right, to define an area. <CAMERA>...
- Page 29 POWER ON ACTION This setting defines a specific activity (scan, MAIN MENU LANGUAG E: ENGLISH preset, pattern) to be performed in the event <SYSTEM INFORMATION> <DISPLAY SETUP > the power to the dome is cycled. <DOM E SETTINGS> <CAMERA> <MOTION> The following settings are available: RESTART FACTORY DEFAULTS...
- Page 30 COMMUNICATION TEST MAIN MENU Use our special software user can test the LANGUAG E: ENGLISH reliability of the dome control line.After <SYSTEM INFORMATION> <DISPLAY SETUP > <DOM E SETTINGS> testing,the reliability value 0-100 will display on <CAMERA> <MOTION> the screen. RESTART FACTORY DEFAULTS HELP...
- Page 31 DOME OTHER SETTINGS TEMP MODE Temperature control mode MAIN MENU COOL Fan pwoer on,heater auto LANGUAG E: ENGLISH <SYSTEM INFORMATION> AUTO Fan auto,heater auto <DISPLAY SETUP > <DOME SETTINGS > HEAT Fan power on,heater power on <CAMERA> <MOTION> OFF Fan power off,heater power off RESTART FACTORY DEFAULTS INTERNAL FAN...
- Page 32 CAMERA AUTO FOCUS MAIN MENU Auto focus allows the lens to remain in focus LANGUAG E: ENGLISH <SYSTEM INFORMATION> during zoom-in, zoom-out, and motion func- <DISPLAY SETUP > tions. <DOM E SETTINGS> <CAMERA> There are two auto focus settings: <MOTION> RESTART The camera will focus automatically FACTORY DEFAULTS...
- Page 33 CAMERA ADVANCED MAIN MENU WHITE BALANCE This feature automatically processes the LANGUAG E: ENGLISH <SYSTEM INFORMATION > viewed image to retain color balance over a <DISPLAY SETUP> <DO ME SETTINGS> color temperature range. The default setting <CAMERA> for auto white balance is ON. <MOTION>...
- Page 34 PRESET Use the following steps to program a MAIN MENU LANGUAG E: ENGLISH preset. <SYSTEM INFORMATION> 1. Select the preset number: <DISPLAY SETUP > <DOM E SETTINGS> a. Use the joystick to position the cursor <CAMERA> <MOTION> beside PRESET NO. Press Iris Open.The RESTART FACTORY DEFAULTS cursor moves to the right.
- Page 35 SCAN MAIN MENU SCAN NO. LANGUAG E: ENGLISH Use the joystick to position the cursor beside <SYSTEM INFORMATION> <DISPLAY SETUP > SCAN NO. and press Iris Open to enter the <DOM E SETTINGS> <CAMERA> edition mode of scan No., move the joystick <MOTION>...
- Page 36 SEQUENCE SEQ NO. MAIN MENU LANGUAG E: ENGLISH Use the joystick to position the cursor beside SEQ <SYSTEM INFORMATION> <DISPLAY SETUP > <DOM E SETTINGS> NO. and press the key Iris Open to enter the edition <CAMERA> <MOTION> RESTART mode, move the joystick up or down to select FACTORY DEFAULTS number.Then press Iris Open to confirm.
- Page 37 PATTERN MAIN MENU A pattern is a memorized, repeating LANGUAG E: ENGLISH series of pan, tilt, zoom, and preset func- <SYSTEM INFORMATION> tions that can be recalled with a com- <DISPLAY SETUP > <DOM E SETTINGS> mand from a controller. <CAMERA>...
- Page 38 ZONES MAIN MENU Horizon dome systems are capable of eight zones, each with a 12-character LANGUAG E: ENGLISH <SYSTEM INFORMATION> label. <DISPLAY SETUP > <DOM E SETTINGS > <CAMERA> <MOTION> To program a zone: RESTART FACTORY DEFAULTS 1. Use the joystick to position the cursor HELP beside ZONE NO.
- Page 39 TIMING ACTION MAIN MENU SCHEDULE NO. LANGUAG E: ENGLISH Schedule Number of a day 1-8. <SYSTEM INFORMATION> <DISPLAY SETUP > <DOM E SETTINGS> <CAMERA> START <MOTION> Start time of timing action. RESTART FACTORY DEFAULTS HELP STOP EXIT Stop time of timing action. MOTION MOTION Select timing action during designated...
-
Page 40: Motion Detect
MOTION DETECT SCENE NO. MAIN MENU LANGUAG E: ENGLISH Select motion detection scene number 1-8. <SYSTEM INFORMATION> <DISPLAY SETUP > EDIT SCENE <DOM E SETTINGS> <CAMERA> Set motion detection scene. <MOTION> RESTART EDIT AREA FACTORY DEFAULTS Edit detection areas,four motion detection areas HELP EXIT... -
Page 41: Auto Tracking
AUTO TRACKING SENSITIVITY MAIN MENU LANGUAG E: ENGLISH Set the sensitivity of tracking: <SYSTEM INFORMATION> <DISPLAY SETUP > HIGH The sensitivity level is high. <DOM E SETTINGS> <CAMERA> <MOTION> MID Average sensitivity. RESTART FACTORY DEFAULTS LOW The sensitivity level is low. HELP EXIT TARGET... - Page 42 IR LED SETTING We could set the IR LED on or off and option mode via IR LED setting manual. 1.CONTROL MODE DOME SETTINGS AUTO : IR LED could turn on or turn off automatically <IR LED> based on the light; <IDLE>...
- Page 43 RESTART RESTART SYSTEM MAIN MENU Reboot the system if it is not operating or LANGUAG E: ENGLISH if there is no control. Rebooting the <SYSTEM INFORMATION> <DISPLAY SETUP > system will cycle dome and camera <DOM E SETTINGS> <CAMERA> power without changing programmed <MOTION>...
-
Page 44: Factory Defaults
FACTORY DEFAULTS Restore factory default settings of the MAIN MENU dome. LANGUAG E: ENGLISH <SYSTEM INFORMATION> <DISPLAY SETUP > <DOM E SETTINGS> <CAMERA> <MOTION> RESTART FACTORY DEFAULTS HELP EXIT WA RNING ARE YOU SURE... CANCEL... - Page 45 HELP HELP MAIN MENU Disply menu operating help information LANGUAG E: ENGLISH <SYSTEM INFORMATION> on the screen. <DISPLAY SETUP > <DOME SETTINGS > <CAMERA> <MOTION> RESTART FACTORY DEFAULTS HELP EXIT MENU OPERATION HELP 1.CALL PRESET95 TO OPEN MENU . 2.MOVE JOYSTICK TO SELECT MENU ITE M.
