AQUA SPAS
PRODUCT REFERENCE
Please fill out and keep this form for future reference.
The serial number is on your right below the keypad on the spa base.
Spa Information
Spa Model:
Spa Serial Number:
Spa Model Number:
Spa Color:
Date of purchase:
Dealer Information
Company:
Address:
Telephone Number:
Email:
Every effort has been made to ensure the accuracy of this manual.
However, due to continuous improvement projects, all models, operation, and /or
specifications are subject to change without prior notice.
Aqua Spa Owner´s Manual, page 1
Congratulations Aqua Spa Owner!
You've made a wonderful investment toward your own general health and well being.
We are certain that you will enjoy this spa for many years.
In order to receive the full benefit of your spa, you need to understand how it functions.
We suggest than you take some time to carefully read this owner's manual.
The manual is meant to be a supplement to the training you should receive from your
Aqua Spas dealer when you purchase and start up your spa for the first time.
Your spa is a powerful piece of electrical equipment, with proper care and installation it
will provide years of safe use and enjoyment for your family and friends.
This manual contains safety warnings and installation instructions, as well as operating
and maintenance procedures.
If you have any questions or comments regarding this manual or your new spa, please
contact your authorised Aqua Spas dealer.
Welcome to your Aqua Spa experience
Sincerely,
Aqua Spa Team
Aqua Spa Owner´s Manual, page 2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for AQUA SPAS Spa
- Page 1 Congratulations Aqua Spa Owner! AQUA SPAS You’ve made a wonderful investment toward your own general health and well being. PRODUCT REFERENCE We are certain that you will enjoy this spa for many years. In order to receive the full benefit of your spa, you need to understand how it functions. Please fill out and keep this form for future reference. We suggest than you take some time to carefully read this owner’s manual. The serial number is on your right below the keypad on the spa base. The manual is meant to be a supplement to the training you should receive from your Aqua Spas dealer when you purchase and start up your spa for the first time. Spa Information Your spa is a powerful piece of electrical equipment, with proper care and installation it will provide years of safe use and enjoyment for your family and friends. This manual contains safety warnings and installation instructions, as well as operating Spa Model: and maintenance procedures. Spa Serial Number: If you have any questions or comments regarding this manual or your new spa, please contact your authorised Aqua Spas dealer. Spa Model Number: Welcome to your Aqua Spa experience Spa Color: Sincerely, Aqua Spa Team Date of purchase: Dealer Information Company: ...
-
Page 2: Table Of Contents
COULD SAVE A LIFE! SITE PREPARATION …………………………………………………….. pg. 9 READ AND FOLLOW ALL WARNINGS! ELECTRICAL REQUIREMENTS………………………….. …………..pg. 9 · WARNING Risk of Accidental Drowning To avoid accidents, do not INSTALLATION PROCEDURE …………………………………………. pg. 10 permit children to use this product unless they are closely supervised by an adult at all times. Do not let children dive under the water they may get trapped by suction line. STARTING FOR THE FIRST TIME ..………………………………….. pg. 10 Always lock the spa cover after using your spa for your children’s safety. · WARNING Risk of injury Never operate your spa if the suction fittings OPERATING INSTRUCTIONS ………………………………………….. pg. 11 are broken or missing to prevent body and hair entrapment. Never replace a suction fitting with one rated less than the flow rate marked on the original suction fitting. The MAIN FUNCTIONS ..……………………………………………………. pg. 12 suction fittings in your spa are sized to match the specific water flow created by the pump. In case of replacement of the suction fittings or the pump, be sure the flow rates LOW LEVEL PROGRAMMING ………………………………………… pg. 14 are compatible. · Wiring should be done by a qualified electrician according to EU WATER QUALITY AND MAINTENANCE …………………………….. pg. 15 ... -
Page 3: Basic Operation Information
BASIC OPERATION INFORMATION · Users with a history of heart disease, low or high blood pressure, circulatory system problems, or diabetes and obese people should consult a physician before · Place your spa on a flat surface using a spa. · Wipe the interior of the spa with a damp cloth. · People using medication should consult a physician before using a spa since some · Fill the spa with water medication may induce drowsiness while other medication may affect heart rate · Never turn the spa on without water. It will void your warranty if any damage blood pressure, and circulation. occurs to the pumps, heater, or controller. · If you experience symptoms of hypothermia (increase in body temperature, · Connect spa to power supply dizziness, fainting, lethargy, drowsiness) refrain from further use of the spa and · Set your water temperature consult your physician. · Wait until the water is comfortable. · People with infectious disease should not use a spa. · ... - Page 4 Knife Valves – the knife valves are used to cut off water flow to the pump in case you need to remove it. For normal operation, the gate valves must remain open. Filter Housing – creates a powerful suction used to pull particles and debris through the filter element. Air Blower – supplies air to the air injectors creating a hydro massage action. Drain Valve – Drains water from the spa. Exterior Components Description Control panel / Keypad – gives you unrestricted access to all of the spa’s functions Light – illuminates the spa water at dark. Massage Jets – the individual jets can be turned on and off. This is done by simply turning the outer jet housing. Turning clockwise will turn the jet on, and turning counterclockwise will turn the jet off. Individual jet control can be done independently from normal diverter valve settings. Suction Intake – it sucks water back into the pumps system to recirculate and run through the jets. Filter Intake – point at which water is drawn into the filter assembly to remove both large debris and small particles. Diverter Valve – allow you to control water pressure and direct water to ...
-
Page 5: Electrical Requirements
SITE PREPARATION INSTALLATION PROCEDURE Because your new spa is portable, you can locate it just about anywhere you wish on a · We recommend that you leave some space open around your spa to allow for easy patio, on a deck, in the middle of your yard, or even indoors. Just be sure to position it access from all sides, making any maintenance easier. above ground in a levelled area with good drainage. It has to support the weight of the · Fill the spa with the water from the hose through the filter inlet (after filling is spa when filled with water and people. complete, remember to put the filter cartridge in place prior to starting the spa). This way · It is responsibility, of the spa owner, to make sure that the spa is on a solid, you minimise the chances of trapping air into the pump system. The water level should be level, and appropriate surface or base. half way up the filter area. · Place the spa on at least 1012 cm of solid dry concrete. Do not place spa on · Never allow the water level to drop bellow the skimmer opening. Air will enter into wet or not completely dry concrete, which may tend to sink or sag and damage the spa water lines system, causing problems with the water flow. Running the pump without and will void your warranty. Make sure that the concrete is leveled. -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS MAIN FUNCTIONS To operate your spa you use your main control panel (keypad). – it features 4 This section describes the most commonly used functions during the operation of the buttons (Pump, Blower, Light, Up/Down) and an LCD screen, which displays controller. information on the status of the system, such as the water temperature or error messages. Typically, each function is managed by a specific button, however sometimes the same button can be used to control more than one function (depending on the version of the firmware installed). The table below summarises the functions assigned to each button. Button Function Pump Starts and stops jet pump. Blower Starts and stops the blower. Switches the light on and off Light Increase the values being set. Up Keypad TSC9 Decrease the values being set. Down Pump if the pump is not stopped manually, it stops automatically after 20 minutes of continuous operation. Key to Display Panel Icons and Buttons Light if the light is not switched off manually, it switches off automatically after 20 ... -
Page 7: Low Level Programming
Powerup signal the PowerUp function signals that a power failure has occurred, if adjustment of the current management feature will invalidate your warranty. this is the case the current water temperature flashes on the display. Controlling the water temperature water temperature is maintained automatically It’s possible to configure various system operating parameters from the key pad. and the spa will heat to within 0.5 °C either side of the desired temperature. When the This is normally done by the spa manufacturer, but may be done at any time. The heater is activated, the corresponding icon on the display remains lit. The same icon configuration will be stored in the controller’s memory. To program these system flashes when the water needs to be heated, but the heater is not active. ... -
Page 8: Water Quality And Maintenance
CHEMICAL SAFETY INSTRUCTIONS spa water should be maintained within the range of 80120 mg/l. This will keep the pH Do not keep your water treatment chemicals outside. stable and help prevent against scaling and cloudy water. Chemicals used to maintain KEEP ALL CHEMICALS OUT OF THE REACH OF CHILDREN! total alkalinity are available from your dealer. · Always read your chemical kit’s instructions before adding anything to the spa Total Hardness water. Total hardness refers to the amount of calcium and magnesium in the water. · Always use brand name spa chemicals. Consult your dealer who will know High pH levels can produce scale deposits on a spa’s surface and also in the pump equipment. how to use the spa chemicals and where to buy them. · Never use spa chemicals if you do not know how to use them. To maintain water clarity additional chemicals such as flocculants, algaecides, · Remember to always maintain a safe and ideal level of chemicals in the spa’s antifoam agents can be used. Consult with your Aqua Spa dealer for more details. water. · Failure to keep the spa’s water clean, balanced, and filtered may result in clogged jets and calcification to the spa’s surface, which may result in discoloration, ... -
Page 9: General Spa Maintenance
Change the water approximately every threefour months. Remove and clean filter cartridges, and store in a secure place to prevent freezing. Do not turn unit off with water in the spa. Frozen water may rupture plumbing. Freeze · Open the equipment compartment and check for leaks every few months. damage repairs are not covered under warranty. · Clean your cabinet as needed. Spa surface Always keep your spa cover on the spa to avoid the spa’s surface from being discolored, cracked, sun grazed, spiderlike cracks, or gloss to fade on the smooth glossy acrylic finish. To clean the spa surface, all you need is a soft cotton towel or moist cellulose sponge with clean water. Never use abrasive cleaner or hand brush, cleaning solvents, acetone, or alcohol to clean the spa. This can fade, discolor, or even crack the surface, voiding the warranty. Spa equipment and pumps The spa equipment and the pumps do not need any regular maintenance. The equipment and the pumps are maintenance free. Jets Once a month check all your jets to see if they are working properly. The jets that are adjustable turn face left and right making sure they are free from any obstructions. Changing the Water It is suggested that you change the water once every four months depending on the area and the amount of usage. Draining the spa Because your spa holds a relatively small amount of water, contaminants such as body oil, perspiration, dirt, hair, etc., may become quite concentrated. For this reason, the water should be drained and replaced every threefour months depending on use. Before draining the spa, turn of power at the breaker. Aqua Spa Owner´s Manual, page 18 Aqua Spa Owner´s Manual, page 17 ... -
Page 10: Troubleshooting
Increase pH with pH plus Low pH Check that the circulation pump is operating. Foaming Body oils, lotion Check that the level of the water is And chemicals sufficient and that the valves are open. Resulting in soap Clean the filter. Or detergent Add antifoam agent If the problem persists contact our Excessive organics Shock the spa with appropriate chemical agent technical service department. Old water Drain, clean and refill the spa If you have any questions please visit or call your dealer for assistance. Sometimes you may need to get advice from your dealer to further understand this manual or for help with your spa. Aqua Spa Owner´s Manual, page 19 Aqua Spa Owner´s Manual, page 20...
